Warning systems — Chime circuit, except hybrid Honda Civic IX
All systems — 33 systems
- Air conditioning 3
- Anti-lock brakes 3
- Anti-theft 4
- Body control modules 2
- Computer data lines 6
- Cooling fan 2
- Cruise control 2
- Defoggers 2
- Electronic power steering 2
- Engine performance 1.5l hybrid 2
- Engine performance 1.8l
- Engine performance 2.4l
- Exterior lights 5
- Ground distribution 2
- Headlights 2
- Horn 2
- Instrument cluster 2
- Interior lights 6
- Navigation 10
- Power distribution 2
- Power door locks 2
- Power mirrors 2
- Power seats
- Power top/sunroof
- Power windows 2
- Radio 5
- Shift interlock 3
- Starting/charging 3
- Supplemental restraints 2
- Transmission 2
- Trunk, tailgate, fuel door 2
- Warning systems 3
- Wiper/washer 2
Components on these wiring diagrams 31
Click a component to highlight it on every diagram it appears on.
