A/C SYSTEM SPECIFICATIONS
| WARNING | Vehicle is equipped with Supplemental Inflatable Restraint (SIR) system. When servicing vehicle, use care to avoid accidental air bag deployment. SIR system-related components are located in various locations throughout interior and exterior of vehicle, depending on application. Do not use electrical test equipment on or near these circuits. If necessary, deactivate SIR system before servicing components. See AIR BAG RESTRAINT SYSTEM article in RESTRAINTS. |
| Application | Specification |
|---|
| Compressor Type | Nippondenso 10-Cyl. |
| Compressor Belt Tension | (1) |
| Oil Capacity (2) |
| Compressor | (3) |
| Condenser | .85 ozs. |
| Evaporator | 1.4 ozs. |
| Leakage Repair | .85 ozs. |
| Line Or Hose | .33 ozs. |
| Receiver/Dryer | .33 ozs. |
| Refrigerant (R-134a) Capacity | 21-23 ozs. |
| System Operating Pressures | (4) |
| (1) Belt tension is adjusted by automatic belt tensioner. (2) Use ND-Oil 8 (Part No. 38897-PR7-A01AH or 38899-PR7-A01). (3) To calculate compressor oil capacity (Scheme 1) (4) See A/C SYSTEM PERFORMANCE under TESTING. |
| (1) | Belt tension is adjusted by automatic belt tensioner. |
| (2) | Use ND-Oil 8 (Part No. 38897-PR7-A01AH or 38899-PR7-A01). |
| (3) | To calculate compressor oil capacity (Scheme 1) |
| (4) | See A/C SYSTEM PERFORMANCE under TESTING. |
A/C SYSTEM SPECIFICATIONS
Scheme 1
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor-to-Bracket Bolts | 16 (22) |
| Compressor Bracket-to-Block Bolts | 33 (44) |
| Heater Case Firewall Nuts | 16 (22) |
| High Pressure (Discharge) Hose | 7.2 (9.8) |
| Instrument Panel Bolts | 16 (22) |
| Low Pressure (Suction) Hose to Evaporator | 23 (31) |
| INCH Lbs. (N.m) |
| Heater Unit Nuts | 86 (9.8) |
| Condenser Bolts/Nuts | 86 (9.8) |
| Evaporator Case Bolts/Nuts | 86 (9.8) |
| Low Pressure (Suction) Hose to Compressor | 86 (9.8) |
| Lower Instrument Panel Cover Bolts | 86 (9.8) |
Automatic A/C-Heater System Wiring Diagram (1 Of 2). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2 Of 2). Scheme 3
Scheme 3: Automatic A/C-Heater System Wiring Diagram (2 Of 2)
