Active Control Engine Mount (Acm) System (V6): Maintenance Honda Accord VIII

Engine Control Systems 2 illustrations ~186 words

ACM Reset

  1. Reset the ACM with the HDS while the engine is stopped.
  2. Turn the ignition switch to LOCK (0).
  3. Turn the ignition switch to ON (II), and wait 30 seconds.
  4. Turn the ignition switch to LOCK (0), and disconnect the HDS from the DLC.

Scheme 53

Scheme 53: How To Troubleshoot Circuits At The Engine Mount Control Unit
Scheme 53: How To Troubleshoot Circuits At The Engine Mount Control Unit

Scheme 54

Scheme 54
Scheme 54
  1. Connect one side of the patch cords terminals (A), to a commercially available digital multimeter (B), and connect the other side of the terminals (C) to a commercially available banana jack (Pomona Electronics Tool No. 3583 or equivalent) (D).
  2. Using the wire insulation as a guide for the contoured tip of the backprobe adapter, gently slide the tip into the connector from the wire suits until it touches the end of the wire terminal.
  3. If you cannot get to the wire side of the connector or the wire side is sealed (A), disconnect the connector, and probe the terminals (B) from the terminal side. Do not force the probe into the connector. NOTE: Do not puncture the insulation on a wire. Punctures can cause poor or intermittent electrical connections.
