Scheme 178
Circuit/System Description
The accessory power receptacle located in rear of the vehicle is supplied B+ all the time. The accessory power receptacles located in the instrument panel and center console are supplied B+ when the ignition is on or in the accessory position.
12 Volt Power Outlet Receptacle Description and Operation
The accessory power receptacle in the rear of the vehicle is supplied battery voltage at all times. The accessory power receptacles located in the center console and the instrument panel are supplied battery voltage when the ignition is on or in the accessory position.
