Honda Civic VI (1995-2002) indicator light control wiring diagram
This page shows the only wiring diagram for the component.indicator light control, which is found in the car Honda Civic VI (1995-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
indicator light control wiring diagram (1 of 1)
1.6L SOHC, 1.6L SOHC VETEC W/ A/T
A/T GEAR POSITION SWITCH (BELOW CENTER CONSOLE, RIGHT SIDE OF GEAR SELECTOR)
ACTUATOR CTRL
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRAKE SWITCH (ON BRAKE PEDAL SUPPORT)
BRAKE SWITCH INPUT
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
CABLE REEL (TOP OF STEERING COLUMN)
CLUTCH SWITCH (ON CLUTCH PEDAL SUPPORT)
CRUISE CONTROL ACTUATOR (ON LEFT SIDE OF ENGINE COMPARTMENT)
CRUISE CONTROL INDICATOR LIGHT
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL MAIN SWITCH LIGHT
CRUISE CONTROL SET/ RESUME SWITCH
CRUISE CONTROL UNIT (BEHIND LEFT SIDE OF DASH)
CRUISE CTRL SIGNAL INPUT
CRUISE CTRL SIGNAL OUT
DIMMING CIRCUIT
FUSE 14 CRUISE CONTROL (KEYLESS)
FUSE 25 METER
FUSE 52 HORN, STOP LT
GAUGE ASSEMBLY
GRN WIRE
GRN/WHT WIRE
GROUND
GRY WIRE
HORN RELAY (BEHIND LEFT SIDE OF DASH, ON BRACKET)
HORNS
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
INDICATOR LIGHT CONTROL
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
OFF ON
ON INDICATOR
PNK A/T WIRE
PNK DISENGAGE INPUT WIRE
PNK M/T WIRE
PNK WIRE
POWER INPUT
POWERTRAIN CONTROL MODULE (PCM) (BEHIND RIGHT KICK PANEL)
RED WIRE
RED/BLU WIRE
RESUME/ ACCEL SIG INPUT
RESUME/ ACCEL SWITCH
SAFETY SOLENOID
SET/ DECEL SWITCH
SET/DECEL SIG INPUT
STEERING WHEEL)
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT)
VACUUM SOLENOID
VEHICLE SPEED INPUT
VEHICLE SPEED OUTPUT (RIGHT KICK PANEL)
VENT SOLENOID
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit -> INDICATOR LIGHT CONTROL
