Maintenance Information: Overview Honda Civic V

Fuse & Circuit Breaker Identification

1. 1 - 55 Amp Main Fuse
2. 2 - 10 Amp Right Headlight Low Beam
3. 3 - 10 Amp Left Headlight Low Beam
4. 4 - 10 Amp Right Headlight High Beam, High Beam Indicator Light
5. 5 - 10 Amp Left Headlight High Beam
6. 6 - 10 Amp Regulator, Fuel Pump Cut-Off Relay, Primary Cut-Off Solenoid, Vacuum Holding Solenoid Valve, EGR Control Solenoid Valves, Speed Sensor, Power Valve Control Solenoid Valve, Control Switch Solenoid Valve, Idle Compensation Unit (Manual Only), Idle Compensation Solenoid Valve (Manual Only), Control Unit (1300 5-Speed Only), T/C Solenoid Valve (1300 5-Speed Only), Upshift Indicator (1300 5-Speed Only)
7. 7 - 15 Amp Wiper & Washer Motor
8. 8 - 10 Amp Turn Signal Relay & Lights, Back-Up Lights, Gauges, Warning Lights, Seat Belt Buzzer
9. 9 - 10 Amp Interior Light, Trunk Light, Cigarette Lighter, Clock, Key Buzzer
10. 10 - 15 Amp Brakelights, Horn, Hazard Flasher/Relay
11. 11 - 15 Amp Taillights, Side Marker Lights, Parking & License Lights, Gauge Lights, Ignition Switch Light, Heater Panel Light, A/T Console Light (Automatic Only)
12. 12 - 15 Amp Rear Window Defroster
13. 13 - 15 Amp Heater Motor
14. 14 - 15 Amp Cooling Fan Motor
15. 15 - 10 Amp Radio
16. 16 - 10 Amp Cranking Solenoid Valve, Cranking Leak Solenoid Valve

Scheme 6

1. 1 - 10 Amp Brake Warning System, Charging System
2. 2 - 15 Amp Wipers & Washers, Sun Roof (If Equipped)
3. 3 - 10 Amp Back-Up Lights, Clock & Gauges, Seat Belt Warning, Tachometer & Warning Indicators, Turn Lights (CRX), Upshift Indicator (CRX), 4WD Indicator (If Equipped)
4. 4 - 10 Amp Emission Controls, Radiator Fan, Alternator Control Unit (1984 CRX 1300), Upshift Indicator (1984 CRX 1300), Charge Indicator (1986-87 Civic), Charging System (1986-87 CRX), 4WD Controls (If Equipped)
5. 5 - 10 Amp Headlights
6. 6 - 10 Amp Headlights
7. 7 - 10 Amp Headlights
8. 8 - 10 Amp Headlights
9. 9 - 15 Amp Brakelights & Horn
10. 10 - Blank
11. 11 - 15 Amp Trunk/Hatch Light, Interior Light, Key Warning, Clock & Radio, Cigarette Lighter, Front Marker Lights (1986-87)
12. 12 - 15 Amp Dash & Console Lights, Front Marker Lights (1984-85), Rear Marker Lights, License Light, Park Lights, Taillights, Emission Control Unit (1986-87 Wagon)
13. 13 - 15 Amp Air Conditioner, Radiator Fan
14. 14 - 20 Amp Air Conditioner, Blower & Heater Controls, Rear Window Defogger
15. 15 - 10 Amp Radio
16. 16 - 20 Amp Air Conditioner, Radiator Fan, Sun Roof (1986-87 CRX Si:30 Amp)
17. 17 - 20 Amp Rear Window Defogger
18. 18 - 15 Amp Emission Controls (1986-87 CRX Si Only)
19. 19 - 15 Amp Hatch Release (Civic Wagon)

