Maintenance Information: Overview Honda Accord V

Fuse & Relay Identification

1. 1 - 10 Amp Radio Motor Antenna, Cigarette Lighter Relay
2. 2 - 7.5 Amp Daytime Running Lights Control Unit (Canada)
3. 3 - 7.5 Amp PGM-FI Main Relay, ECM, Gauge (Brake Check Circuit) Starter Signal
4. 4 - 7.5 Amp Heater Control Relay, A/C Compressor Clutch Relay, Radiator Fan Control Module, Recirculation Control Motor, Heater Control Panel, Rear Window Defogger Indicator Light, Mode Control Motor, A/C Thermostat, Rear Window Defogger Relay, Blower Motor Relay
5. 5 - 7.5 Amp ABS Inspection Connector, ABS Control Unit, ABS Pump Motor Relay, Power Mirror Actuator
6. 6 - 30 Amp Spare Fuse
7. 7 - 7.5 Amp Turn Signal/Hazard Relay
8. 8 - 10 Amp Spare Fuse
9. 9 - 30 Amp Windshield Wiper/Washer, Intermittent Wiper
10. 10 - Not Used (Coupe) 10 Amp (4-Door & Wagon) Power Window Relay
11. 11 - 7.5 Amp Alternator, Transmission Control Module (TCM), ELD Unit Radiator Fan Control Module, Cruise Control System (ECU)
12. 12 - 20 Amp Spare Fuse
13. 13 - 7.5 Amp Spare Fuse
14. 14 - 10 Amp SRS
15. 15 - 15 Amp PGM-FI Main Relay & Fuel Pump, SRS Unit
16. 16 - 10 Amp Back-Up Lights, Gauge & Warning/Indicator Lights, Shift Lever Position Indicator, Shift Lock Solenoid, Safety Indicator, Vehicle Speed Sensor (VSS), Clock Turn Signal Lights/Relay, Integrated Control Unit
17. 17 - 15 Amp Spare Fuse

Scheme 1

Relay Identification

1. A - Cooling Fan
2. B - Headlight Dimmer
3. C - Power Windows
4. D - Head Lights

Fuse & Circuit Breaker Identification

1. 1 - 20 Amp Radiator Fan Motor
2. 2 - 20 Amp Right Headlight
3. 3 - 20 Amp Left Headlight
4. 4 - 10 Amp Daytime Running Lights (Canada)
5. 5 - 50 Amp Ignition Switch
6. 6 - Not Used (Coupe) 20 Amp Right Rear Power Window Motor
7. 7 - 20 Amp Right Front Power Window Motor
8. 8 - 30 Amp Moon Roof
9. 9 - 15 Amp A/C Condenser Fan Motor, A/C Compressor Clutch Relay Cooling Fan Timer Unit
10. 10 - 7.5 Amp Radio (Backup), Clock, ECM, Transmission Control Module
11. 11 - Not Used (Coupe) 20 Amp Left Rear Power Window Motor & Switch
12. 12 - 20 Amp Left Front Power Window Motor & Switch
13. 13 - 15 Amp PGM-FI Main Relay
14. 14 - 20 Amp Power Door Lock Control Unit
15. 15 - 15 Amp Dash Lights & Dimmer Circuit, Parking Lights, Taillights, License Plate Lights
16. 16 - 7.5 Amp Dome Light, Courtesy Lights, Cigarette Lighter, Trunk Light Power Antenna, Integrated Control Unit
17. 17 - 20 Amp Power Seat Height Motor
18. 18 - 15 Amp Radio, Cigarette Lighter
19. 19 - 20 Amp Horn, Brakelight Circuit, Key Interlock Solenoid
20. 20 - 15 Amp Turn Signal & Hazard Circuit
21. 21 - 40 Amp Blower Motor Relay
22. 22 - 40 Amp Rear Window Defogger Relay
23. 23 - 80 Amp 100 Amp (EX, EX-R) Battery, Power Distribution

Scheme 2

1. 1 - 40 Amp ABS Motor
2. 2 - 20 Amp ABS B1
3. 3 - 15 Amp ABS B2
4. 4 - 10 Amp ABS Unit
