Interior Lights: Overview Honda Civic IX

Interior/illumination Lights 5 illustrations

Scheme 1

Scheme 1: Removal

Scheme 1: Removal

Ceiling Light Turn the ceiling light switch OFF. Carefully pry off the lens (A). Remove the ceiling light (B). Disconnect the connector.

Scheme 2

Scheme 2: Test

Scheme 2: Test

Scheme 3

Scheme 3

Scheme 3

Ceiling Light - Test NOTE: When doing the ceiling light test, make sure to install the bulb correctly. Check for continuity between the terminals in each switch position according to the table. If the continuity is not as specified, replace the bulb or the ceiling light (A).

Scheme 4

Scheme 4: Installation

Scheme 4: Installation

Ceiling Light Connect the connector. Install the ceiling light (A). Carefully install the lens (B).

Scheme 5

Scheme 5: Entry Lights Control System Component Location Index

Scheme 5: Entry Lights Control System Component Location Index

CEILING LIGHT	REMOVAL, TEST, AND INSTALLATION
DRIVER'S DOOR LOCK KNOB SWITCH (Built into the door latch)	2-Door: Test See FRONT DOOR LOCK KNOB SWITCH TEST (2-DOOR)
DRIVER'S DOOR LOCK KNOB SWITCH (Built into the door latch)	4-Door: Test See FRONT DOOR LOCK KNOB SWITCH TEST (4-DOOR) .
FRONT INDIVIDUAL MAP LIGHT	Front Individual Map Light Removal, Installation, and Test
IGNITION KEY LIGHT	TEST
IGNITION KEY SWITCH	TEST
MICU (Built into the under-dash fuse/relay box)	INPUT TEST
MICU (Built into the under-dash fuse/relay box)	UNDER-DASH FUSE/RELAY BOX REMOVAL AND INSTALLATION (KA KX MODELS WITHOUT KEYLESS ACCESS SYSTEM) or UNDER-DASH FUSE/RELAY BOX REMOVAL AND INSTALLATION (KA MODEL WITH KEYLESS ACCESS SYSTEM)
