VIN LOCATION
The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.
SERVICE PARTS IDENTIFICATION LABEL
Label is located inside glove box door and has the vehicle's VIN, wheelbase, paint information, and a list of all production options and special equipment.
VIN CODE ID EXPLANATION
Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.
VIN CODE ID EXPLANATION. Scheme 1
SHORT TRIP/CITY & LONG TRIP/HIGHWAY SERVICE DEFINITIONS
Note. Starting in the 1996 model year, General Motors has renamed their maintenance schedules; One is referred to as the Short-Trip/City and the other is the Long Trip/Highway schedule. These schedule requirements are similar to the familiar Severe Service and Normal schedules and can be used in place of one another.
SEVERE & NORMAL SERVICE DEFINITIONS
Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions
Service is recommended at mileage intervals based on vehicle operation, emission classification, and Gross Vehicle Weight Rating (GVWR, VIN Position 4). Emission classification is identified by engine VIN code (except diesel-powered vehicles). Manufacturer's Schedules identify items to be serviced based on type of operation. Service schedules are based on the following primary operating conditions
Severe Service
- Short Trips (4 Miles Or Less)
- Freezing Temperatures
- Towing Or Heavily Loaded
- Severe Dust Conditions
- Hot Weather, Stop-And-Go Driving
- Extensive Idling Conditions (Taxi Or Delivery Type Service)
Normal Service
- No Severe Service Operating Conditions
Scheme 2
Note. For more information regarding lifting and hoisting refer to the JACKING & HOISTING article in the WHEEL ALIGNMENT section.
Scheme 3
DRAINING, FLUSHING AND REPLACEMENT OF DIESEL COOLANT
- Open the air bleed valve in the engine coolant outlet (thermostat housing). (Scheme 4)
- Fill the surge tank bottle until coolant comes out of the air bleed valve.
- ON VEHICLES WITH REAR HEATER, close the air bleed valve. Start the engine and bring the engine speed to 2000 RPM for 2 to 3 minutes to flush any air for rear heater. Shut off the engine and open the air bleed valve. Fill the surge tank until coolant comes out the air bleed valve.
- Close the air bleed valve and install pressure cap on the surge tank.
- Monitor the cold coolant level in the surge tank. Add coolant as needed to bring the coolant level to the "Full Cold" mark.
- Verify there are no leaks.
Scheme 4
Note. For more information regarding Diesel Idle Speed Adjustments refer to the ADJUSTMENTS - 6.5L DIESEL article in the ENGINE PERFORMANCE section.
DRAINING FUEL FROM WATER/FUEL SEPARATOR (DIESEL)
| WARNING | Diesel fuel system may be contaminated with fungi or other microorganisms. Keep contaminated fuel away from open skin cuts or sores to prevent skin irritation or infection. |
| WARNING | DO NOT drain fuel/water separator when engine is running or hot. Allow engine to cool before draining. Verify that the WATER IN FUEL light on instrument panel is OFF. |
- Turn off engine and block drive wheels.
- Remove fuel filler cap(s) to release any pressure or vacuum in the vehicle fuel tank(s).
- Place a suitable container under the filter drain hose.
- Open the drain valve. (Scheme 5)
- Start engine and allow to idle for 1 to 2 minutes or until clear fuel is observed.
- Close the drain valve and stop the engine.
- Replace fuel filler cap(s).
- Dispose of drained mixture in a proper manner.
Scheme 5
Note. For more information regarding Diesel Idle Speed Adjustments refer to the ADJUSTMENTS - 6.5L DIESEL article in the ENGINE PERFORMANCE section.
CHANGING FUEL FILTER (DIESEL)
| WARNING | Diesel fuel system may be contaminated with fungi or other microorganisms. Keep contaminated fuel away from open skin cuts or sores to prevent skin irritation or infection. |
| WARNING | DO NOT drain fuel/water separator when engine is running or hot. Allow engine to cool before draining. Verify that the WATER IN FUEL light on instrument panel is OFF. |
- Turn off engine and block drive wheels.
