Wiring diagram engine performance 5.0l (vin h)s, 4l60-e a/t (3 of 3) for GMC Vandura G3500 (1985-1996)

1-2 SHIFT SOLENIOD 1995 VFTC 2-3 SHIFT SOLENIOD 3-2 SHIFT SOLENOID AUTOMATIC TRANSMISSION AUXILIARY FUSE BLOCK B/H CONN BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE DATA LINK CONNECTOR (BEHIND LEFT SIDE OF I/P) DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE FUEL PUMP AND SENDER FUEL PUMP FUSE FUEL PUMP OIL PRESSURE SWITCH (TOP REAR OF ENGINE) FUEL PUMP PRIME CONNECTOR (NO LOCATION AVAILABLE) FUEL PUMP RELAY (RIGHT FRONT OF COWL, ABOVE BLOWER MOTOR) FUSE BLOCK TRANS FUSE GRY WIRE HEATED OXYGEN SENSOR (IN EXHAUST Y-PIPE) HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE PNK/BLK WIRE PPL PPL 3 4 PPL/WHT WIRE PRESSURE CONTROL SOLENOID SOLENOID PWM TORQUE CONVERTER CLUTCH RANGE MODE SELECTOR RED WIRE RED/BLK WIRE SOLENOID TAN/BLK WIRE TORQUE CONVERTER CLUTCH TRANS- MISSION TEMP SENSOR VEHICLE SPEED SENSOR (LEFT REAR OF TRANSMISSION) VEHICLE SPEED SENSOR BUFFER (ON PARKING BRAKE SUPPORT BRACKET) WHT WIRE WHT/BLK WIRE YEL/BLK WIRE