Scheme 7

1. 1 - 10 Amp Integrated Control Unit, Combination Switch, Gauge Assembly, Back-Up Lights Switch, Shift Position Console Switch, Clock (1990), Shift Lock Solenoid (1990), Interlock Control Unit (1990), Automatic Seat Belts (If Equipped)
2. 2 - 10 Amp Starter Solenoid, PGM-FI Main Relay, PGM-FI Electronic Control Unit, Integrated Control Unit
3. 3 - 20 Amp Power Door Locks (If Equipped)
4. 4 - 10 Amp Right Headlight High Beam, High Beam Indicator Light, Daytime Running Lights Relay (Canada)
5. 5 - 10 Amp Left Headlight High Beam
6. 6 - 30 Amp Sun Roof Motor (If Equipped)
7. 7 - 10 Amp Rear Lights (Canada Only)
8. 8 - 10 Amp Integrated Control Unit, Interior & Exterior Lighting
9. 9 - Blank
10. 10 - 10 Amp Left Headlight Low Beam
11. 11 - 10 Amp Right Headlight Low Beam
12. 12 - 15 Amp Integrated Control Unit, Luggage Compartment Light, Dome Light, Ignition Switch, Clock, Radio, Cigarette Lighter
13. 13 - 15/20 Amp Power Windows, Windshield Wipers & Washer, Sun Roof Relay (1990), Integrated Control Unit (Canada), Combination Switch (1990 CRX)
14. 14 - 10 Amp Gauge Assembly, Engine Sensors & Controls, PGM-FI Main Relay (Wagon & CRX Only), PGM-FI ECU (Wagon & CRX Only), Fuel Pump (Wagon & CRX Only), ELD Unit (Wagon & CRX Only), EACV (Wagon & CRX Only)
15. 15 - 15 Amp Cooling Fan Motor (Except 4WD A/T Wagon), Cooling Fan Relay
16. 16 - 10 Amp Daytime Running Lights (Canada Only)
17. 17 - 10 Amp Radio, Cigarette Lighter Relay (1990 only)
18. 18 - 10 Amp Rear Window Defogger, Power Door Mirrors, Air Conditioning
19. 19 - 30 Amp Blower Motor
20. 20 - 20 Amp Right Front Power Window
21. 21 - 20 Amp Left Front Power Window
22. 22 - 20 Amp Right Rear Power Window
23. 23 - 20 Amp Left Rear Power Window

Scheme 8

1. 1 - 30 Amp Moon Roof
2. 2 - Not Used
3. 3 - 7.5 Amp Integrated Control Unit, Ceiling Light, Trunk/Cargo Light
4. 4 - Not Used (Coupe, 3-Door and del Sol) 20 Amp Right Rear Power Window Motor
5. 5 - 20 Amp Driver's Power Window Motor
6. 6 - 20 Amp Power Door Lock Control Unit
7. 7 - Not Used (Coupe and 3-Door) 20 Amp (Sedan) Left Rear Power Window Motor 20 Amp (del Sol) Rear Power Window
8. 8 - 20 Amp Front Passenger's Power Window Motor
9. 9 - 10 Amp Right Headlight (HIGH)
10. 10 - 10 Amp Left Headlight (HIGH), High Beam, Indicator Light
11. 11 - Not Used (Coupe, 3-Door and Sedan) 10 Amp (del Sol) Auxiliary Light (Foglights)
12. 12 - 15 Amp Alternator (Canada, W/O SRS), PGM-FI, Cruise Control, Gauges (without SRS), ELD Assembly
13. 13 - 7.5 Amp Rear Window Defogger Relay, ABS Motor Relay, Power Mirrors, Air Delivery, Blower Motor Relay, Radiator Fan Relay, Condenser Fan Relay
14. 14 - 20 Amp Windshield Wiper Relay, Moon Roof Relay, Integrated Control Unit, Power Window Relay, Front/Rear Window Washer Motor, Front/Rear Windshield Wiper Motors
15. 15 - 10 Amp Gauge & Warning Lights, Clock, Back-Up Lights Interlock System, Integrated Control Unit
16. 16 - 7.5 Amp Daytime Running Lights (Canada)
17. 17 - 10 Amp Daytime Running Lights (Canada)
18. 18 - 7.5 Amp PGM-FI ECU, ECU Main Relay, Starter Signal
19. 19 - 10 Amp Dash Lights, Taillights, Parking/License/Console Lights
20. 20 - Not Used
21. 21 - 10 Amp Right Headlight (LOW)
22. 22 - 10 Amp Left Headlight (LOW)
23. 23 - 15 Amp Stereo Radio & Cassette Player, Cigarette Lighter
24. 24 - 15 Amp Supplemental Restraint System (SRS) Unit (VB), Alternator, Cruise Control, Gauges (with SRS)
25. 25 - 10 Amp Supplemental Restraint System (SRS) Unit (VA)
26. 26 - 30 Amp Spare Fuse
27. 27 - 15 Amp Spare Fuse
28. 28 - 20 Amp Spare Fuse
29. 29 - 7.5 Amp Spare Fuse
30. 30 - 10 Amp Spare Fuse