- Remove fuel filler cap(s) to release any pressure or vacuum in the vehicle fuel tank(s).
- Place a suitable container under the filter drain hose.
- Start engine and open the drain valve. (Scheme 5)
- Once fuel begins to flow from the drain hose open the air bleed valve on the top of fuel filter housing. (Scheme 6)
- Stop the engine.
- After all fuel has drained from filter housing, close the fuel drain valve (Fig. (Scheme 5) ), and the air bleed valve. (Fig. (Scheme 6) ).
- Dispose of drained mixture in a proper manner.
- Loosen the element nut on the top of the fuel filter housing (Scheme 6) An oil filter type wrench may be used.
- Remove housing cap and lift out old fuel filter element.
- Verify filter housing and all mating surfaces are free of any water or other contamination. Some clean fuel may be left in housing, as it will be absorbed by the new filter element.
- Install new fuel filter by aligning the widest key slot located under the element assembly cap with the widest key in the housing.
- Push the element assembly downward until the mating surfaces make contact.
- Install and tighten element nut by hand.
- Bleed air from fuel/water separator as follows.
- Open air bleed valve on top of filter housing (Fig. (Scheme 6) ).
- Connect hose to the air bleed valve on the top of the filter housing (Fig. (Scheme 6) ).
- Disconnect the fuel injection pump shutdown solenoid (pink wire) located on the fuel injection pump. (Scheme 7)
- Crank the engine in 10 to 15 second intervals until clear fuel is observed at the air bleed hose (Wait 1 minute between cranking intervals to avoid overheating the starter).
- Close the air bleed valve.
- Connect the shutdown solenoid wire and reinstall fuel filler cap(s).
- Start the engine and allow to idle for 5 minutes.
- Check fuel filter assembly for leaks.
- Dispose of drained mixture in a proper manner.
Scheme 6
Scheme 7
STARTING OUT OF FUEL DIESEL
| WARNING | DO NOT USE starting fluids (ether) or flammable liquids to aid the starting of a Diesel engine. NEVER pour diesel fuel, flammable liquids or starting fluids into the air cleaner canister, air intake or turbocharger housing in an attempt to start the vehicle. A flash fire may result causing personal injury. |
- Add 5 gallons of diesel fuel to fuel tank.
- Open air bleed valve on top of filter housing (Fig. (Scheme 6) ).
- Connect hose to the air bleed valve on the top of the filter housing (Fig. (Scheme 6) ).
- Place a suitable container under the filter drain hose.
- Crank the engine in 10 to 15 second intervals until clear fuel is observed at the air bleed hose (Wait 1 minute between cranking intervals to avoid overheating the starter). CAUTION: If engine starts during step #5, stop engine and close air bleed valve before attempting restart.
- Close the air bleed valve.
- Crank the engine in 10 to 15 second intervals until the engine starts. (Wait 1 minute between cranking intervals to avoid overheating the starter).
Scheme 8
Scheme 9
Note. For more information regarding Diesel Idle Speed Adjustments refer to the ADJUSTMENTS - 6.5L DIESEL article in the ENGINE PERFORMANCE section.
Scheme 10
Note. For more information regarding CDRV testing and service refer to the SYSTEM/COMPONENT TESTS - 6.5L DIESEL article in the ENGINE PERFORMANCE section.
Scheme 11
Scheme 12
Scheme 13
Note. For more information regarding EGR system service refer to the EGR FUNCTION TESTING article in the ENGINE PERFORMANCE section.
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
BRAKE SERVICE INFORMATION
Note. For more information regarding brake system service refer to the BRAKE SYSTEM article in the BRAKES section.
Scheme 20
Scheme 21
AXLE & TRANSMISSION IDENTIFICATION
Note. For more information regarding Axle identification refer to the DRIVE AXLE RATIO IDENTIFICATION article in the DRIVE AXLES section.
