Honda Civic VI (1995-2002) led control dash lights dash lights switch common wiring diagram
This page shows the only wiring diagram for the component.led control dash lights dash lights switch common, which is found in the car Honda Civic VI (1995-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
led control dash lights dash lights switch common wiring diagram (1 of 1)
AIR MIX POTENTIAL INPUT
AIR MIXTURE CONTROL MOTOR (BELOW RIGHT SIDE OF CENTER CONSOLE)
BLK WIRE
BLK/YEL WIRE
BLOWER MOTOR (BELOW RIGHT SIDE OF DASH)
BLOWER MOTOR HIGH RELAY (BELOW RIGHT SIDE OF DASH)
BLOWER MOTOR RELAY
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
DEFOGGER SYSTEM INTERIOR LIGHTS SYSTEM
FRESH
FUSE 47 BACK UP
FUSE 55 HEATER MOTOR
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HEATER CONTROL PANEL
HEATER PUSH SWITCHES
HOT AT ALL TIMES
HOT IN ON FUSE 17 HEATER A/C RLY
JUNCTION CONNECTOR
LED CONTROL DASH LIGHTS DASH LIGHTS SWITCH COMMON
LT GRN WIRE
LT GRN/BLK WIRE
MODE CONTROL MOTOR (BEHIND LEFT SIDE OF FRONT CONSOLE)
ORG/ WIRE
ORG/WHT WIRE
PNK/BLK WIRE
POWER TRANSISTOR (BEHIND GLOVE BOX)
PPL
RECIRC
RECIRC LED CONTROL
RECIRC ON LED FRESH/ RECIRC SWITCH
RECIRC SWITCH INPUT SWITCH INPUT
RECIRCULATION CONTROL MOTOR (BEHIND GLOVE BOX)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
SENSOR GROUND BLWR MOT HIGH RLY CTRL
SWITCH LED COMMON
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPARTMENT)
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
