Exterior light circuit, coupe & sedan for Honda Civic VI (1995-2002)

ANTI-THEFT SYSTEM BLK WIRE BRAKE SWITCH (ON BRAKE PEDAL SUPPORT) COMBINATION LIGHT SWITCH FUSE 32 LICENSE LIGHTS TAIL LIGHTS FUSE 48 HEADLIGHT FUSE 52 HORN, STOP LT GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HEADLIGHT SWITCH HEAD OFF PARK HIGH MOUNT BRAKE LIGHT HIGH MOUNT BRAKE LIGHT HOT AT ALL TIMES KEYLESS DOOR LOCK CONTROL UNIT LEFT FRONT PARKING/TURN SIGNAL LIGHT LEFT INNER BRAKE LIGHT/ TAILLIGHT (1996-98 SEDAN) (ALL COUPE) LEFT INNER TAILLIGHT (1999, 2000) LEFT LICENSE PLATE LIGHT LEFT OUTER BRAKE LIGHT/ TAILLIGHT LEFT REAR TURN SIGNAL LIGHT RED/BLK WIRE RED/GRN WIRE RIGHT FRONT PARKING/TURN SIGNAL LIGHT RIGHT INNER TAILLIGHT (1999, 2000) RIGHT LICENSE PLATE LIGHT RIGHT OUTER BRAKE LIGHT/ TAILLIGHT RIGHT REAR TURN SIGNAL LIGHT TO HAZARD WARNING SWITCH (DIAGRAM 2 OF 2) TO TURN SIGNAL SWITCH (DIAGRAM 2 OF 2) UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH) UNDERHOOD FUSE/RELAY BOX (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT) W/ CRUISE CONTROL W/O CRUISE CONTROL W/ KEYLESS ENTRY (1999, 2000) W/ SPOILER W/O SPOILER W/O CRUISE CONTROL W/ CRUISE CONTROL WHT GRN/ WIRE WHT WIRE WHT/GRN WIRE

BLK WIRE COMBINATION LIGHT SWITCH FROM UNDERDASH FUSE/RELAY BOX (DIAGRAM 1 OF 2) FUSE 12 TURN LIGHTS FUSE 53 HAZARD GAUGE ASSEMBLY GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND HAZARD WARNING SWITCH HAZARD WARNING SWITCH LAMP HOT AT ALL TIMES HOT IN ON IGNITION J/C LEFT LEFT TURN SIGNAL INDICATOR OFF RED WIRE RED/BLK WIRE RELAY OUT RIGHT RIGHT TURN SIGNAL INDICATOR TURN SIGNAL SWITCH TURN SIGNAL/ HAZARD RELAY UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH) UNDERHOOD FUSE/RELAY BOX (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT) WHT/BLK WIRE YEL/BLK WIRE
