Front Suspension System: Maintenance GMC Terrain I

Suspension Front 3 illustrations

Adhesives, Fluids, Lubricants, and Sealers

ApplicationType of MaterialGM Part Number
USCanada
Front and Rear Wheel Bearing/Hub Mounting BoltsThread Locker©8902129710953488

Adhesives, Fluids, Lubricants, and Sealers

Scheme 5

Scheme 5: Stabilizer Shaft Replacement
Scheme 5: Stabilizer Shaft Replacement
CalloutComponent Name
Preliminary Procedure Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the tire and wheel assembly. Refer to Tire and Wheel Removal and Installation . Remove the engine front splash shield. Refer to Engine Splash Shield Replacement - Left Side .
1Stabilizer Shaft Procedure Remove the outer tie rod end from the steering knuckle. Refer to Steering Linkage Outer Tie Rod Inspection . Remove the stabilizer link from the stabilizer shaft. Refer to Stabilizer Shaft Link Replacement . Remove the stabilizer shaft insulators. Refer to Stabilizer Shaft Insulator Replacement . Remove the stabilizer shaft through the left wheel opening.

Stabilizer Shaft Replacement

Scheme 6

Scheme 6: Stabilizer Shaft Link Replacement
Scheme 6: Stabilizer Shaft Link Replacement
CalloutComponent Name
Preliminary Procedures Raise the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the front wheel and tire assembly. Refer to Tire and Wheel Removal and Installation .
1Stabilizer Shaft Link Nut CAUTION: Refer to Fastener Caution . TIP: Use the proper size Allen wrench to keep the stabilizer link ball stud from rotate while removing or installing the nut. Tighten 75 N.m (55 lb ft).
2Stabilizer Shaft Link Nut TIP: Use the proper size Allen wrench to keep the stabilizer link ball stud from rotate while removing or installing the nut. Tighten 85 N.m (63 lb ft).
3Stabilizer Shaft Link
CAUTION
Refer to Fastener Caution .

Stabilizer Shaft Link Replacement

Scheme 7

Scheme 7: Stabilizer Shaft Insulator Replacement
Scheme 7: Stabilizer Shaft Insulator Replacement
CalloutComponent Name
Preliminary Procedures Raise the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the front wheel and tire assemblies. Refer to Tire and Wheel Removal and Installation .
1Stabilizer Shaft Insulator Bolt (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 50 N.m (37 lb ft).
2Stabilizer Shaft Insulator Clamp (Qty: 2)
3Stabilizer Shaft Insulator (Qty: 2)
CAUTION
Refer to Fastener Caution .

Stabilizer Shaft Insulator Replacement
