Starting circuit, a/t for Honda Civic VI (1995-2002)
Starting circuit, a/t
A/T GEAR POSITION SWITCH (BELOW CENTER CONSOLE)
BATTERY
BATTERY FUSE 41
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/WHT(OR BLK/YEL) WIRE
BLK/YEL WIRE
BLU WIRE
CANADA: EX, SI USA: LX, EX, HX,
ELECTRICAL LOAD DETECTOR (ELD) UNIT
ENGINE CONTROLS SYSTEM
HD IN
IG 1 FUSE 42 USA ONLY
IGNITION SWITCH
INTEGRATED CONTROL UNIT
LOCK (0)
ON (II) (I)
RED WIRE
SECURITY CONTROL UNIT (BEHIND RADIO) STR CUT OUT
SECURITY STARTER CUT RELAY (BEHIND LEFT SIDE OF DASH, TAPED TO HARNESS)
STARTER
STARTER MOTOR
STARTER SOLENOID PL IN
UNDER- DASH FUSE/ RELAY BOX (BEHIND LEFT SIDE OF DASH) STARTER SIGNAL FUSE 31
UNDERHOOD ABS FUSE/ RELAY BOX
UNDERHOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPT)
W/ ANTI- THEFT
W/O ANTI- THEFT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
