Engine Starter Testing & Overhaul - 2.2L Engine: Specifications

Engine Starter Testing & Overhaul - 2.2L Engine: Specifications Honda Accord V

Starter 2 illustrations

STARTER SPECIFICATIONS

Application	Specification
Brush Length (Minimum)	.43" (11.0 mm)
Brush Spring Tension	3.5-4.0 Lbs. (1.6-1.8 kg)
Commutator Diameter (Minimum)	1.08" (27.5 mm)
Commutator Mica Depth (Minimum)	.006" (.15 mm)
Commutator Runout (Maximum)	.002" (.05 mm)

STARTER SPECIFICATIONS (MITSUBA)

Application	Specification
Brush Length (Minimum)	.39" (10.0 mm)
Brush Spring Tension	3.7-5.3 Lbs. (1.7-2.4 kg)
Commutator Diameter (Minimum)	1.14" (29.0 mm)
Commutator Mica Depth (Minimum)	.008" (.20 mm)
Commutator Runout (Maximum)	.002" (.05 mm)

STARTER SPECIFICATIONS (NIPPONDENSO)

Application	Ft. Lbs. (N.m)
Starter Mounting Bolts	33 (45)

TORQUE SPECIFICATIONS

Scheme 1: Starting System Wiring Diagram (A/T)

Scheme 2: Starting System Wiring Diagram (M/T)
