Electrical Component Locator GMC Typhoon I

Electrical Component Locations 5 illustrations ~104 words

BUZZERS, RELAYS & TIMERS

ComponentLocation
A/C Clutch Control Relay
2.5L (VIN A)Far left side of firewall. (Scheme 1)
2.8L (VIN R)Center of left side inner fender. (Scheme 2)
4.3L (VIN Z)Far left side of firewall. (Scheme 3)
A/C High Blower RelayBetween blower motor and A/C accumulator.
Daytime Running Lights (DRL) RelayOn right side of steering column.
Foglight RelayAbove interior fuse block.
Fuel Pump Relay
2.5L (VIN A)On firewall, left of brake booster. (Scheme 1)
2.8L (VIN R)On firewall, left of brake booster. (Scheme 2)
4.3L (VIN Z)On firewall, left of brake booster. (Scheme 3)
4.3L HP (VIN W)On firewall, left of brake booster. (Scheme 4)
Hazard Flasher
Digital ClusterOn convenience center.
Standard ClusterOn interior fuse block.
Horn RelayOn convenience center.
Power Door Lock RelayOn right side of steering column.
Rear Window Defogger RelayOn right side of brake pedal support.
Rear Window Release RelayNear interior fuse block.
Turn Signal Flasher
Digital ClusterOn fuse block.
Standard ClusterAt convenience center.
Variable Tuning Relay (4.3L HP)On left side of firewall.

BUZZERS, RELAYS & TIMERS LOCATION

CIRCUIT PROTECTION DEVICES

ComponentLocation
Circuit Breakers
Power AccessoriesAt top of fuse block.
Power WindowsAt bottom of fuse block.
Convenience CenterLeft of steering column, at lower edge of dash.
Fuse Block
2.5L (VIN A)Below left side of dash. (Scheme 1)
2.8L (VIN R)Below left side of dash. (Scheme 2)
4.3L (VIN Z)Below left side of dash. (Scheme 3)
4.3L HP (VIN W)Below left side of dash. (Scheme 4)
Fusible Links
Power Distribution (2.5L & 4.3L)At rear of alternator (2 links).
Power Distribution (2.8L)At starter solenoid.
Interior Lights In-line FuseOn center of firewall.

CIRCUIT PROTECTION DEVICES LOCATION

CONTROL UNITS

ComponentLocation
ABS Module
Rear ABS (RABS)Near master cylinder.
4WD ABSOn left front fender.
Audio Alarm ModuleOn convenience center.
Cruise Control ModuleOn left side of steering column.
Daytime Running Lights (DRL) ModuleAbove interior fuse block.
Diode ModuleAbove fuse block.
Elapsed Timer Module (2.8L)Under right side of dash, next to ECM. (Scheme 2)
Electronic Control Module (ECM)
2.5L (VIN A)Under right side of dash. (Scheme 1)
2.8L (VIN R)Under right side of dash. (Scheme 2)
4.3L (VIN Z)Under right side of dash. (Scheme 3)
4.3L HP (VIN W)Under right side of dash. (Scheme 4)
Elec. Spark Control (ESC) Module
2.8L (VIN R)On center of firewall. (Scheme 2)
4.3L (VIN Z)On center of firewall. (Scheme 3)
4.3L HP (VIN W)On center of firewall. (Scheme 4)
Elec. Spark Timing (EST) ModuleAt distributor.
Elec. Transfer Case ModuleNear ECM.
Variable Tuning Controller (4.3L HP)On top of intake manifold.
Windshield Wiper ModuleOn center of firewall .

CONTROL UNITS LOCATION

SENDING UNITS & SENSORS

ComponentLocation
Coolant Temperature Sensor
2.5LOn top rear of engine. (Scheme 1)
2.8L (VIN R)On top front of engine. (Scheme 2)
4.3L (VIN Z)On top front of engine. (Scheme 3)
4.3L HPOn lower right side of engine. (Scheme 4)
Knock Sensor
2.8LOn right side of engine. (Scheme 2)
4.3LNear distributor. (Scheme 3)
4.3L HPOn lower left & on top rear of engine. (Scheme 4)
Manifold Absolute Pressure (MAP) Sensor (Except 4.3L HP)
2.5L (VIN A)On top right side of engine. (Scheme 1)
2.8L (VIN R)On top right side of engine. (Scheme 2)
4.3L (VIN Z)On top right side of engine. (Scheme 3)
4.3L HPNear A/C compressor. (Scheme 4)
Manifold Air Temp. (MAT) Sensor
2.5L (VIN A)On right side of engine, near alternator. (Scheme 1)
4.3L HP (VIN W)On right side of engine, near alternator. (Scheme 4)
Throttle Position Sensor (TPS)
2.5L (VIN A)On throttle body assembly. (Scheme 1)
2.8L (VIN R)On throttle body assembly. (Scheme 2)
4.3L (VIN Z)On throttle body assembly. (Scheme 3)
4.3L HP (VIN W)On throttle body assembly. (Scheme 4)
Transfer Case Speed SensorOn right rear of transfer case.
Vehicle Speed Sensor (VSS)
2.5L (VIN A)On left rear of transmission. (Scheme 1)
2.8L (VIN R)On left rear of transmission. (Scheme 2)
4.3L (VIN Z)On left rear of transmission. (Scheme 3)
4.3L HP (VIN W)On left rear of transmission. (Scheme 4)

