Entertainment System: Specifications GMC Yukon II

Entertainment Systems 27 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Antenna Cable Mounting Screw5 N.m44 lb in
Antenna Mast6 N.m53 lb in
Antenna Mounting Nut5 N.m44 lb in
Mounting Bracket Bolts6 N.m53 lb in
Speaker to Mounting Bracket Screws2 N.m18 lb in
Subwoofer Assembly Retaining Bolts9 N.m80 lb in
Trim Bezel Screws2 N.m18 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Radio/Audio System Schematics
Scheme 1: Radio/Audio System Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16: Steering Wheel Controls Schematics
Scheme 16: Steering Wheel Controls Schematics

Scheme 17

Scheme 17: Entertainment Component Views
Scheme 17: Entertainment Component Views
CalloutComponent Name
1Right Hand Body Harness
2Inline Connector C498
3Left Hand Body Harness
4Body Side Inner Panel
5Audio Amplifier

Scheme 18

Scheme 18
Scheme 18
CalloutComponent Name
1Rear Cargo Trim Panel
2Audio Amplifier
3Subwoofer

Scheme 19

Scheme 19
Scheme 19
CalloutComponent Name
1Door-RF
2Speaker - RF Door
3Speaker Connector (Harness)

Scheme 20

Scheme 20
Scheme 20
CalloutComponent Name
1Speaker - LF Door
2Door-LH (Inner)
3Speaker Connector (Harness)

Scheme 21

Scheme 21
Scheme 21
CalloutComponent Name
1Side Garnish Molding
2Speaker-Tweeter
3Instrument Panel Harness Speaker Connector

Scheme 22

Scheme 22
Scheme 22
CalloutComponent Name
1Body Side Inner Panel
2Regulator
3Speaker

Scheme 23

Scheme 23
Scheme 23
CalloutComponent Name
1Speaker - Subwoofer
2Body Side Inner Panel

Scheme 24

Scheme 24
Scheme 24
CalloutComponent Name
1D Pillar Trim Panel
2Speaker - D Pillar Twiddler

Scheme 25

Scheme 25
Scheme 25
CalloutComponent Name
1Electrical Connectors (Radio)
2Instrument Panel
3Radio
4Electrical Connector (CD)
5Remote Playback Device - CD Player
6Lower Console
7Lower Console Compartment
8HVAC and Blower Switch Compartment
9Radio Antenna Connector

Scheme 26

Scheme 26
Scheme 26
CalloutComponent Name
1Front Floor Console
2Rear Seat Audio (RSA) Controller

Scheme 27

Scheme 27
Scheme 27
CalloutComponent Name
1Steering Wheel Controls - Left
2Steering Wheel Assembly
