Engine Block (Hybrid): Component Locations Honda Accord VII рестайлинг

Crankshaft Bore Code Location

Letters or bars have been stamped on the end of the block as a code for the size of each of the four main journal bores.

Use them, and the numbers stamped on the crankshaft (codes for main journal size), to choose the correct bearings. If the codes are indecipherable because of an accumulation of dirt and dust, do not scrub them with a wire brush or scraper. Clean them only with solvent or detergent.

Scheme 539

Scheme 540

Main Journal Code Locations (Numbers or Bars)

Scheme 541

Scheme 542

1. Remove the connecting rod cap and bearing half (see «CRANKSHAFT AND PISTON REMOVAL»(ref-219787-S11517560602006021500000) ).
2. Clean the crankshaft rod journal and bearing half with a clean shop towel.
3. Place a strip of plastigage across the rod journal.
4. Reinstall the bearing half and cap, and torque the bolts. Tightening Torque: 20 N.m (2.0 kgf.m, 14 lbf.ft)+90 ° Apply new engine oil to the bolt threads. NOTE: Do not rotate the crankshaft during inspection.
5. Remove the rod cap and bearing half and measure the widest part of the plastigage. Connecting Rod Bearing-to-Journal Oil Clearance Standard (New): 0.020-0.044 mm (0.0008-0.0017 in.) Service Limit: 0.050 mm (0.0020 in.)
6. If the plastigage measures too wide or too narrow, remove the upper half of the bearing, then install a new, complete bearing with the same color code, and recheck the clearance. Do not file, shim, or scrape the bearings or the caps to adjust clearance.
7. If the plastigage shows the clearance is still incorrect, try the next larger or smaller bearing (the color listed above or below that one), and check clearance again. If the proper clearance cannot be obtained by using the appropriate larger or smaller bearings, replace the crankshaft and start over.

Connecting Rod Journal Code Locations

Numbers or bars have been stamped on the side of each connecting rod as a code for the size of the big end. Use them, and the letters or bars stamped on the crank (codes for rod journal size), to choose the correct bearings. If the codes are indecipherable because of an accumulation of dirt and dust, do not scrub them with a wire brush or scraper. Clean them only with solvent or detergent.

Scheme 543

Scheme 544

Connecting Rod Journal Code Locations (Letters or Bars)

Scheme 545

Scheme 546

Scheme 547

Scheme 548

1. If the engine is out of the vehicle, go to step 29 .
2. Drain the engine oil (see «ENGINE OIL REPLACEMENT»(ref-219788-S14092701142006021500000) ).
3. Remove the front grille cover (see step 1 on «FRONT GRILLE REPLACEMENT»(ref-219827-S30136135932006021500000) ).
4. Remove the intake manifold cover (see step 11 on «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
5. Disconnect the connectors from the steering gearbox (see step 20 on «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
6. Remove the steering joint cover. Lock the steering wheel. Make a reference mark across the steering joint and steering gearbox pinion shaft. Remove the steering joint bolt, and disconnect the steering joint from the steering gearbox pinion shaft. To prevent damage to the cable reel, do not turn the steering wheel once the steering joint has been removed (see step 27 on «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
7. Raise the vehicle on the hoist to full height.
8. Remove the front wheels.
9. Remove the splash shield (see step 32 on «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
10. Disconnect the stabilizer links (see «STABILIZER LINK REPLACEMENT»(ref-219810-S28885855762006021500000) ).
11. Remove the damper fork (see step 3 on «LOWER ARM REMOVAL/INSTALLATION»(ref-219810-S40055171722006021500000) ).
12. Separate the tie-rod end ball joints from the knuckles (see step 11 on «RACK END REMOVAL AND INSTALLATION»(ref-302090-S22715507222008102100000) ).
13. Separate the knuckles from the lower arms (see step 5 on «LOWER ARM REMOVAL/INSTALLATION»(ref-219810-S40055171722006021500000) ).
14. Remove exhaust pipe A (see step 41 on «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
15. Remove the bolt securing the transmission lower mount (see step 42 on «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
16. Lower the vehicle on the hoist.
17. Remove the connector bracket from the front cylinder head; use the bracket bolt hole to attach engine balancer bar front arm (see step 47 on «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
18. Remove the harness clamp bracket from the rear cylinder head; use the bracket bolt hole to attach engine balancer bar rear arm (see step 48 on «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
19. Lift and support the engine with engine hanger and engine balancer bar. Attach the front arm to the front cylinder head with a spacer and the connector bracket bolt (10 x 1.25 mm). Attach the rear arm to the rear cylinder head with the harness clamp bracket bolt (8 x 1.25 mm) (see step 49 on «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
20. Remove the harness clamp, then disconnect the front active control engine mount actuator connector. Remove the front mount stop, then remove the front mount bolt (see step 51 on «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
21. Disconnect the rear active control engine mount actuator connector. Remove the rear mount stop, then remove the rear mount bolt (see step 53 on «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
22. Remove the harness clamp, then remove the shift cable bracket (see step 54 on «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
23. Raise the vehicle on the hoist to full height.
24. Remove both mid-mounts (see step 56 on «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
25. Make the appropriate reference lines at both ends of the subframe that line up with the edge of the stiffeners (see step 57 on «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
26. Attach the special tool to the subframe by hanging the belt over the front of the subframe, then secure the belt with its stop (see step 58 on «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
27. Raise the jack and line up the slots in the special tool arms with the bolt holes on the jack base, then securely attach them with four bolts.
28. Remove the subframe (see step 60 on «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
29. Remove the rear warm up three way catalytic converter (rear WU-TWC) bracket.
30. Remove the sealing bolts (A) and the four bolts (B) securing the transmission.
31. Remove the bolts securing the oil pan.
32. Using a flat blade screwdriver, separate the oil pan from the block in the places shown.
33. Remove the oil pan.

