Headlight circuit, without drl for Honda Civic VI (1995-2002)
Headlight circuit, without drl
BLK WIRE
BLU/RED WIRE
COMBINATION LIGHT SWITCH
FLASH- TO- PASS SWITCH OFF ON
FOG LIGHT ON INDICATOR
FOGLIGHT IN-LINE FUSE (BEHIND LEFT SIDE OF DASH PANEL)
FOGLIGHT RELAY (BEHIND LEFT SIDE OF DASH, TAPED TO HARNESS)
FOGLIGHT SWITCH
GAUGE ASSEMBLY
HEAD
HEADLIGHT FUSE 48
HEADLIGHT SWITCH
HI DIMMER SWITCH
HIGH BEAM INDICATOR
HOT AT ALL TIMES
J/C
L H/L HI BEAM FUSE 5
L H/L LO BEAM FUSE 22
LEFT HEADLIGHT
OFF
OFF ON
PARK
R H/L HI BEAM FUSE 4
R H/L LO BEAM FUSE 21
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FOGLIGHT
RIGHT HEADLIGHT HIGH LEFT FOGLIGHT
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPARTMENT)
WHT WIRE
YEL WIRE
