Honda Civic VI (1995-2002) left right Wiring diagrams
This page contains all the electrical diagrams for the component. left right, in which he is found in the car Honda Civic VI (1995-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left right (1 of 2)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
DEFOGGER
DEFOGGER SYSTEM
DOWN
FUSE 16 RR DEF RELAY
GRN WIRE
GRY WIRE
HOT IN ON
LEFT
LEFT RIGHT
LEFT/RIGHT
LT GRN WIRE
MIRROR SELECTOR SWITCH
ORG/ WIRE
PNK WIRE
POWER MIRROR SWITCH
RED WIRE
RIGHT
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UP/DOWN LEFT MIRROR
UP/DOWN RIGHT MIRROR
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit, with defogger -> LEFT RIGHT
Wiring diagram left right (2 of 2)
1999-00
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
FUSE 16 RR DEF RELAY
FUSE 17 HEATER A/C RELAY
GRN WIRE
GRY WIRE
HOT IN ON
LEFT MIRROR
LEFT RIGHT
LEFT/RIGHT
LT GRN WIRE
MIRROR SELECTOR SWITCH
ORG/ WIRE
PNK WIRE
POWER MIRROR SWITCH
RED WIRE
RIGHT LEFT
RIGHT MIRROR
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UP DOWN
UP/DOWN
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit, without defogger -> LEFT RIGHT
