HVAC System - Automatic: Overview GMC Yukon Denali

HVAC Schematic Icons

HVAC Schematic Icons Icon Icon Definition Refer to Handling ESD Sensitive Parts Notice in Cautions and Notices

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

DTC DESCRIPTION INDEX

DTC DESCRIPTIONS

Test Description

The number(s) below refer to the step number(s) on the diagnostic table.

1. 2: Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition.
2. 3: Determine if HVAC, Body Control Module, or Powertrain Control Module DTCs which may affect HVAC operation are present.
3. 4: The presence of DTCs which begin with "U" indicate some other module is not communicating. The specified procedure will compile all the available information before tests are performed.

Diagnostic System Check

The number(s) below refer to the step number(s) on the diagnostic table.

1. 8: Tests for the possibility of a short to another 5 V reference circuit.

DTC B0159 Outside Air Temperature Sensor Circuit Range/Performance

The number(s) below refer to the step number(s) on the diagnostic table.

1. 8: Tests for the possibility of a short to another 5 V reference circuit.

DTC B0164 Passenger Compartment Temperature Sensor #1 (Single Sensor or LH) Circuit Range/Performance

The number(s) below refer to the step number(s) on the diagnostic table.

1. 8: Tests for the possibility of a short to another 5 V reference circuit.

DTC B0174 Output Air Temperature Sensor #1 (Upper; Single or LH) Circuit Range/Performance

The number(s) below refer to the step number(s) on the diagnostic table.

1. 8: Tests for the possibility of a short to another 5 V reference circuit.

DTC B0179 Output Air Temperature Sensor #2 (Lower; Single or LH) Circuit Range/Performance

The number(s) below refer to the step number(s) on the diagnostic table.

1. 8: Tests for the possibility of a short to another 5 V reference circuit.

DTC B0184 Solar Load Sensor #1 CKT Range

The number(s) below refer to the step number(s) on the diagnostic table.

1. 5: This step verifies that the KDD data circuit is functioning.
2. 6: This test verifies that the KDD clock data circuit is operating at the correct frequency.

DTC U1500 Communication (Front to Rear) State of Health

The number(s) below refer to the step number(s) on the diagnostic table.

1. 4: The HVAC control module is inoperative when the module does not respond to any operator control requests.
2. 24: When the blower motor is in the OFF position, a voltage is applied to the OFF blower motor control circuit. The A/C system will not operate if a voltage is applied to the OFF blower motor control circuit.

HVAC Compressor Clutch Does Not Engage

The number(s) below refer to the step number(s) on the diagnostic table.

1. 2: This step tests for blower motor operation in any speed setting.
2. 3: This step identifies if the HVAC control module is commanding the blower motor to operate at HI speed.
3. 5: This step verifies that power is being supplied to the blower motor.
4. 6: This step tests for a possible open in the blower motor ground circuit or a bad motor.

Blower Motor Inoperative in Auto Mode

Air Delivery Description and Operation

The air delivery controls are divided into eight areas

1. HVAC Control Components
2. Air Speed
3. Auxiliary Air Speed
4. Air Delivery
5. Auxiliary Air Delivery
6. Recirculation Operation
7. Auxiliary HVAC Combinations
8. Automatic Operation

Recirculation Operation

When air recirculation is selected, a signal is sent from the HVAC control module to the recirculation actuator through the recirculation door control circuit. The recirculation actuator closes the recirculation door in order to circulate the air within the vehicle. The outside air switch opens the recirculation door in order to route outside air into the vehicle.

Regardless of the blower motor switch position, recirculation is available only in the vent and bi-level mode switch positions. Including the OFF position. The mode switch must be placed in either the vent or bi-level position before the blower motor switch is placed in the OFF position. In order to reduce windshield fogging, outside air is circulated when the mode switch is in the defrost, floor, and mix-blend positions. If the recirculation switch is pressed into the ON position when the mode switch is in an unavailable mode position, then the recirculation switch LED will flash 3 times.