Note. For more information regarding Automatic Transmission ID refer to the TRANSMISSION OIL PAN GASKET ID article in the AUTOMATIC TRANS SERVICE section.
SERVICE LABOR TIMES
Note. Labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.
WHEEL & TIRE SPECIFICATIONS
Wheel and tire information can be found on the decal attached to rear of driver's door.
| Application | Ft. lbs. (N.m) | |
|---|---|---|
| 1995 | ||
| C-1500 (5 bolt) | 120 (163) | |
| K-1500 & C/K-2500 (6 bolt) | 120 (163) | |
| C/K-2500 (8 bolt) | 120 (163) | |
| 1996-98 | ||
| C-1500 (5 bolt) | 140 (190) | |
| K-1500 & C/K-2500 (6 bolt) | 140 (190) | |
| C/K-2500 (8 bolt) | 140 (190) | |
WHEEL LUG NUT TORQUE SPECIFICATIONS
BATTERY SPECIFICATIONS
| CAUTION | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section. |
SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG)
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAGS article in ACCESSORIES/SAFETY EQUIPMENT. |
Modification to the air bag system component or wiring can adversely affect system performance and possibly cause injury.
| CAUTION | The Diagnostic Energy Reserve Module (DERM) can maintain enough voltage to cause a deployment of the inflator module for up to 10 minutes after the ignition switch is turned off and the battery is disconnected. Many of the service procedures require e disconnection of the inflator module to avoid an accidental deployment. |
| CAUTION | Disconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation |
Note. See the AIR BAGS article in the ACCESSORIES/SAFETY EQUIPMENT Section.
Modifications or improper maintenance, including incorrect removal and installation of the Supplemental Restraint System (SRS), can adversely affect system performance. DO NOT cover, obstruct or change the steering wheel horn pad in any way, as such action could cause improper function of the system. Use only plain water when cleaning the horn pad. Solvents or cleaners could adversely affect the air bag cover and cause improper deployment of the system.
AIR CONDITIONING SERVICING
| WARNING | R-134a service equipment or vehicle A/C systems SHOULD NOT be pressure tested or leak tested with compressed air. Some mixtures of air/R134a have shown to be combustible at elevated pressures. These mixtures are dangerous and may cause fire and/or explosions. See AIR CONDITIONING SERVICE article in AIR CONDITIONING & HEATING section. |
| CAUTION | Avoid breathing R-134a refrigerant and PAG lubricant vapors, exposure may irritate eyes, nose and throat. To remove R-134a from system use R-134a recycling equipment that meets SAE J2210 specifications. If accidental system discharge occurs, ventilate work area before resuming service. |
ANTI-LOCK BRAKE SYSTEM
The anti-lock brake system contains electronic equipment that can be susceptible to interference caused by improperly installed or high output radio transmitting equipment. Since this interference could cause the possible loss of the anti-lock braking capability, such equipment should be installed by qualified professionals.
On models equipped with anti-lock brake systems, ALWAYS observe the following cautions
- DO NOT attempt to bleed hydraulic system without first referring to the appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES Section.
- DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings.
- Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in an ABS-equipped vehicle.
AXLE FLUID
| CAUTION | Axle lubricant should be changed whenever the axle has been submerged in water. Water can enter through the axle vent hole and contaminate the lubricant. |
REPLACING BLOWN FUSES
Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.
BATTERY WARNING
| CAUTION | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See the COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section. |
BRAKE PAD WEAR INDICATOR
Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.
BRAKE PAD REPLACEMENT
| WARNING | Use caution when checking and/or changing brake pads, some pads may contain asbestos which can irritate eyes and may cause other health hazards. A water based solution should be used to clean brake dust from wheel and brake components. DO NOT use compressed air to blow off brake dust. |
CATALYTIC CONVERTER
To prevent catalytic converter overheating, DO NOT allow engine to idle for more than 20 minutes.
