Power door locks — Keyless entry circuit, uplevel GMC Yukon Denali

Components on these wiring diagrams 21

Click a component to highlight it on every diagram it appears on.

• Body Control Module
• Cargo Door Jamb Switch
• Convenience Center
• Door Ajar Sw Cargo Dr Unlk Horn Relay
• Door Lock Inversion Module
• Left Front Door Jamb Switch
• Left Front Door Lock Actuator
• Left Front Door Lock Switch
• Left Rear Door Jamb Switch
• Left Rear Door Lock Actuator
• Pwr Accy Circuit Breaker A
• Rear Cargo Door Lock Actuator
• Rear Door Lock Switch
• Right Front Door Jamb Switch
• Right Front Door Lock Actuator
• Right Front Door Lock Switch
• Right Rear Cargo Door Contactor
• Right Rear Door Jamb Switch
• Right Rear Door Lock Actuator
• Unlock
• Vehicle Interface Unit