Scheme 9

1. 1 - 55 Amp Main Power Distribution & Hazard Fuse
2. 2 - 45 Amp Ignition Switch
3. 3 - 45 Amp Dash Fuse Box, Headlights

Scheme 10

1. 1 - 55 Amp Power Distribution
2. 2 - 45 Amp Power Distribution
3. 3 - 45 Amp Power Distribution

Scheme 11

1. 1 - 60 Amp Power Distribution
2. 2 - 50 Amp Dash Fuse Box
3. 3 - 40 Amp Dash Fuse Box, Exterior Lighting
4. 4 - 10 Amp PGM-FI Electronic Control Unit, Hazard Lights, A/T Control Unit (Wagon), Integrated Control Unit (1990), Automatic Shoulder Belts (1990)
5. 5 - 15 Amp Horns, Brakelights, A/T Control Unit (Wagon Only), Key Interlock Solenoid (A/T Only), Seat Belt Retractors (1990)
6. 6 - 20 Amp Rear Window Defogger
7. 7 - 15 Amp PGM-FI Main Relay
8. 8 - 15 Amp A/C Compressor Clutch, Condenser Fan Relay

Scheme 12

1. 1 - 15 Amp PGM-FI Main Relay
2. 2 - 7.5 Amp PGM-FI ECM, Clock, Radio/Cassette Player
3. 3 - 15 Amp Radiator Fan Relay (Contacts)
4. 4 - 30 Amp Rear Window Defogger Relay (Contacts)
5. 5 - 20 Amp Condenser Fan Motor, A/C Clutch Relay
6. 6 - 50 Amp Option Connector "A", Moon Roof, Power Windows, Power Locks Integrated Control Unit, Ceiling Light, Trunk/Cargo Light
7. 7 - 30 Amp Blower Motor Relay
8. 8 - Not Used
9. 9 - 50 Amp Ignition Switch (BAT)
10. 10 - 40 Amp Combination Light Switch, Daytime Running Lights (Canada)
11. 11 - 80 Amp Power Distribution
12. 12 - 20 Amp Horns, Brakelights, Key Interlock Solenoid
13. 13 - 10 Amp Hazard Warning Light, Turn Signal/Hazard Relay
14. 14 - 50 Amp Not Used
15. 15 - 50 Amp Not Used
16. 16 - 50 Amp Not Used

Scheme 13

Fuse & Relay Identification

1. 1 - 50 Amp ABS Pump Motor
2. 2 - Not Used ABS Clutch (Back Up)
3. 3 - Not Used
4. 4 - 15 Amp ABS Control Unit (+B2)
5. 5 - 20 Amp ABS Control Unit (+B1, +B3)
6. 6 - Not Used ABS Clutch (Monitor)
7. 7 - 7.5 Amp ABS Motor Check
8. 8 - Not Used ABS Clutch (Main)
9. A - ABS Pump Motor Relay
10. B - ABS Rear Fail-Safe Relay
11. C - ABS Front Fail-Safe Relay
