Exterior light circuit, hatchback for Honda Civic VI (1995-2002)

2 1 (1996-97) (1998-00) 2 1 (1998-00) (1996-97) ANTI-THEFT SYSTEM BLK WIRE BRAKE SWITCH (ON BRAKE PEDAL SUPPORT) COMBINATION LIGHT SWITCH FUSE 32 LICENSE LIGHTS TAIL LIGHTS FUSE 48 HEADLIGHT FUSE 52 HORN, STOP LT GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HEADLIGHT SWITCH HEAD OFF PARK HIGH MOUNT BRAKE LIGHT HOT AT ALL TIMES KEYLESS DOOR LOCK CONTROL UNIT LEFT BRAKE LIGHT/ TAILLIGHT LEFT FRONT PARKING/TURN SIGNAL LIGHT LEFT LICENSE PLATE LIGHT LEFT REAR TURN SIGNAL LIGHT LEFT TAILLIGHT RED GRN/ WIRE RED/ BLK WIRE RED/BLK WIRE RED/GRN WIRE RIGHT BRAKE LIGHT/ TAILLIGHT RIGHT FRONT PARKING/TURN SIGNAL LIGHT RIGHT LICENSE PLATE LIGHT RIGHT REAR TURN SIGNAL LIGHT RIGHT TAILLIGHT TO HAZARD WARNING SWITCH (DIAGRAM 2 OF 2) TO TURN SIGNAL SWITCH (DIAGRAM 2 OF 2) UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH) UNDERHOOD FUSE/RELAY BOX (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT) W/ CRUISE CONTROL W/O CRUISE CONTROL W/ KEYLESS ENTRY (1999, 2000) W/O CRUISE CONTROL W/ CRUISE CONTROL WHT WIRE WHT/GRN WIRE

BLK WIRE COMBINATION LIGHT SWITCH FROM UNDERDASH FUSE/RELAY BOX (DIAGRAM 1 OF 2) FUSE 12 TURN LIGHTS FUSE 53 HAZARD GAUGE ASSEMBLY GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND HAZARD WARNING SWITCH HAZARD WARNING SWITCH LIGHT HOT AT ALL TIMES HOT IN ON OR START IGNITION J/C LEFT LEFT TURN SIGNAL INDICATOR OFF RED WIRE RED/BLK WIRE RELAY OUT RIGHT RIGHT TURN SIGNAL INDICATOR TURN SIGNAL SWITCH TURN SIGNAL/ HAZARD RELAY UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH) UNDERHOOD FUSE/RELAY BOX (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT) WHT/BLK WIRE YEL/BLK WIRE
