Supplemental Inflatable Restraint System: Specifications GMC Terrain I

Airbag 3 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Driver or Passenger Seat Side Inflatable Restraint Module Nut9 N.m80 lb in
Driver or Passenger Seat Belt Tensioner Assembly Fastener45 N.m33 lb ft
Driver or Passenger Seat Belt Tensioner Fastener7.5 N.m66 lb in
Driver or Passenger Seat Shoulder Belt Guide Fastener45 N.m33 lb ft
Driver or Passenger Seat Shoulder Belt Retractor Fastener45 N.m33 lb in
Front Seat Belt Tensioner Fastener7.5 N.m66 lb in
Inflatable Restraint Remote Impact Fasteners7.5 N.m66 lb in
Inflatable Restraint Roof Side Rail Module Fasteners9 N.m80 lb in
Inflatable Restraint Sensing and Diagnostic Module (SDM) Fasteners10 N.m89 lb in
Inflatable Restraint Side Impact Sensor Bolts7.5 N.m66 lb in
Inflatable Restraint Steering Wheel Module Coil Bolt3 N.m27 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Module Power, Ground, Serial Data And Front Passenger Presence System
Scheme 1: Module Power, Ground, Serial Data And Front Passenger Presence System

Scheme 2

Scheme 2: Air Bags And Sensors (1 Of 2)
Scheme 2: Air Bags And Sensors (1 Of 2)

Scheme 3

Scheme 3: Air Bags And Sensors (2 of 2) And Pretensioners
Scheme 3: Air Bags And Sensors (2 of 2) And Pretensioners
