GMC Vandura G3500 (1985-1996) upfitter package Wiring diagram
This page shows the only wiring diagram for the component.upfitter package, which is found in the car GMC Vandura G3500 (1985-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram upfitter package (1 of 1)
BASE MODELS
BATTERY IN GROUND
BLK WIRE
BLK/WHT WIRE
CONVENIENCE CENTER (UNDER LEFT SIDE OF I/P)
GAGES FUSE 4
GRY WIRE
HAZARD FUSE 5
HOT AT ALL TIMES
HOT IN PARK OR HEAD
HOT IN RUN OR START
I/P FUSE BLOCK
ILLUM FUSE 14
INSTRUMENT CLUSTER
KEY-IN SW IN FASTEN BELTS OUT
KEY-IN WARNING SWITCH (INSIDE STEERING COLUMN ASSEMBLY)
LEFT FRONT DOOR JAMB SWITCH
LIGHTS ON IN SAFETY BELT IN
LT GRN WIRE
MULTI-FUNCTION ALARM MODULE (IN CONVENIENCE CENTER)
NCA WIRE
ORG/ WIRE
PNK IGN ON IN WIRE
PNK WIRE
SAFETY BELT LAMP
SEAT BELT SWITCH (SEAT BELT BUCKLE ASSY)
SUPPLEMENTAL RESTRAINTS SYSTEM
TAN WIRE
UPFITTER PACKAGE
WHT WIRE
YEL WIRE
Go to component -> Warning system circuits -> UPFITTER PACKAGE