COOLANT (DEX-COOL 1995 MODELS)
| CAUTION | Some 1995 build-out models may have DEX-COOL engine coolant installed at the factory. DEX-COOL coolant is orange in color and should not be mixed with regular ethylene-glycol coolant. To avoid possible damage to vehicle cooling system, visually check engine coolant color before adding and/or changing engine coolant. Vehicle should have an identification label placed under the hood stating what type coolant is installed. |
COOLANT (PROPYLENE-GLYCOL FORMULATIONS)
| CAUTION | Propylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C); Ethylene-Glycol -35° F (-37°C) - 263° F (128°C). |
| CAUTION | Propylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations. |
To avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. Full strength anti-freeze has a freeze point of only -8° F (-22°C).
DIESEL FUEL ANTI-FUNGAL ADDITIVES
| CAUTION | If fuel contamination due to fungi or other microorganisms is suspected a fuel additive with a biocide may be used. Follow the manufacturers dosage as recommended on product label. Use biocides ONLY when necessary, excessive use can may cause other fuel system problems. |
DIESEL FUEL CONTAMINATION
| WARNING | Diesel fuel system may be contaminated with fungi or other microorganisms. Keep contaminated fuel away from open skin cuts or sores to prevent skin irritation or infection. |
DIESEL FUEL REQUIREMENTS
| CAUTION | All diesel engines are to use Diesel Fuel #2 when the outside temperature is above 20°F (-7°C). In temperatures that are below 20°F (-7°C) use Diesel Fuel #1, this will reduce the chance of the fuel thickening and forming wax. |
Note. A Diesel Fuel #1 & #2 combination (Blended Fuel) may be used, and is recommended for mild winter driving.
JUMP STARTING (TURBO DIESEL)
| WARNING | DO NOT USE a booster battery or power source that has more than 12 volts of power. NEVER USE a 24 volt power source. |
STARTING FLUID USE (TURBO DIESEL)
| WARNING | DO NOT USE starting fluids (ether) or flammable liquids to aid the starting of a Diesel engine. NEVER pour diesel fuel, flammable liquids or starting fluids into the air cleaner canister, air intake or turbocharger housing in an attempt to start the vehicle. A flash fire may result causing personal injury. |
ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS
| CAUTION | Many solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component. |
FUEL SYSTEM SERVICE
| WARNING | Relieve fuel system pressure prior to servicing any fuel system component (fuel injection models). |
HALOGEN BULBS
| WARNING | Halogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs. |
RADIATOR FAN
| WARNING | Keep hands away from radiator fan. |
TURBOCHARGED MODELS (TURBO-DIESEL)
| CAUTION | Do not race engine immediately after starting. When stopping engine, allow engine to idle for approximately 60 seconds before shutting it off. Failure to do so may cause turbocharger damage due to lack of oil flowing to the turbocharger bearings. |
WARRANTY INFORMATION
| CAUTION | Due to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options. |
BUMPER-TO-BUMPER PLUS COVERAGE LIMITED WARRANTY
Entire vehicle (except battery) is covered for 3 years or 50,000 miles, whichever occurs first. Covered by this warranty are any repairs to vehicle components which have proven defective in material and workmanship under normal use (tires excluded). Warranty repairs (parts and labor) will be made by the Dealer at no charge using new or remanufactured parts. This warranty is subject to a 100 deductible for each repair visit after the first year or 12,000 miles, whichever occurs first.
BATTERY COVERAGE
Covers replacement cost of battery for 3 years or 50,000 miles (36,000 miles on 1992 models), whichever occurs first. A prorated charge applies after first 12 months or 12,000 miles, whichever occurs first.
CORROSION COVERAGE
Covers any body sheet metal panel that is perforated due to corrosion. Coverage is for 6 years or 100,000 miles, whichever occurs first.
EMISSIONS "DEFECT" & "PERFORMANCE" WARRANTIES (EXCEPT CALIFORNIA)
Defect Warranty ensures vehicle meets applicable EPA regulations and that emission control system is free from defects in materials and workmanship. Coverage is for 5 years or 50,000 miles, whichever occurs first.