Scheme 549

Scheme 550

Scheme 551

Scheme 552

Scheme 553

Scheme 554

Scheme 555

Scheme 556

1. Remove the engine assembly (see «ENGINE REMOVAL»(ref-219785-S33445979882006021500000) ).
2. Remove the IMA motor housing (see «MOTOR HOUSING REMOVAL/INSTALLATION»(ref-302084-S14598584502008102100000) ).
3. Remove the cylinder heads (see «CYLINDER HEAD REMOVAL»(ref-219786-S41872074672006021500000) ).
4. Remove the crankshaft position (CKP) sensor (see «CKP SENSOR REPLACEMENT»(ref-302081-S16333845992008102100000) ).
5. Remove the timing belt drive pulley from the crankshaft.
6. Remove the oil pan (see «OIL PAN REMOVAL»(ref-219787-S40827448602006021500000) ).
7. Remove the engine block end cover.
8. Remove the oil filter base/oil filter assembly.
9. Remove the oil screen (A), baffle plate (B), and oil pump (C).
10. If you can feel a ridge of metal or hard carbon around the top of any cylinder, remove it with a ridge reamer (A). Follow the reamer manufacturer's instructions. If the ridge is not removed, it may damage the piston as it's pushed out.
11. Remove the bearing from the cap. Keep all caps/bearings in order.
12. Remove the upper bearing halves from the connecting rods, and set them aside with their respective caps.
13. Remove the connecting rod caps after setting the crank pin at bottom dead center (BDC) for each cylinder. Remove the piston assembly by pushing on the connecting rod. Take care not to damage the oil jets, crank pin, or cylinder with the connecting rod.
14. To avoid confusion during reassembly, mark each piston/connecting rod assembly with its cylinder number.
15. Unscrew the bearing cap bolts and bearing cap side bolts in sequence 1/3 turn at a time; repeat the sequence until all bolts are loosened.
16. Remove the bearing cap bolts (A) and bearing cap side bolts (B), then remove the bearing cap (C).
17. Lift the crankshaft (A) out of the engine block, being careful not to damage the journals.
18. Reinstall the main caps and bearings on the engine block in the proper order.

Scheme 557

1. 1. Remove the crankshaft from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-219787-S11517560602006021500000) ).
2. 2. Clean the crankshaft oil passages with pipe cleaners or a suitable brush.
3. 3. Check the keyway and threads.
4. 4. Measure out-of-round at the middle of each rod and main journal in two places. The difference between measurements on each journal must not be more than the service limit. Journal Out-of-Round Standard (New): 0.005 mm (0.0002 in.) max. Service Limit: 0.010 mm (0.0004 in.)
5. Measure taper at the edges of each rod and main journal. The difference between measurements on each journal must not be more than the service limit. Journal Taper Standard (New): 0.005 mm (0.0002 in.) max. Service Limit: 0.010 mm (0.0004 in.)

