Honda Civic VI (1995-2002) alternator sp sensor fuse 15 Wiring diagrams
This page contains all the electrical diagrams for the component. alternator sp sensor fuse 15, in which he is found in the car Honda Civic VI (1995-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
alternator sp sensor fuse 15 wiring diagram (1 of 2)
3 3 (CANADA) (USA) 2 1
ALTERNATOR
ALTERNATOR SP SENSOR FUSE 15
BATTERY
BATTERY FUSE 41
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
CHARGING SYSTEM INDICATOR
ELD IN- PUT ALT OUTPUT SIG ALT FR SIG
ELECTRICAL LOAD DETECTOR (ELD) UNIT (USA ONLY)
ENGINE/POWERTRAIN CONTROL MODULE (ECM/PCM) (BEHIND RIGHT KICK PANEL)
GAUGE ASSEMBLY
GRN WIRE
GRN/RED WIRE
GROUND
HOT IN ON OR START
IGNITION INPUT
INTEGRATED CONTROL UNIT
LOAD OUTPUT
RED WIRE
STARTER SOLENOID
UNDER- DASH FUSE/ RELAY BOX (BEHIND LEFT SIDE OF DASH)
UNDERHOOD ABS FUSE/RELAY BOX
UNDERHOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPT)
USA ONLY
WHT WIRE
YEL WIRE
Go to component -> Charging circuit -> ALTERNATOR SP SENSOR FUSE 15
alternator sp sensor fuse 15 wiring diagram (2 of 2)
ALTERNATOR SP SENSOR FUSE 15
BATTERY INPUT
BLK WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE BULB CHECK OUTPUT
DOOR OPEN INPUT
DRIVER'S DOOR SWITCH INPUT
DRIVER'S SEAT BELT SW IN
FR WIPER FR WASHER FUSE 26
FRONT WIPER/ WASHER
GRN WIRE
GRN/RED WIRE
GROUND
HOT AT ALL TIMES INTERIOR LIGHT FUSE 43
HOT IN ON OR
HOT WITH ENGINE CRANKING
HOT WITH HEADLIGHT SWITCH IN PARK OR HEAD
IGNITION INPUT
INSTRUMENT CLUSTER SYSTEM (BRAKE INDICATOR LIGHT)
INSTRUMENT LIGHTS FUSE 30
INTEGRATED CONTROL UNIT (REAR OF UNDERDASH FUSE/RELAY BOX)
KEY IN IGNITION INPUT
LIGHTS ON IN
LT GRN/RED WIRE
METER FUSE 25
RED/BLU WIRE
START INPUT
STARTER SIGNAL FUSE 31
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPT)
WARNING SYSTEMS
WHT/BLK WIRE
WHT/RED WIRE
WIPER/WASHER SYSTEM
YEL/BLU WIRE
Go to component -> Integrated control unit circuit -> ALTERNATOR SP SENSOR FUSE 15
