Shift interlock — Reverse lockout circuit, sedan Honda Civic Type R X
All systems — 41 systems
- Air conditioning 1.5l turbo
- Air conditioning 2.0l
- Air conditioning 2.0l turbo
- Anti-lock brakes 3
- Anti-theft 2
- Body control modules 2
- Computer data lines 3
- Cooling fan 1.5l turbo
- Cooling fan 2.0l
- Cooling fan 2.0l turbo
- Cruise control 1.5l turbo
- Cruise control 2.0l
- Cruise control 2.0l turbo
- Defoggers 3
- Electronic power steering
- Electronic suspension 3
- Engine performance 1.5l turbo 3
- Engine performance 2.0l
- Engine performance 2.0l turbo
- Exterior lights 5
- Ground distribution 3
- Headlights
- Horn
- Instrument cluster 3
- Interior lights 5
- Navigation 11
- Power distribution 3
- Power door locks
- Power mirrors 4
- Power seats 5
- Power top/sunroof
- Power windows
- Radio 7
- Shift interlock 4
- Starting/charging 5
- Supplemental restraints
- Transmission 1.5l turbo
- Transmission 2.0l
- Trunk, tailgate, fuel door 3
- Warning systems 3
- Wiper/washer 2
Components on these wiring diagrams 5
Click a component to highlight it on every diagram it appears on.
