Accord & Prelude (Except Prelude With Automatic Torque Transfer System - ATTS)
- Raise and support vehicle. Remove lock nut on end of radius (strut) rod. (Scheme 1) Remove radius rod bolts and radius rod from lower control arm.
- Adjust caster angle by increasing or decreasing adjusting shims. On Prelude, a 1/8" (3.2 mm) thick shim changes caster angle by.67 degree (40 minutes). Caster angle can be adjusted a maximum of 1.33 degree (one degree, 20 minutes). On Accord, a 1/8" (3.2 mm) thick shim changes caster angle by.58 degree (35 minutes). Caster angle can be adjusted a maximum of 1.17 degree (one degree, 10 minutes). Install NEW lock nut. Tighten radius rod bolts and lock nuts to specification. See «TORQUE SPECIFICATIONS»(ref-99218-S38305720582001062900000).
Scheme 1
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Accord |
| Radius Rod Flange Bolts | 119 (162) |
| Radius Rod Lock Nut | 40 (54) |
| Rear Control Arm Adjusting Bolt Lock Nuts | 40 (54) |
| Tie Rod Lock Nut | 33 (45) |
| Wheel Lug Nuts | 80 (108) |
| Civic |
| Front Damper Pinch Bolts | 76 (103) |
| Rear Control Arm Adjusting Bolt | 43 (59) |
| Tie Rod Lock Nut | 33 (44) |
| Wheel Lug Nuts | 80 (108) |
| CR-V |
| Rear Control Arm Adjusting Bolt | 47 (64) |
| Tie Rod Lock Nut | 40 (54) |
| Wheel Lug Nuts | 80 (108) |
| Insight |
| Front Damper Pinch Bolts | 72 (98) |
| Tie Rod Lock Nuts | 31 (41) |
| Wheel Lug Nuts | 80 (108) |
| Odyssey |
| Front Damper Pinch Bolts | 116 (157) |
| Rear Toe Adjusting Bolt Lock Nut | 61 (83) |
| Tie Rod Lock Nut | 33 (45) |
| Wheel Lug Nuts | 80 (108) |
| Prelude |
| Except ATTS |
| Radius Rod Lock Nut | 40 (54) |
| Radius Rod Flange Bolts | 80 (108) |
| ATTS |
| Radius Rod Flange Nut | 27 (37) |
| Radius Rod Flange Bolt | 47 (64) |
| Rear Toe Adjusting Bolt Lock Nut | 40 (54) |
| Tie Rod Lock Nut | 33 (45) |
| Wheel Lug Nuts | 80 (108) |
| S2000 |
| Rear Control Arm Adjusting Bolt Lock Nuts (Upper) | 40 (54) |
| Rear Control Arm Adjusting Bolt Lock Nuts (Lower) | 54 (74) |
| Tie Rod Lock Nut | 33 (44) |
| Wheel Lug Nuts | 80 (108) |
| Application | Preferred | Range |
|---|
| Accord |
| Camber (1) |
| Front | 0 | 1 To 1 |
| Rear | .5 | 1.5 To 0.5 |
| Caster (1) | 2.8 | 1.8 To 3.8 |
| Toe-In (2) |
| Front | 0 (0) | .08 To .08 (- 2.0 To 2.0) |
| Rear | .08 (2.0) | 0 To 0.16 (0 To 4.0) |
| Toe-Out On Turns (1) |
| Inner | 38.53 | 37.53 To 39.53 |
| Outer | 31.05 | 30.05 To 32.05 |
| Civic |
| Camber (1) |
| Front | 0 | .75 To .75 |
| Rear | .75 | 1.5 To 0.0 |
| Caster (1) | 1.55 | .55 To 2.55 |
| Toe-In (2) |
| Front | 0 (0) | .12 To .12 (-3.0 To 3.0) |
| Rear | .08 (2.0) | .04 To .16 (1.0 To 4.0) |
| Toe-Out On Turns (1) |
| Inner | 40.00 | — |
| Outer | 33.00 | — |
| CR-V |
| Camber (1) |
| Front | 0 | 1 To 1 |
| Rear | 1 | 2 To 0 |
| Caster (1) | 2.17 | 1.17 To 3.17 |
| Toe-In (2) |
| Front | 0 (0) | .12 To .12 (- 3.0 To 3.0) |
| Rear | .08 (2.0) | .04 To .16 (1.0 To 4.0) |
| Toe-Out Turns (1) |
| Inner | 37.00 | — |
| Outer | 31.50 | — |
| Insight |
| Camber (1) |
| Front | 0 | 1 To 1 |
| Rear | 1 | 2 To 0 |
| Caster (1) | 2 | 1 To 3 |
| Toe-In (2) |
| Front | 0 (0) | .08 To .08 (-2.0 To 2.0) |
| Rear | .12 (3) | .00 To .24 (0.0 To 6.0) |
| Toe-Out On Turns (1) |
| Inner | 40.00 | 38.00 To 42.00 |
| Outer | 33.00 | — |
| Odyssey |
| Camber (1) |
| Front | 0 | 1 To 1 |
| Rear | .50 | 1.25 To .25 |
| Caster (1) | 2.1 | 1.1 To 3.1 |
| Toe-In (2) |
| Front | 0 (0) | .08 To .08 (- 2.0 To 2.0) |
| Rear | 0 (0) | .08 To .08 (- 2.0 To 2.0) |
| Toe-Out On Turns (1) |
| Inner | 41.77 | 39.77 To 43.77 |
| Outer | 33.47 | — |
| Prelude |
| Camber (1) |
| Front | 0 | 1.0 To 1.0 |
| Rear | .75 | 1.75 To .25 |
| Caster (1) |
| With ATTS (3) | 4.33 | 3.58 To 5.08 |
| Without ATTS (3) | 2.40 | 1.40 To 3.40 |
| Toe-In (2) |
| Front | 0 (0) | .08 To .08 (- 2.0 To 2.0) |
| Rear | .08 (2.0) | 0 To .16 (.0 To 4.0) |
| Toe-Out On Turns (1) |
| Inner |
| With ATTS (3) | 34.50 | — |
| Without ATTS (3) | 36.20 | — |
| Outer |
| With ATTS (3) | 28.50 | — |
| Without ATTS (3) | 29.40 | — |
| S2000 |
| Camber (1) |
| Front | .5 | .7 To -.3 |
| Rear | 1.5 | 1.3 To 1.7 |
| Caster (1) | 6 | 5.75 To 6.25 |
| Toe-In (2) |
| Front | 0 (0) | .08 To .08 (- 2.0 To 2.0) |
| Rear | .25 (6.0) | .17 To 1.05 (4.0 To 8.0) |
| Toe-Out On Turns (1) |
| Inner | 34.00 | — |
| Outer | 29.00 | — |
| (1) Measurement in degrees. (2) Measurement in inches (mm). (3) Active Torque Transfer System (ATTS). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
| (3) | Active Torque Transfer System (ATTS). |
WHEEL ALIGNMENT SPECIFICATIONS