SENDING UNITS & SENSORS LOCATION

MOTORS

ComponentLocation
A/C-Heater Blower MotorIn evaporator housing, in engine compartment.
Idle Air Control (IAC) Motor
2.5L (VIN A)On throttle body. (Scheme 1)
2.8L (VIN R)On throttle body. (Scheme 2)
4.3L (VIN Z)On throttle body. (Scheme 3)
4.3L HP (VIN W)On throttle body. (Scheme 5)
Power Door Lock MotorIn bottom rear of each door.
Power Window MotorIn each door.
Windshield Washer MotorOn side of washer reservoir.
Windshield Wiper MotorOn center of firewall.

MOTORS LOCATION

SOLENOIDS & SOLENOID VALVES

ComponentLocation
EGR Vacuum Solenoid
2.5LNear A/C compressor. (Scheme 1)
2.8LNear distributor. (Scheme 2)
Elec. Air Control (EAC) Sol. (2.8L)On bracket, at right front of engine. (Scheme 2)
Elec. Vacuum Regulator Valve (EVRV) (4.3L)On right valve cover.
Torque Converter Clutch Sol. (TCC)On left side of transmission.

SOLENOIDS & SOLENOID VALVES LOCATION

SWITCHES

ComponentLocation
A/C Cycling Pressure SwitchOn accumulator.
A/C Low Charge Protection SwitchOn rear of A/C compressor.
Back-Up Light SwitchOn left side of transmission.
Brake Pressure SwitchOn master cylinder.
Brake/Stoplight SwitchOn brake pedal support bracket.
Brake/Cruise SwitchOn brake pedal support bracket.
Coolant Temperature Switch
4.3L HPNear A/C compressor.
Except 4.3L HPLower right side of engine.
Clutch/Cruise SwitchOn clutch pedal support bracket.
Front Axle Lock SwitchOn front axle, near steering gear.
Fuel Pump/Oil Pressure Switch
4.3L HPNear distributor.
Except 4.3L HPNear distributor.
Neutral Safety SwitchOn top of steering column.
Oil Pressure Switch
2.5LOn right rear of engine. (Scheme 1)
2.8LOn left side of engine. (Scheme 2)
4.3L (VIN Z)On top rear of engine. (Scheme 3)
4.3L HP (VIN W)On top rear of engine. (Scheme 4)
Parking Brake SwitchOn base of parking brake assembly.
Power Steering Press. Switch (PSPS)In power steering pressure hose, near steering gear. (Scheme 1)
Starter Lock-Out Switch (M/T)On clutch pedal bracket.
Starter Lock-Out Switch (A/T)Base of steering column.
Transmission Position SwitchOn steering column.
4WD Indicator SwitchOn front drive axle.

SWITCHES LOCATION

MISCELLANEOUS

ComponentLocation
A/C-Heater Blower Motor ResistorOn blower motor housing.
ALDL Diagnostic Connector
2.5L (VIN A)Under left side of dash, to right of steering column. (Scheme 1)
2.8L (VIN R)Under left side of dash, to right of steering column. (Scheme 2)
4.3L (VIN Z)Under left side of dash, to right of steering column. (Scheme 3)
4.3L HP (VIN W)Under left side of dash, to right of steering column. (Scheme 4)
Fuel Pump Prime/Test Connector
2.5L (VIN A)On center of firewall. (Scheme 1)
2.8L (VIN R)On center of firewall. (Scheme 2)
4.3L (VIN Z)On center of firewall. (Scheme 3)
4.3L HP (VIN W)On center of firewall. (Scheme 4)
Vehicle Speed Sensor BufferNear ECM.

MISCELLANEOUS LOCATION

COMPONENT LOCATION GRAPHICS

Note. Figures may show multiple component locations. Refer to appropriate table for proper figure references.

Component Locations (1 Of 5). Scheme 1

Scheme 1: Component Locations (1 Of 5)

Component Locations (2 Of 5). Scheme 2

Scheme 2: Component Locations (2 Of 5)

Component Locations (3 Of 5). Scheme 3

Scheme 3: Component Locations (3 Of 5)

Component Locations (4 Of 5). Scheme 4

Scheme 4: Component Locations (4 Of 5)

Component Locations (5 Of 5). Scheme 5

Scheme 5: Component Locations (5 Of 5)
