Honda Civic VI (1995-2002) except 1.6l sohc vtec-e w/ m/t 1.6l sohc vtec-e w/ m/t Wiring diagram
This page shows the only wiring diagram for the component.except 1.6l sohc vtec-e w/ m/t 1.6l sohc vtec-e w/ m/t, which is found in the car Honda Civic VI (1995-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram except 1.6l sohc vtec-e w/ m/t 1.6l sohc vtec-e w/ m/t (1 of 1)
A/C DIODE
A/C PRESSURE SWITCH (ON A/C REFRIGERANT LINE)
A/C THERMOSTAT (BEHIND GLOVE BOX)
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
COND FAN FUSE 56
CONDENSER FAN MOTOR
CONDENSER FAN RELAY
COOL FAN FUSE 57
ENGINE COOLANT TEMPERATURE SWITCH (RIGHT REAR OF ENGINE)
EXCEPT 1.6L SOHC VTEC-E W/ M/T 1.6L SOHC VTEC-E W/ M/T
FANC
GRN WIRE
HOT AT ALL TIMES
HOT IN ON HTR, A/C RLY FUSE 17
J/C
POWERTRAIN OR ENGINE CONTROL MODULE (BEHIND RIGHT KICK PANEL)
RADIATOR FAN MOTOR
RADIATOR FAN RELAY
UNDER- DASH FUSE/ RELAY BOX
UNDERHOOD FUSE/RELAY BOX
USA
WHT WIRE