Scheme 558

1. 6. Place the engine block on the surface plate.
2. 7. Clean and install the bearings on the No. 1 and No. 4 journal of the engine block.
3. 8. Lower the crankshaft into the block.
4. 9. Measure the runout on all of the main journals. Rotate the crankshaft two complete revolutions. The difference between measurements on each journal must not be more than the service limit. Crankshaft Total Runout Standard (New): 0.025 mm (0.0010 in.) max. Service Limit: 0.030 mm (0.0012 in.)

Scheme 559

Scheme 560

Scheme 561

Scheme 562

1. Remove the piston from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-219787-S11517560602006021500000) ).
2. Check the piston for distortion or cracks.
3. Measure the piston diameter at a point 16.0 mm (0.63 in.) from the bottom of the skirt. Piston Diameter Standard (New): 85.975-85.985 mm (3.3848-3.3852 in.) Service Limit: 85.965 mm (3.3844 in.) Oversize Piston Diameter 0.25: 86.225-86.235 mm (3.3947-3.3951 in.) 0.50: 86.475-86.485 mm (3.4045-3.4049 in.)
4. Measure wear and taper in direction X and Y at three levels in each cylinder as shown. If measurements in any cylinder are beyond the oversize bore service limit, replace the block. If the block has to be rebored, refer to step 7 . after reboring. Cylinder Bore Size Standard (New): 86.000-86.015 mm (3.3858-3.3864 in.) Service Limit: 86.065 mm (3.3884 in.) Oversize 0.25: 86.250-86.265 mm (3.3957-3.3963 in.) 0.50: 86.500-86.515 mm (3.4055-3.4061 in.) Reboring Limit: 0.5 mm (0.02 in.) Bore Taper Limit: (Difference between first and third measurement) 0.05 mm (0.002 in.)
5. Scored or scratched cylinder bores must be honed (see «CYLINDER BORE HONING»(ref-219787-S17723243922006021500000) ).
6. Check the top of the engine block for warpage. Measure along the edges and across the center as shown. Engine Block Warpage Standard (New): 0.07 mm (0.003 in.) max. Service Limit: 0.10 mm (0.004 in.)
7. Calculate the difference between cylinder bore diameter and piston diameter. If the clearance is near or exceeds the service limit, inspect the piston and cylinder bore for excessive wear. Piston-to-Cylinder Bore Clearance Standard (New): 0.015-0.040 mm (0.0006-0.0016 in.) Service Limit: 0.08 mm (0.003 in.)

Scheme 563

1. Measure the cylinder bores (see step 4 on .). If the engine block is to be reused, hone the cylinders and remeasure the bores. Only scored or scratched cylinder bores must be honed.
2. Remove and discard the oil jets (see «OIL JET REPLACEMENT»(ref-219788-S06085805712006021500000) ).
3. Hone the cylinder bores with honing oil and a fine (400 grit) stone in a 60 degree crosshatch pattern. NOTE: Use only a rigid hone with 400 grit or finer stone, such as Sunnen, Ammco, or equivalent. Do not use stones that are worn or broken.
4. When honing is complete, thoroughly clean the engine block of all metal particles. Wash the cylinder bores with hot soapy water, then dry and oil them immediately to prevent rusting. Never use solvent, it will only redistribute the grit on the cylinder walls.
5. If scoring or scratches are still present in the cylinder bores after honing to the service limit, rebore the engine block. Some light vertical scoring and scratching is acceptable if it is not deep enough to catch your fingernail and does not run the full length of the bore.
6. Install the oil jets (see «OIL JET REPLACEMENT»(ref-219788-S06085805712006021500000) ).

Scheme 564

Scheme 565

Scheme 566

1. Remove the piston from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-219787-S11517560602006021500000) ).
2. Apply new engine oil to the piston pin snap rings (A) and turn them in the ring grooves until the end gaps are lined up with the cutouts in the piston pin bores (B). NOTE: Take care not to damage the ring grooves.
3. Remove snap rings (A) from both sides of the piston. Start at the cutout in the piston pin bore. Remove the snap rings carefully so they do not go flying or get lost. Wear eye protection.
4. Heat the piston and connecting rod assembly to about 158°F (70°C), then remove the piston pin.
