Honda Civic VI (1995-2002) lock input key switch input ignition input unlck/lck output lights flash cntl Wiring diagram
This page shows the only wiring diagram for the component.lock input key switch input ignition input unlck/lck output lights flash cntl, which is found in the car Honda Civic VI (1995-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lock input key switch input ignition input unlck/lck output lights flash cntl (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
DRIVER'S DOOR LOCK ACTUATOR
DRIVER'S DOOR LOCK SWITCH
DRIVER'S DOOR SWITCH
FRONT PASSENGER'S DOOR LOCK ACTUATOR
FRONT PASSENGER'S DOOR SWITCH
FUSE 14 CRUISE CONTROL (KEYLESS)
FUSE 51 DOOR LOCK UNIT, ROOF
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GROUND BATTERY INPUT
GRY WIRE
HEADLIGHT SYSTEM
HORN CONTROL
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION KEY SWITCH
INTEGRATED CONTROL UNIT
KEYLESS DOOR LOCK CONTROL UNIT (BEHIND LEFT KICK PANEL)
LEFT REAR DOOR LOCK ACTUATOR (SEDAN)
LEFT REAR DOOR SWITCH (SEDAN)
LOCK
LOCK INPUT KEY SWITCH INPUT IGNITION INPUT UNLCK/LCK OUTPUT LIGHTS FLASH CNTL
LT GRN/BLK WIRE
LT GRN/RED WIRE
ORG/ WIRE
RED/BLK WIRE
RIGHT REAR DOOR LOCK ACTUATOR (SEDAN)
RIGHT REAR DOOR SWITCH (SEDAN)
STEERING LOCK
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT)
UNLCK/LCK OUTPUT UNLOCK INPUT LOCK INPUT
UNLOCK
WARNING SYSTEM
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Power door lock circuit, with keyless entry -> LOCK INPUT KEY SWITCH INPUT IGNITION INPUT UNLCK/LCK OUTPUT LIGHTS FLASH CNTL