When the recirculation door moves to a desired position, a variable resistor within the actuator is used to create the recirculation door position signal. The HVAC module uses the recirculation door position signal to determine the actual recirculation door position. The left instrument panel fuse block provides power to the recirculation actuator through the ignition 3 voltage circuit and the IP wiring harness junction block. Power and ground are provided to the HVAC control module by the fuse block through the ignition 3 voltage circuit and the ground circuits through the right instrument panel junction block. A 5 volt reference signal is sent to the actuator through the 5 volt reference circuit, through the right instrument panel junction block, to the recirculation actuator.

When the automatic setting has been selected, the HVAC control module will recirculate air whenever system temperature performance is insufficient to provide the desired temperature. The recirculation switch LED will not be illuminated. If either the outside air or recirculation switch is pressed during automatic operation, then automatic operation will be over ridden. The appropriate recirculation or outside air switch LED will be illuminated. The recirculation door will be opened or closed depending upon the selected override. When the ambient air temperature is below 4°C (40°F) the recirculation override of the automatic setting will only be available for 10 minutes.

When the automatic setting has not been selected, only the outside air or recirculation switch will be used to determine the recirculation door position. When the ambient air temperature is below 4°C (40°F) any recirculation selection will only be available for 10 minutes.

The A/C high pressure recirculation switch can cause the HVAC system to recirculate air. When the high side pressure reaches 2206-2620 Kpa (320-380 psi), the PCM will place the HVAC system in recirculation mode. The high side pressure is lowered when the inside air cools the refrigerant within the A/C evaporator. When the high side pressure reaches 1447-1861 Kpa (210-270 psi), the PCM will place the HVAC system out of recirculation mode.

Automatic Operation

The automatic HVAC system will maintain the interior temperature of the vehicle by controlling the blower motor, air temperature, mode and recirculation actuators to achieve the desired temperature. For full automatic operation, both the blower and mode switches must be in the AUTO position and the air temperature set between 19°C (66°F) and 28°C (82°F). Blower speeds will be gradually increased or decreased, and can be reduced based on vehicle speed in order to maintain airflow into the vehicle. At start up, the automatic HVAC system will use to the last settings used prior to vehicle shut down.

In cold temperatures, the automatic HVAC system will provide heat in the most efficient manner. At initial vehicle start up, the blower motor is not turned on until the coolant reaches a predetermined temperature. If the coolant does not warm up within a preset time, the blower will be activated. The HVAC system can quickly warm up the vehicle when the temperature and blower motor settings are set to maximum and outside air and floor modes are selected. Once the desired temperature is reached, the blower motor will slow down, discharge temperatures will be lowered, and the mode actuator will remain in the floor setting. The system can be placed in bi-level if the ambient temperature is near 7-10°C (45-50°F). Regardless of mode selection, some air will be diverted to the defrost setting to keep window fogging at a minimum.

If the ambient air temperature is less than 2°C (35°F) and the coolant temperature is less than 10°C (50°F), then a 75 second purge will occur. The purge is performed in order to reduce window fogging until the coolant warms up. The purge will begin as soon as the coolant temperature reaches 4°C (40°F). The mode door will move to the defrost position and the blower motor will be near half speed.

In warm temperatures, the automatic HVAC system will provide A/C in the most efficient manner. The HVAC system can quickly cool down the vehicle when the temperature is set to minimum, blower motor is set to maximum, and recirculation and vent modes are selected. Once the desired temperature is reached, the blower motor will slow down, discharge temperatures will be raised, and the mode actuator will be switched to bi-level for better passenger comfort. The recirculation actuator can be partially opened to assist in temperature control. Regardless of mode selection, some air will be diverted to the floor setting to keep occupant comfort at a maximum.

