Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Assist Step Bracket Bolt | 25 N.m | 18 lb ft |
| Assist Step Bracket Nuts | 9 N.m | 80 lb in |
| Assist Step Controller Bolts | 10 N.m | 89 lb in |
| Body Mounting Bolt | 95 N.m | 70 lb ft |
| Engine Front Crossmember Nut - LD | 105 N.m | 77 lb ft |
| Engine Protection Shield to Frame Rail Bolts | 20 N.m | 15 lb ft |
| Engine Splash Shield Nut | 12 N.m | 106 lb in |
| Front Engine Crossmember Bolt - HD | 120 N.m | 88 lb ft |
| Intermediate Cable Nut | 4 N.m | 30 lb in |
| Master Cylinder Mounting Nuts | 28 N.m | 21 lb ft |
| Oil Pan Skid Plate | 28 N.m | 21 lb ft |
| Spare Wheel Hoist Crossmember to Frame Crossmember Bolts | 50 N.m | 37 lb ft |
| Spare Wheel Hoist Crossmember to Frame Rail Bolts | 70 N.m | 52 lb ft |
| Steering Linkage Shield Bolts | 20 N.m | 15 lb ft |
| Tow Hook to Frame Rail Bolts | 85 N.m | 63 lb ft |
| Trailer Hitch to Bumper Bolts | 95 N.m | 70 lb ft |
| Trailer Hitch to Frame Bolts | 125 N.m | 92 lb ft |
| Trailer Hitch to Frame Bolts - (Four bolts w/ loose nuts) | 113 N.m | 83 lb ft |
| Transfer Case Shield | 20 N.m | 15 lb ft |
| Transmission Crossmember Nut | 95 N.m | 70 lb ft |
| Transmission Mount to Crossmember Nuts | 50 N.m | 37 lb ft |
| Wheelhouse Liner Screws | 3 N.m | 27 lb in |
Scheme 1
Scheme 1: Step/Running Board Schematics