Performance Warranty covers all costs of repairing or adjusting any components or parts as needed in order for the vehicle to pass a federally-required state or local emissions test. Other emission control parts related to these components are covered by the Performance Warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered.
EMISSION "PERFORMANCE" WARRANTY (CALIFORNIA)
If vehicle fails a Smog Check inspection, all necessary repairs and adjustments will be made by manufacturer to ensure vehicle passes inspection. Coverage is for 3 years or 50,000 miles, whichever occurs first.
LIGHT-DUTY EMISSION "DEFECTS" WARRANTY (CALIFORNIA)
If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer. Coverage is for 3 years or 50,000 miles, whichever occurs first.
Some emission-related parts are covered for 7 years or 70,000 miles, whichever occurs first, and will be repaired or replaced by manufacturer if found to be defective in material or workmanship. See customer's copy of warranty information for specific items covered.
HEAVY-DUTY EMISSION CONTROL SYSTEMS (GASOLINE ENGINES)
Warranty coverage is 5 years or 50,000 miles, whichever occurs first.
HEAVY-DUTY EMISSION CONTROL SYSTEMS (DIESEL ENGINES)
Warranty coverage is 5 years or 100,000 miles, whichever occurs first.
FUSE PANEL LOCATION
The fuse block is located behind a cover in the dash to the left of the steering column.
Scheme 22
Fuse & Circuit Breaker Identification
- 1 - Stop/Haz 20 Amp (Yellow) - Stop/TCC Switch, Hazard Flasher, Seat Belt Reminder, Stoplights, CHMSL (Center High Mounted Stop Light)
- 2 - T Case (Not Used) - Transfer Case
- 3 - CTSY 20 Amp (Yellow) - Courtesy Lamps, Cargo Lamp, Glove Box Light, Power Mirrors, Dome/Reading Lamps, Vanity Mirrors
- 4 - Gauges 10 Amp (Red) - DRL Relay, DRL Module Buzzer, Headlamp Switch, Keyless Entry, Cluster/Gauges, Low Coolant Module, Convenience Center Electrochromatic Rearview Mirror with Compass
- 5 - RR HVAC 10 Amp (Red) - RR HVAC Controls
- 6 - Cruise 10 Amp (Red) - Cruise Module, Cruise Activator Switch
- 7 - AUX PWR 25 Amp (Clear) - Power Outlets (2)
- 8 - Crank 10 Amp (Red) - Diesel Fuel Pump, DERM ECM (Air Bag), PCM
- 9 - Park Lamps 20 Amp (Yellow) - License Plate Light, Park Lamps, Tail Lamps, Ashtray Lamp, Door Switch Illumination, Headlight ON Warning, Side Marker Fog Lamp Relay, Clearance Lights, Heater & A/C Illumination
- 10 - Air Bag 10 Amp (Red) - DERM (Air Bag)
- 11 - Wiper 25 Amp (Clear) - Windshield Washer/Wiper
- 12 - HTR-A/C 25 Amp (Clear) - L, M1, M2 Blower, HVAC Indicator Lamp, A/C Compressor, Mode/Temp/Air In Actuator, High Blower Relay
- 13 - CIG LTR 20 Amp (Yellow) - Cigar Lighter, Power Amplifier, Door Lock Relay, Power Lumbar Seat, Rear Liftglass