Air Temperature Description and Operation

The air temperature controls are divided into eleven areas

1. HVAC Control Components
2. Heating
3. Air Conditioning
4. Automatic Operation
5. Engine Coolant
6. A/C Cycle
7. Auxiliary HVAC Combinations
8. Automatic Auxiliary HVAC System
9. Manual Auxiliary HVAC w/o CF5
10. Manual Auxiliary HVAC w/CF5
11. Manual Auxiliary w/C36 or C69 Only

Heating Operation

The purpose of the heater is to supply heat to the interior of the vehicle. The vehicle operator can determine the level of heat by turning the air temperature switch, located on the HVAC control module, to any setting. The air temperature switch can change the vehicle's air temperature regardless of the HVAC mode setting, heater or A/C.

When the air temperature switch is placed to the warmest position the HVAC control module will not regulate the air temperature. The HVAC control module will move the air temperature actuator to divert all air flow through the heater core. The blower speed and mode selection will be set at the last known manual input to the HVAC control module. Unless the blower motor switch is in the Auto position then the blower motor is at full speed. The HVAC control module will not monitor the sensors as the module will place the air temperature actuator to its full warm position.

When the air temperature switch is placed to any position other than the warmest position the air temperature actuator position is regulated to achieve desired temperature. This action does not place the entire HVAC system to automatic mode. When a warm air temperature is needed the HVAC control module will monitor the lower air temperature sensor, the inside air temperature assembly and the sunload sensor to correctly position the air temperature door. The HVAC control module will only change the position of air temperature actuator to get the desired temperature, blower speed and mode are not regulated.

A/C Operation

The purpose of the air conditioning (A/C) system is to provide cool air and remove humidity from the interior of the vehicle. The vehicle operator can activate the A/C system by manually placing the mode switch in the Defrost position or by pressing the A/C button. The A/C system can operate regardless of the temperature setting, as long as outside ambient temperature is above 4°C (40°F). If the A/C is requested and temperatures are too low, the LED will flash 3 times to remind the vehicle operator that A/C is not available. If the blower motor switch is in the Off position the A/C button is inoperative. The A/C indicator lamp will not illuminate if system mode is selected to Defog or Defrost if it is off, or when the A/C compressor is on and in Automatic mode. The A/C indicator lamp will illuminate when the outside air temperature is above 40° and vehicle operator selects A/C on in manual mode.

When the air temperature switch is placed to the coldest position the HVAC control module will not regulate the air temperature. The HVAC control module will move the air temperature actuator to divert all air flow through the evaporator. The blower speed and mode selection will be set at the last known manual input to the HVAC control module. Unless the blower motor switch is in the Auto position then the blower motor is at full speed. The HVAC control module will not monitor the sensors as the module will place the air temperature actuator to its full cool position.

When the air temperature switch is placed to any position other than the coldest position the air temperature actuator position is regulated to achieve desired temperature. This action does not place the entire HVAC system to automatic mode. When a warm air temperature is needed the HVAC control module will monitor the upper air temperature sensor, the inside air temperature assembly and the solar sensor to correctly position the air temperature door. The HVAC control module will only change the position of air temperature actuator to get the desired temperature, blower speed and mode are not regulated.

When the A/C button is pressed, a request is made to the powertrain control module (PCM) to turn on the A/C compressor. The PCM turns on the A/C compressor by providing a path to ground through the A/C clutch relay control circuit for the A/C compressor clutch relay. Once the relay closes its internal switch, power from the battery is provided to the A/C compressor clutch through the A/C compressor clutch supply voltage circuit. Whenever the compressor is turned off, the A/C compressor clutch diode provides a path for the voltage spike resulting from the collapsing magnetic field of the compressor clutch coil.

In order for the PCM to internally ground the A/C clutch relay control circuit, the A/C low pressure switch signal circuit needs to be grounded and the A/C request signal circuit needs to have 12 volts applied to it from the HVAC control module. A 12-volt reference signal is sent out over the A/C request signal circuits from the HVAC control module, through the A/C high pressure switch and then to the PCM when the vehicle operator makes an A/C request. A separate 12-volt reference signal is sent out over the A/C low pressure switch signal circuit, through the A/C low pressure switch and the ground circuit.

