Automatic Transmission Servicing (Except Cvt): Adjustments Honda Civic VII

Automatic Trans 5 illustrations ~380 words

ADJUSTMENTS

WARNINGAll models are equipped with a Supplemental Inflatable Restraint (SIR) system (SRS). When servicing vehicle, use care to avoid accidental air bag deployment. SIR system-related components are located in various locations throughout interior and exterior of vehicle, depending on application. Do not use electrical test equipment on or near these circuits. If necessary, deactivate SIR system before servicing components. See appropriate AIR BAG RESTRAINT SYSTEMS article in RESTRAINTS.
CAUTIONRadio has a coded theft protection circuit. Before disconnecting battery cables, obtain radio anti-theft code number from customer. After reconnecting power, turn ignition and radio on. When CODE is displayed on radio, enter customer 5-digit code using radio preset buttons to restore radio operation.

Scheme 297

Scheme 297
Scheme 297

Scheme 298

Scheme 298
Scheme 298

Scheme 299

Scheme 299
Scheme 299

Scheme 300

Scheme 300
Scheme 300

Scheme 301

Scheme 301
Scheme 301
  1. Move the shift lever to N.
  2. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(ref-173253-S01895924622005031100000) ).
  3. Remove the nut securing the shift cable end (A), then separate the cable end from the shift lever assembly.
  4. Rotate the socket holder (A) on the shift cable (B) toward the shift lever a quarter turn, then slide the holder out to remove the shift cable from the shift cable bracket base (C). NOTE: Do not remove the shift cable by twisting the shift cable guide (D).
  5. Push the shift cable until it stops, then release it. Pull the shift cable back two steps so that the shift position is in N.
  6. Turn the ignition switch ON (II), and verify that the N position indicator comes on.
  7. Turn the ignition switch to OFF.
  8. Insert a 6.0 mm (0.24 in.) pin (A) through the positioning hole (B) on the shift lever bracket base and into the positioning hole (C) on the shift lever assembly. The shift lever is secured in the N position.
  9. Align the socket holder (A) on the shift cable (B) with the slot in the cable bracket base (C), then slide the holder into the base. Install the shift cable end (D) over the mounting stud (E) by aligning its square hole (F) with the square fitting (G) at the bottom of the stud. Rotate the holder clockwise a quarter turn to secure the shift cable. NOTE: Do not install the shift cable by twisting the shift cable guide (H).
  10. Verify that the shift cable end (A) is properly installed on the mounting stud (B).
  11. If improperly installed, remove the shift cable from the shift cable bracket base, and reinstall the shift cable. Do not install the shift cable end on the mounting stud while the shift cable is on the shift cable bracket base.
  12. Install and tighten the nut.
  13. Remove the 6.0 mm (0.24 in.) pin that was installed to hold the shift lever.
  14. Move the shift lever to each position, and verify that the A/T gear position indicator follows the transmission range switch.
  15. Push the shift lock release, and verify that the shift lever releases.
  16. Install the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(ref-173253-S01895924622005031100000) ).
