Honda Civic VI (1995-2002) underhood abs fuse/ relay box Wiring diagrams
This page contains all the electrical diagrams for the component. underhood abs fuse/ relay box, in which he is found in the car Honda Civic VI (1995-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram underhood abs fuse/ relay box (1 of 2)
A/T GEAR POSITION SWITCH (BELOW CENTER CONSOLE)
BATTERY
BATTERY FUSE 41
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/WHT(OR BLK/YEL) WIRE
BLK/YEL WIRE
BLU WIRE
CANADA: EX, SI USA: LX, EX, HX,
ELECTRICAL LOAD DETECTOR (ELD) UNIT
ENGINE CONTROLS SYSTEM
HD IN
IG 1 FUSE 42 USA ONLY
IGNITION SWITCH
INTEGRATED CONTROL UNIT
LOCK (0)
ON (II) (I)
RED WIRE
SECURITY CONTROL UNIT (BEHIND RADIO) STR CUT OUT
SECURITY STARTER CUT RELAY (BEHIND LEFT SIDE OF DASH, TAPED TO HARNESS)
STARTER
STARTER MOTOR
STARTER SOLENOID PL IN
UNDER- DASH FUSE/ RELAY BOX (BEHIND LEFT SIDE OF DASH) STARTER SIGNAL FUSE 31
UNDERHOOD ABS FUSE/ RELAY BOX
UNDERHOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPT)
W/ ANTI- THEFT
W/O ANTI- THEFT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Starting circuit, a/t -> UNDERHOOD ABS FUSE/ RELAY BOX
Wiring diagram underhood abs fuse/ relay box (2 of 2)
BATTERY
BATTERY FUSE 41
BLK WIRE
BLK/WHT (OR BLK/YEL) WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
CLUTCH INTERLOCK SWITCH (ON CLUTCH PEDAL SUPPORT)
ELECTRICAL LOAD DETECTOR (ELD) UNIT
ENGINE CONTROLS SYSTEM
HD IN
IG 1 FUSE 42 USA ONLY
IGNITION SWITCH
INTEGRATED CONTROL UNIT
LOCK (0)
ON (II) (I)
PL IN
RED WIRE
SECURITY CONTROL UNIT (BEHIND RADIO) STR CUT OUT
SECURITY STARTER CUT RELAY (BEHIND LEFT SIDE OF DASH, TAPED TO HARNESS)
STARTER
STARTER CUT RELAY (BEHIND LEFT SIDE OF DASH, ON BRACKET)
STARTER MOTOR
STARTER SOLENOID
UNDER- DASH FUSE/ RELAY BOX (UNDER LEFT SIDE OF DASH) STARTER SIGNAL FUSE 31
UNDERHOOD ABS FUSE/ RELAY BOX
UNDERHOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPT)
USA: LX, EX, HX, DXV, SI CANADA: EX, SI
W/ ANTI- THEFT
W/O ANTI- THEFT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Starting circuit, m/t -> UNDERHOOD ABS FUSE/ RELAY BOX
