6.5l (vin p), transmission circuit, 4l60-e for GMC Vandura G3500 (1985-1996)

1-2 SHIFT SOL TCC SOL 2-3 SHIFT SOL 3-2 SHIFT SOL ACCELERATOR PEDAL POSITION (APP) MODULE (TOP OF ACCEL- ERATOR BRACKET) APP #2 PNK PPL WIRE APP #3 APP #3 SENSOR SIG APP 1 BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRK FUSE BRN WIRE DATA LINK CONNECTOR (BELOW LEFT SIDE OF I/P) DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ECM I FUSE ECM-B FUSE ELECTRONIC 4-SPEED AUTOMATIC OVERDRIVE TRANSMISSION ENGINE COOLANT TEMPERATURE (ECT) SENSOR (RIGHT SIDE OF ENGINE) HOT AT ALL TIMES HOT IN RUN HOT IN START OR RUN HOT IN START OR RUN FUSE BLOCK TRANS FUSE INGNITION FEED 3-2 CONTROL SOL DIAGNOSTIC REQUEST LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE PNK/BLK WIRE PNK/WHT WIRE POWERTRAIN CONTROL MODULE PPL PPL APP #2 SENSOR GROUND APP #1 SENSOR GROUND APP #3 SENSOR GROUND SENSOR GROUND PPL TCC/BRAKE SW VEHICLE SPEED SIG PPL/WHT WIRE PRESSURE CONTROL SOLENOID RANGE MODE SELECTOR RED WIRE RED/BLK WIRE SPEED SENSOR (LEFT REAR SIDE OF TRANSMISSION) TAN WIRE TAN/BLK WIRE TCC/ BRAKE SWITCH (ON BRAKE PEDAL SUPPORT BRACKET) TRANS FLUID TEMP (TFT) SENSOR TRANSFER CASE SWITCH VEHICLE SPEED SENSOR BUFFER (UNDER RIGHT END OF I/P) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
