Multiplex Control System (Hybrid): Overview Honda Civic VII рестайлинг

Scheme 26

Scheme 27

Scheme 28

System Descriptions

The multiplex Control System has four internal functions

1. Multiplexing (send multiple signals over shared wires)
2. Wake up/sleep (runs at full power only on demand to reduce battery draw)
3. Fail-safe (fixes or ignores faulty signals)
4. Self-diagnosis (Mode 1 for the system, Mode 2 for input lines)

The system controls the function of these circuits

1. Entry light control (ignition key light and ceiling light)
2. Wiper/washer (intermittent wipe and park functions)
3. Keyless/power door lock
4. Meter assembly, temperature gauge, and indicator lights
5. HVAC (compressor and fan control)
6. Key-in reminder
7. Headlight reminder
8. Seat belt reminder