The PCM will engage the A/C clutch any time the engine speed is below 5500 RPM and the A/C is requested unless any of the following conditions exist

1. Throttle angle is at 100 percent.
2. The A/C low pressure switch pressure is less than 145-172 kPa (21-25 psi).
3. The A/C high pressure switch pressure is more than 2896 kPa (420 psi).
4. Engine speed is more than 5500 RPM.
5. Engine coolant temperature (ECT) is more than 121°C (250°F).

In order to place the HVAC system in Automatic mode these requirements need to be meet

1. The blower motor switch must be in the Auto position.
2. The air temperature switch must be in any other position other than the coldest position or the warmest position.
3. The mode switch must be in the Auto position.

The HVAC control module will perform the following routines to maintain the desired air temperature

1. Monitor the following sensors: The inside air temperature sensor The ambient air temperature sensor The upper air temperature sensor if cool air is required The lower air temperature sensor if warm air required The sunload sensor
2. Regulate blower motor speed.
3. Position the air temperature actuator
4. Position the mode actuator
5. Position the recirculation actuator
6. Request A/C operation

When the temperature is placed in the coldest position, the HVAC control module will do the following

1. The automatic blower will go to maximum speed
2. The automatic mode will position the mode door to the Panel position

When the temperature switch is in the warmest position, the HVAC control module will do the following

1. The automatic blower will go to maximum speed
2. The automatic mode will position the mode door to the Floor position

Auxiliary Heating Operation

The operation of the front HVAC control assembly when put into the OFF position disables the auxiliary controls. When the front HVAC control assembly is put into the REAR position the rear auxiliary HVAC control module controls the auxiliary HVAC operation. Only the rear seat occupants can control the HVAC settings. When AUTO is selected on the front auxiliary HVAC assembly, the rear auxiliary HVAC control module uses calculations based on these following components to regulate the air temperature

1. Auxiliary inside air temperature sensor
2. Upper auxiliary air temperature sensor
3. Lower auxiliary air temperature sensor
4. Auxiliary air temperature actuator
5. Mode actuator

The signal from the front auxiliary control assembly for auxiliary air temperature signal is a varied 12 volt signal. When a warm air request is made the signal voltage is high. When a cool air request is made the signal voltage is low.

Auxiliary A/C Operation

The operation of the front HVAC control assembly when put into the OFF position disables the auxiliary controls. When the front HVAC control assembly is put into the REAR position the rear auxiliary HVAC control module controls the auxiliary HVAC operation. Only the rear seat occupants can control the HVAC settings. When AUTO is selected on the front auxiliary HVAC assembly, the rear auxiliary HVAC control module uses calculations based on these following components to regulate the air temperature

1. Auxiliary inside air temperature sensor
2. Upper auxiliary air temperature sensor
3. Lower auxiliary air temperature sensor
4. Auxiliary air temperature actuator
5. Mode actuator

When an auxiliary warm air request is made the auxiliary HVAC control processor will send a high voltage signal to the auxiliary air temperature actuator on the auxiliary air temperature door position signal circuit. This voltage signal is a varied 12 volt signal. This signal is monitored by the logic incorporated in the actuator and it will move the actuator in the desired direction when a position change is requested. The signal from the auxiliary HVAC control assemblies to the auxiliary HVAC control processor is a varied 12 volt signal. This signal, when warm air is requested, is a high voltage signal.

When an auxiliary cool air request is made the auxiliary HVAC control processor will send a low voltage signal to the auxiliary air temperature actuator on the auxiliary air temperature door position signal circuit. This voltage signal is a varied 12 volt signal. This signal is monitored by the logic incorporated in the actuator and it will move the actuator in the desired direction when a position change is requested. The signal from the auxiliary HVAC control assemblies to the auxiliary HVAC control processor is a varied 12 volt signal. This signal, when cool air is requested, is a low voltage signal.

