Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Information Center Telltale Assembly Retaining Screws | 2 N.m | 18 lb in |
| Rear Object Alarm Detection Module Retainer | 1.7 N.m | 15 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Rear Parking Assist Schematics
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 5: Rear Parking Assist Component Views
| Callout | Component Name |
|---|
| 1 | RPA Switch |
| 2 | I/P Switch Assembly Bracket |
Scheme 6
| Callout | Component Name |
|---|
| 1 | Rear Parking Assist (RPA) Display |
| 1 | RPA Display |
| 2 | D Pillar Trim Panel |
Scheme 7
| Callout | Component Name |
|---|
| 1 | Object Sensor |
| 2 | Rear Bumper Molding |
Scheme 8
| Callout | Component Name |
|---|
| 1 | Rear Seat Frame |
| 2 | Rear Parking Assist Module Connector |
| 3 | Rear Parking Assist Module Diagnostic Connector |
| 4 | Rear Parking Assist Module Connector |
| 5 | Right Body Harness |
Scheme 9
| Callout | Component Name |
|---|
| 1 | Rear Parking Assist (RPA) Display |
| 2 | Object Sensor-RR |
| 3 | Object Sensor-RM |
| 4 | Object Sensor-LM |
| 5 | Object Sensor-LR |
| 6 | Rear Object Sensor Control Module |
| 7 | Rear Object Sensor Control Module Connector |
| 8 | Real Time Damping (RTD) Module |
| 9 | RTD Module Connectors |
| 10 | LH Body Harness |
| 11 | P301 |
| 12 | RPA Diagnostic Connector |
