Integrated control unit circuit for Honda Civic VI (1995-2002)
Integrated control unit circuit
ALTERNATOR SP SENSOR FUSE 15
BATTERY INPUT
BLK WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE BULB CHECK OUTPUT
DOOR OPEN INPUT
DRIVER'S DOOR SWITCH INPUT
DRIVER'S SEAT BELT SW IN
FR WIPER FR WASHER FUSE 26
FRONT WIPER/ WASHER
GRN WIRE
GRN/RED WIRE
GROUND
HOT AT ALL TIMES INTERIOR LIGHT FUSE 43
HOT IN ON OR
HOT WITH ENGINE CRANKING
HOT WITH HEADLIGHT SWITCH IN PARK OR HEAD
IGNITION INPUT
INSTRUMENT CLUSTER SYSTEM (BRAKE INDICATOR LIGHT)
INSTRUMENT LIGHTS FUSE 30
INTEGRATED CONTROL UNIT (REAR OF UNDERDASH FUSE/RELAY BOX)
KEY IN IGNITION INPUT
LIGHTS ON IN
LT GRN/RED WIRE
METER FUSE 25
RED/BLU WIRE
START INPUT
STARTER SIGNAL FUSE 31
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPT)
WARNING SYSTEMS
WHT/BLK WIRE
WHT/RED WIRE
WIPER/WASHER SYSTEM
YEL/BLU WIRE
