Steering Wheel & Steering Column: Specifications

Steering Wheel & Steering Column: Specifications GMC Yukon III

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Automatic Transmission Control Bolt	10 N.m	89 lb in
Lower Steering Column Shroud Bolt	3 N.m	27 lb in
Shift Lever Bolt	20 N.m	15 lb ft
Steering Column Bracket Screw	6 N.m	53 lb in
Steering Column Bolt	27 N.m	20 lb ft
Steering Column Nut	27 N.m	20 lb ft
Steering Column Seal Nut	3 N.m	27 lb in
Steering Shaft Coupling Bolt (at the Upper Intermediate Shaft)	50 N.m	37 lb ft
Steering Shaft Coupling Bolt (at the Steering Gear)	47 N.m	35 lb ft
Steering Shaft Coupling Nut (at the Steering Column)	62 N.m	46 lb ft
Steering Wheel Heat Module Screw	2 N.m	18 lb in
Steering Wheel Lower Cover Bolt	1 N.m	9 lb in
Steering Wheel Nut	41 N.m	30 lb ft
Tilt Motor Bracket Bolt	2 N.m	18 lb in
Turn Signal Multifunction Switch Bolt	3 N.m	27 lb in
Upper Steering Column Shroud Bolt	2 N.m	18 lb in

Scheme 1: Steering Wheel Schematics

Scheme 2: Tilt/Telescoping Steering Column Schematics

Scheme 3: Steering Column Disassembled View (Manual Tilt)

Callout	Component Name
1	Upper Steering Column Shroud
2	Lower Steering Column Shroud
3	Steering Wheel Nut
4	Inflatable Restraint Steering Wheel Module Coil Retaining Ring
5	Inflatable Restraint Steering Wheel Module Coil
6	Inflatable Restraint Steering Wheel Module Coil Wave Washer
7	Steering Shaft Lock Plate Retaining Ring
8	Turn Signal Switch Cancel Cam Position Plate
9	Turn Signal Switch Cancel Cam
10	Steering Shaft Upper Bearing Spring
11	Steering Shaft Upper Bearing Inner Race Seat
12	Steering Shaft Upper Bearing Inner Race
13	Turn Signal Multifunction Switch Bracket
14	Shift Lever Seal
15	Shift Lever Bolt
16	Shift Lever
17	Theft Deterrent Module
18	Ignition and Start Switch
19	Ignition Lock Cylinder Case Bolt
20	Ignition Lock Cylinder Case
21	Transmission Control Bolt
22	Transmission Control
23	Automatic Transmission Shift Lock Control Actuator
24	Steering Shaft Upper Bearing
25	Steering Column Tilt Head Assembly
26	Lower Steering Column Shroud Bolt
27	Tilt Lever
28	Steering Shaft Upper Bearing
29	Steering Column Tilt Spring Guide
30	Steering Column Tilt Spring
31	Pivot Pin
32	Steering Column Support and Upper Jacket Assembly
33	Steering Column Bracket Screw
34	Turn Signal Multifunction Switch Bolt
35	Turn Signal Multifunction Switch
36	Steering Shaft Lower Bearing
37	Steering Wheel Position Sensor
38	Steering Wheel Position Sensor Retaining Clip
39	Steering Shaft Coupling Bolt
40	Steering Shaft Coupling Nut
41	Upper Intermediate Steering Shaft
42	Steering Column Electrical Harness
43	Service Steering Column

Scheme 4: Steering Column Disassembled View (Automatic Tilt)

Callout	Component Name
1	Upper Steering Column Shroud
2	Lower Steering Column Shroud
3	Steering Wheel Nut
4	Inflatable Restraint Steering Wheel Module Coil Retaining Ring
5	Inflatable Restraint Steering Wheel Module Coil
6	Inflatable Restraint Steering Wheel Module Coil Wave Washer
7	Steering Shaft Lock Plate Retaining Ring
8	Turn Signal Switch Cancel Cam Position Plate
9	Turn Signal Switch Cancel Cam
10	Steering Shaft Upper Bearing Spring
11	Steering Shaft Upper Bearing Inner Race Seat
12	Steering Shaft Upper Bearing Inner Race
13	Steering Shaft Upper Bearing
14	Shift Lever Seal
15	Shift Lever Bolt
16	Shift Lever
17	Theft Deterrent Module
18	Ignition and Start Switch
19	Ignition Lock Cylinder Case Bolt
20	Ignition Lock Cylinder Case
21	Transmission Control Bolt
22	Transmission Control
23	Automatic Transmission Shift Lock Control Actuator
24	Steering Column Tilt Head Assembly
25	Lower Steering Column Shroud Bolt
26	Steering Column Tilt Wheel Switch
27	Steering Shaft Upper Bearing
28	Pivot Pin
29	Steering Column Support and Upper Jacket Assembly
30	Steering Column Bracket Screw
31	Tilt Motor Bracket Bolt
32	Tilt Motor
33	Tilt Motor Cable
34	Turn Signal Multifunction Switch Bolt
35	Turn Signal Multifunction Switch
36	Steering Shaft Lower Bearing
37	Steering Wheel Position Sensor
38	Steering Wheel Position Sensor Retaining Clip
39	Steering Shaft Coupling Nut
40	Steering Shaft Coupling Bolt
41	Upper Intermediate Steering Shaft
42	Service Steering Column
43	Steering Column Electrical Harness