- 14 - ILLUM 10 Amp (Red) - 4WD Indicator Lamp, Cluster, HVAC Controls, Chime Module, Radio Illumination, Instrument Panel Switches, RR HVAC Controls
- 15 - DRL-FOG 20 Amp (Yellow) - DRL Relay, Fog Lamps
- 16 - Turn B/U 20 Amp (Yellow) - Front Turn, RR Turn, Trailer Turn, Back-up Lamps, BTSI (Brake/Transmission Shift Interlock) Solenoid
- 17 - Radio 10 Amp (Red) - Radio (IGN)
- 18 - Brake 10 Amp (Red) - DRAC, 4WAL/PCM, ABS, Cruise
- 19 - Radio 10 Amp (Red) - Radio (BATT)
- 20 - Acc/Ign 10 Amp (Red) - PRNDL, Auto Transmission, Speedometer, Check Gauges, Tell Tale
- 21 - Not Used
- 22 - Not Used
- 23 - RR Wiper 25 Amp (Clear) - Rear Wiper, Rear Wash Pump
- 24 - 4WD 25 Amp (Clear) 4X4 Models - Front Axle Actuator, 4WD Indicator Lamp, TP2 Relay, Hour Meter (7Y4 Option)
- A - PWR ACCY 30 Amp (Circuit Breaker) - Power Door Lock, 6 Way Power Seat, Keyless Entry Module
- B - PWR WDOS 30 Amp (Circuit Breaker) - Power Windows
Scheme 23
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
Fuse & Relay Identification
- 1 - Spare
- 2 - STOP 30 Amp Maxifuse (Green) - Stop Lamps
- 3 - A/C 50 Amp Maxifuse (Red) - High Blower Relay, Rear Blower Relay
- 4 - ABS 60 Amp Maxifuse (Blue) - ABS Module
- 5 - IGN B 50 Amp Maxifuse (Red) 50 Amp - IGN B Switch, Go To Fuse Block Busbar
- 6 - IGN A 40 Amp Maxifuse (Amber) - IGN A Switch, Go To Fuse Block Busbar
- 7 - BATTERY 50 Amp Maxifuse (Red) - Battery, Fuse Block Busbar
- 8 - LIGHTING 50 Amp Maxifuse (Red) - Headlamp & Panel Dimmer Switch, Fog Lights, Courtesy Lights
- 9 - 30 Amp (Green)
- 10 - 30 Amp (Green)
- 11 - 10 Amp (Red) - Spare
- 12 - 20 Amp (Yellow) - Spare
- 13 - 30 Amp (Green) - Spare
- 14 - Not Used
- 15 - A/C COMP 10 Amp (Red) - SW A/C Pressure to A/C Clutch
- 16 - HORN 20 Amp (Yellow) - Horn, Underhood Lamps
- 17 - ECM B 20 Amp (Yellow) - Fuel Pump, PCM
- 18 - Not Used
- 19 - AUX FAN 30 Amp (Green) - Aux. Fan
- 20 - RR- DEFOG 30 Amp (Green)
- 19 - RR- DEFOG 30 Amp (Green) - RR DEFOG
- 20 - RR- DEFOG 30 Amp (Green) - RR DEFOG
- 21 - ENG 1 20 Amp (Yellow) - IGN A Switch to Engine Loads, EGR, Canister Purge EVRV Idle Coast Solenoid, Heated O2 Sensor, Fuel Heater, Water Sensor
- 22 - ECM 1 20 Amp (Yellow) - Injector #1, Injector #2, PCM
- 23 - FUEL SOL 20 Amp (Yellow) - Fuel Solenoid (Diesel Engine Only)
- 24 - Not Used
- 25 - Not Used
- 26 - IGN E 10 Amp (Red) - Aux Fan Relay Coil, Hot Fuel Module
- 27 - Not Used
- 28 - Not Used
- 29 - GLOW PLUGS 10 Amp (Red) - Glow Plugs (Diesel Engine Only)
- 30 - Not Used
- 31 - Not Used
- 32 - Not Used
- A - 30 Amp
- B - 30 Amp - UY1, UY7 Camper/Trailer Wiring
- C - Brake Lamp Relay
- D - Horn Relay
- E - Auxiliary Fan Relay
- F - A/C Relay
- G - Fuel Pump Relay
Scheme 24
Fuse & Circuit Breaker Identification
- A - Fog Lamp Relay
- B - DRL (Daytime Running Lights) Relay
- C - Hazard Flasher
- D - Chime
See also:
• COMPUTER RELEARN PROCEDURES
