Honda Civic VI (1995-2002) door open input Wiring diagrams
This page contains all the electrical diagrams for the component. door open input, in which he is found in the car Honda Civic VI (1995-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram door open input (1 of 2)
1996-98 SEDAN W/O MOONROOF
1996-98 USA: CX, DX, CANADA
1996-98 USA: LX, EX,, HX
1998 GX
1999-00
ANTI-THEFT SYSTEM (OPTIONAL)
BLK WIRE
BLU/BLK WIRE
CEILING LIGHT
COUPE, SEDAN
DOOR LOCKS SYSTEM
DOOR ON
DOOR OPEN INPUT
DRIVER'S DOOR SWITCH
EXCEPT 1996-98 SEDAN W/O MOONROOF
GRN WIRE
HATCHBACK
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
INTEGRATED CONTROL UNIT
INTERIOR LIGHTS FUSE 43
KEYLESS DOOR LOCK CONTROL UNIT DOOR OPEN OUTPUT
LEFT REAR DOOR SWITCH (SEDAN)
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
NOT USED
OFF
PASS- ENGER'S DOOR SWITCH
RED WIRE
RIGHT REAR DOOR SWITCH (SEDAN)
SEDAN
SPOTLIGHTS
STEREO RADIO TUNER KEYLESS RECEIVER UNIT DOOR OPEN OUTPUT
TRUNK LATCH SWITCH
TRUNK LIGHT
UNDERDASH FUSE/RELAY BOX
W/ SPOTLIGHTS
WHT/RED WIRE
Go to component -> Courtesy lamps circuit -> DOOR OPEN INPUT
Wiring diagram door open input (2 of 2)
ALTERNATOR SP SENSOR FUSE 15
BATTERY INPUT
BLK WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE BULB CHECK OUTPUT
DOOR OPEN INPUT
DRIVER'S DOOR SWITCH INPUT
DRIVER'S SEAT BELT SW IN
FR WIPER FR WASHER FUSE 26
FRONT WIPER/ WASHER
GRN WIRE
GRN/RED WIRE
GROUND
HOT AT ALL TIMES INTERIOR LIGHT FUSE 43
HOT IN ON OR
HOT WITH ENGINE CRANKING
HOT WITH HEADLIGHT SWITCH IN PARK OR HEAD
IGNITION INPUT
INSTRUMENT CLUSTER SYSTEM (BRAKE INDICATOR LIGHT)
INSTRUMENT LIGHTS FUSE 30
INTEGRATED CONTROL UNIT (REAR OF UNDERDASH FUSE/RELAY BOX)
KEY IN IGNITION INPUT
LIGHTS ON IN
LT GRN/RED WIRE
METER FUSE 25
RED/BLU WIRE
START INPUT
STARTER SIGNAL FUSE 31
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPT)
WARNING SYSTEMS
WHT/BLK WIRE
WHT/RED WIRE
WIPER/WASHER SYSTEM
YEL/BLU WIRE
Go to component -> Integrated control unit circuit -> DOOR OPEN INPUT