When an auxiliary warm air request is made the front auxiliary HVAC control assembly will send a high voltage signal to the auxiliary air temperature actuator on the auxiliary air temperature door position signal circuit. This voltage signal is a varied 12 volt signal. This signal is monitored by the logic incorporated in the actuator and it will move the actuator in the desired direction when a position change is requested.

When an auxiliary cool air request is made the front auxiliary HVAC control assembly will send a low voltage signal to the auxiliary air temperature actuator on the auxiliary air temperature door position signal circuit. This voltage signal is a varied 12 volt signal. This signal is monitored by the logic incorporated in the actuator and it will move the actuator in the desired direction when a position change is requested.

With the C36 option there is no auxiliary A/C system. This system has only a blower motor switch to regulate air speed. It does not use an air temperature actuator or a mode actuator. The lowest blower speed will have high auxiliary duct temperature. The highest blower speed will have low auxiliary duct temperature. The slower the air travels past the auxiliary heater core the more time it has to absorb heat.

With the C69 option there is no auxiliary heater system. This system has only a blower motor switch to regulate air speed. It does not use an air temperature actuator or a mode actuator. The lowest blower speed will have low auxiliary duct temperature. The highest blower speed will have high auxiliary duct temperature. The slower the air travels past the auxiliary evaporator core the more time the evaporator has to absorb the heat.

Purge Mode Description

The electronic climate control (ECC) module may access 3 additional purge modes when the following conditions exist

1. When the system is powered up, purge the system of stale air and/or redirect the air in order to avoid window fogging or other undesirable conditions.
2. When the ignition is turned ON and the fan increase/decrease knob is not in the OFF position, the ECC module will determine if any of the undesirable conditions exist.

The ECC module may select from one of the following 3 purge modes in order to eliminate the undesirable condition

1. The normal purge mode
2. The cold purge mode
3. The A/C purge mode

Inside Air Temperature Sensor Description

The inside air temperature sensor is a temperature-sensitive resistor similar to the outside temperature sensor. As cabin air temperature increases, resistance decreases. As cabin air temperature decreases, resistance increases.

A fan located in the in-vehicle air temperature sensor housing continually draws passenger compartment air over the sensor. This condition increases the accuracy of the temperature reading.

The electronic climate control (ECC) module monitors the vehicle temperature signals and uses this information in order to help determine command signals.

Ambient Outside Air Temperature Sensor Description

The outside air temperature sensor is a temperature-sensitive resistor. The resistance of the outside air temperature sensor varies inversely with the outside air temperature. As the outside air temperature increases, the resistance decreases. As the outside air temperature decreases, the resistance increases.

The electronic climate control (ECC) module monitors the outside temperature signal and uses this information in order to help determine command signals. NOTE: The sensor will not update when the vehicle is traveling less than 5 mph.

Sun Load Sensor Description

The sun load temperature sensor is a light-sensitive photo-diode that is used to monitor the heat load of the sun on the vehicle. The sensor is located in the defroster grille where the sunlight reaches the sensor. As the sunlight intensity increases, the conductivity of the sensor increases.

The electronic climate control (ECC) module monitors the sun load temperature sensor and uses this information in order to vary the in-vehicle temperature in order to compensate for the increased solar heat.

Actuator Description

The following six actuators control the automatic climate control system

1. The air temperature valve sensor and motor
2. The vacuum inlet door actuator
3. Four vacuum mode door actuators

When servicing an actuator, replace parts with the correct service parts for the actuator being serviced.

The air temperature valve sensor and motor contains a feedback potentiometer. The feedback potentiometer reports the position of the air temperature valve sensor and motor to the electronic climate control (ECC) module. If the air temperature valve sensor and motor has been removed or replaced for service the actuator must be initialized. Perform the following procedure in order to initialize the actuator

1. Turn the ignition switch to the OFF position.
2. Remove the RADIO fuse for 10 seconds.
3. Reinstall the RADIO fuse.
4. Turn the ignition switch to the ON position.
5. Ensure that the air temperature valve sensor and motor cycles through the hot and cold range.
