Honda Civic VI (1995-2002) Manual a/c circuit

A/C ON INDICATOR A/C SWITCH ON AIR MIX POTENTIAL INPUT AIR MIXTURE CONTROL MOTOR (BELOW RIGHT SIDE OF CENTER CONSOLE) BLK WIRE BLK/YEL WIRE BLOWER MOTOR (BELOW RIGHT SIDE OF DASH) BLOWER MOTOR HIGH RELAY (BELOW RIGHT SIDE OF DASH) BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE DEFOGGER SYSTEM FRESH GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE HEATER CONTROL PANEL HEATER PUSH SWITCHES HOT IN ON FUSE 17 HEATER A/C RLY JUNCTION JUNCTION CONNECTOR LT GRN WIRE LT GRN/BLK WIRE MODE CONTROL MOTOR (BEHIND LEFT SIDE OF FRONT CONSOLE) ORG/ WIRE ORG/WHT WIRE PNK/BLK WIRE POWER TRANSISTOR PPL RECIRC FRESH/ RECIRC SWITCH RECIRC ON LED RECIRCULATION CONTROL MOTOR (BEHIND GLOVE BOX) RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE SWITCH LED COMMON UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH) WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE

1600 CC W/ M/T ALL EXCEPT 1600 CC W/ M/T A/C COMPRESSOR CLUTCH A/C DIODE A/C THERMOSTAT (BEHIND GLOVE BOX, ON PLENUM) ACS BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLOWER MOTOR RELAY BLU WIRE BLU/ BLK WIRE BLU/RED WIRE BLU/WHT WIRE CONDENSER FAN MOTOR (BEHIND CONDENSER) CONDENSER FAN RELAY ENGINE COOLANT TEMPERATURE SWITCH (ON RIGHT SIDE OF ENGINE, ON THERMOSTAT COVER) FAN C FUSE 56 COND FAN FUSE 47 BACK UP FUSE 57 COOL FAN FUSE 55 HEATER MOTOR GRN WIRE HOT AT ALL TIMES JUNCTION NCA WIRE POWERTRAIN OR ENGINE CONTROL MODULE (PCM OR ECM) (BEHIND RIGHT KICK PANEL) RADIATOR FAN MOTOR (BEHIND RADIATOR) RADIATOR FAN RELAY RED WIRE THERMISTOR WHT WIRE WHT/BLU WIRE
