GMC Vandura G3500 (1985-1996) right rear power door lock switch Wiring diagrams
This page contains all the electrical diagrams for the component. right rear power door lock switch, in which he is found in the car GMC Vandura G3500 (1985-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right rear power door lock switch (1 of 2)
A/C COMP MINI FUSE
A/C COMPRESSOR CLUTCH RELAY
AUXILIARY POWER OUTLET
BAT/HAZ MAXI- FUSE
BLK WIRE
CENTER DOME LAMP REAR DOME LAMP
CIG LTR FUSE 13
CIGARETTE LIGHTER
CONVENIENCE CENTER
CTSY FUSE 3
DATA LINK CONNECTOR
DAYTIME RUNNING LAMP RELAY
DRL FUSE 15
ECM-B MINI FUSE
FROM UNDERHOOD FUSE-RELAY CENTER
FRONT DOME LAMP
FUEL PUMP RELAY
HAZARD FUSE 5
HAZARD WARNING SWITCH
HEADLAMP SWITCH
HEATER AND A/C CONTROLLER MULTI- FUNCTION ALARM MODULE
HORN MINI FUSE
HORN RELAY
HTD MIR FUSE 2
I/P COMPARTMENT LAMP
I/P FUSE BLOCK
ILLUMINATED ENTRY MODULE
LEFT FRONT POWER DOOR LOCK SWITCH
LEFT POWER SEAT SWITCH
LEFT STEPWELL LAMP RIGHT STEPWELL LAMP
LEFT SUN SHADE MIRROR LAMP RIGHT SUN SHADE MIRROR LAMP
LIGHTING MAXI FUSE
NCA WIRE
ORG/ WIRE
PARK LPS FUSE 9
POWER ANTENNA ASSEMBLY
POWER DOOR LOCK RELAY REMOTE CONTROL DOOR LOCK RECEIVER
PWR ACCY CB A
PWR AUX FUSE 7
RADIO
RADIO-B FUSE 19
REAR STEPWELL LAMP POWER OUTSIDE REAR VIEW MIRROR REMOTE CONTROL SWITCH
RED WIRE
RIGHT FRONT POWER DOOR LOCK SWITCH POWER DOOR LOCK CONTROL MODULE
RIGHT POWER SEAT SWITCH
RIGHT REAR POWER DOOR LOCK SWITCH
STOP FUSE 1
TCC/STOP- LAMP SWITCH
UNDERHOOD FUSE-RELAY CENTER
UNDERHOOD LAMP
UNDERHOOD REEL LAMP
W/O UPFITTER PROVISIONS W/ UPFITTER PROVISIONS
Go to component -> Power distribution circuit (2 of 4) -> RIGHT REAR POWER DOOR LOCK SWITCH
Wiring diagram right rear power door lock switch (2 of 2)
BASE
BATTERY RR DR UNLCK
BLK WIRE
BLK/WHT WIRE
CONVENIENCE CENTER (LEFT SIDE OF I/P)
DATA LINK CONNECTOR (PARTIAL)
DOME LP DEF IGN PNK WIRE
DOOR JAMB SWITCH
DR INPUT BATTERY LOCK
DR UNLOCK DOME LP GND DR UNLOCK BATTERY
GAUGES FUSE 4
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK
LEFT FRONT DOOR LOCK MOTOR
LEFT FRONT POWER DOOR LOCK SWITCH
LOCK
LOCK SIG UNLOCK SIG GROUND
LOCK UNLOCK
LT BLU WIRE
ORG/ WIRE
PNK WIRE
POWER DOOR LOCK CONTROL MODULE (BEHIND RIGHT KICK PANEL)
POWER DOOR LOCK RELAY (BEHIND RIGHT KICK PANEL)
PROG SIG
PWR ACC CIRCUIT BREAKER A
REAR DOOR LOCK MOTOR
REMOTE CONTROL DOOR LOCK RECEIVER (BEHIND RIGHT KICK PANEL)
RIGHT FRONT DOOR LOCK MOTOR
RIGHT FRONT POWER DOOR LOCK SWITCH
RIGHT REAR POWER DOOR LOCK SWITCH
SEATS SYSTEM
SIDE DOOR CONTACT BUTTONS
SIDE DOOR LOCK MOTOR
TAN WIRE
UNLOCK
UNLOCK LOCK
W/ REMOTE KEYLESS ENTRY (RKE) ONLY
W/ RKE W/O RKE
W/ UPFITTER PROVISIONS
W/O UPFITTER PROVISIONS
WHT WIRE
WHT/BLK WIRE
Go to component -> Power door lock circuit -> RIGHT REAR POWER DOOR LOCK SWITCH
