| Application | Specification |
|---|
| Adjustment Procedures | (Scheme 12) |
| Camber in Degrees (Fraction) | 1 13/32 to 13/32 |
| Camber in Degrees (Decimal) | .30 to 1.3 |
| Caster in Degrees (Fraction) | 2 3/16 to 3 3/16 |
| Caster in Degrees (Decimal) | 2.2 to 3.2 |
| Toe-In in Inches (Decimal) | .05 +/- .03 |
| Toe-In in Degrees (Decimal) | .1 +/- .05 |
| Toe-Out on Turns (Inner) | (1) |
| Toe-Out on Turns (Outer) | (1) |
| Steering Axis Inclination (SAI) | (1) |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (ASTRO & SAFARI)
| Application | Specification |
|---|
| Adjustment Procedures | (Scheme 11) |
| Camber in Degrees | 1/2 (0.5) |
| Caster in Degrees | 1 (1.0) |
| Toe-In in Inches | 1/4 (0.025) |
| Toe-In in Degrees | 1/2 (0.05) |
| Toe-Out on Turns | (1) |
| Steering Axis Inclination (SAI) | (1) |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (C100, C200 & C300)
| Application | Specification |
|---|
| Adjustment Procedures | (Scheme 11) |
| Camber in Degrees | 29/32 +/- 1/2 (0.90 +/- 0.5) |
| Caster in Degrees | 4 +/- 1/2 (4.0 +/- 0.5) |
| Toe-In in Inches | 3/16 (0.188) |
| Toe-In in Degrees | 3/8 (0.375) |
| Toe-Out on Turns | (1) |
| Steering Axis Inclination (SAI) | (1) |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (K100 & K200)
| Application | Specification |
|---|
| Adjustment Procedures | (Scheme 11) |
| Camber in Degrees | 3/4 +/- 1/2 (0.75 +/- 0.5) |
| Caster in Degrees | 4 +/- 1/2 (4.0 +/- 0.5) |
| Toe-In in Inches | 1/32 +/- 1/64 (0.035 +/- 0.025) |
| Toe-In in Degrees | 5/64 +/- 3/64 (0.07 +/- 0.05) |
| Toe-Out on Turns | (1) |
| Steering Axis Inclination (SAI) | (1) |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (K300)
| Application | Specification |
|---|
| Adjustment Procedures | (Scheme 12) |
| Camber in Degrees | 45/64 (0.7) |
| Toe-In in Inches | 1/64 (0.018) |
| Toe-In in Degrees | 1/32 (0.036) |
| Toe-Out on Turns | (1) |
| Steering Axis Inclination | (1) |
| Caster |
| With 2 1/2" Ride Height | 3 45/64 (3.7) |
| With 2 3/4" Ride Height | 3 1/2 (3.5) |
| With 3" Ride Height | 3 13/64 (3.2) |
| With 3 1/4" Ride Height | 2 29/32 (2.9) |
| With 3 1/2" Ride Height | 2 19/32 (2.6) |
| With 3 3/4" Ride Height | 2 13/32 (2.4) |
| With 4" Ride Height | 2 3/32 (2.1) |
| With 4 1/4" Ride Height | 1 51/64 (1.8) |
| With 4 1/2" Ride Height | 1 1/2 (1.5) |
| With 4 3/4" Ride Height | 1 19/64 (1.3) |
| With 5" Ride Height | 1 (1.0) |
| With 5 1/4" Ride Height | 51/64 (0.8) |
| With 5 1/2" Ride Height | 1/2 (0.5) |
| With 5 3/4" Ride Height | 19/64 (0.3) |
| With 6" Ride Height | 0 (0) |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (R100)
| Application | Specification |
|---|
| Adjustment Procedures | (Scheme 12) |
| Camber in Degrees | 1/4 (0.25) |
| Toe-In in Inches | 1/64 (0.018) |
| Toe-In in Degrees | 1/32 (0.036) |
| Toe-Out on Turns | (1) |
| Steering Axis Inclination (SAI) | (1) |
| Caster |
| With 2 1/2" Ride Height | 1 1/2 (1.5) |
| With 2 3/4" Ride Height | 1 13/64 (1.2) |
| With 3" Ride Height | 29/32 (0.9) |
| With 3 1/4" Ride Height | 19/32 (0.6) |
| With 3 1/2" Ride Height | 19/64 (0.3) |
| With 3 3/4" Ride Height | 3/32 (0.1) |
| With 4" Ride Height | 1/64 (-0.1) |
| With 4 1/4" Ride Height | 5/32 (-0.15) |
| With 4 1/2" Ride Height | 45/64 (-0.7) |
| With 4 3/4" Ride Height | 1 (-1.0) |
| With 5" Ride Height | 1 13/64 (-1.2) |
| With 5 1/4" Ride Height | 1 13/32 (-1.4) |
| With 5 1/2" Ride Height | 1 19/32 (-1.6) |
| With 5 3/4" Ride Height | 1 51/64 (-1.8) |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (R200 & R300)
| Application | Specification |
|---|
| Adjustment Procedures | (Scheme 12) |
| Camber in Degrees (Fraction) | 5 (center) |
| Camber in Degrees (Decimal) | 5.0 (center) |
| Caster in Degrees (Fraction) | 5 (center) |
| Caster in Degrees (Decimal) | 5.0 (center) |
| Toe-In in Inches | 1/8 (0.125) |
| Toe-In in Degrees | 1/4 (0.25) |
| Toe-Out on Turns | (1) |
| Steering Axis Inclination (SAI) | (1) |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (V100, V200 & V300)
| Application | Specification |
|---|
| Adjustment Procedures | (Scheme 12) |
| Camber in Degrees (Fraction) | 1/2 |
| Camber in Degrees (Decimal) | 0.5 |
| Toe-In in Inches (Fraction) | 1/64 |
| Toe-In in Inches (Decimal) | 0.018 |
| Toe-In in Degrees (Fraction) | 1/32 |
| Toe-In in Degrees (Decimal) | 0.036 |
| Toe-Out on Turns | (1) |
| Steering Axis Inclination (SAI) | (1) |
| Ride Height in Inches | 1 1/2 |
| Caster in Degrees (Fraction) | 3 13/32 |
| Caster in Degrees (Decimal) | 3.4 |
| Ride Height in Inches | 1 3/4 |
| Caster in Degrees (Fraction) | 3 13/32 |
| Caster in Degrees (Decimal) | 3.4 |
| Ride Height in Inches | 2 |
| Caster in Degrees (Fraction) | 3 13/32 |
| Caster in Degrees (Decimal) | 3.4 |
| Ride Height in Inches | 2 1/4 |
| Caster in Degrees (Fraction) | 3 13/32 |
| Caster in Degrees (Decimal) | 3.4 |
| Ride Height in Inches | 2 1/2 |
| Caster in Degrees (Fraction) | 3 13/32 |
| Caster in Degrees (Decimal) | 3.4 |
| Ride Height in Inches | 2 3/4 |
| Caster in Degrees (Fraction) | 3 13/32 |
| Caster in Degrees (Decimal) | 3.4 |
| Ride Height in Inches | 3 |
| Caster in Degrees (Fraction) | 3 13/32 |
| Caster in Degrees (Decimal) | 3.4 |
| Ride Height in Inches | 3 1/4 |
| Caster in Degrees (Fraction) | 3 13/32 |
| Caster in Degrees (Decimal) | 3.4 |
| Ride Height in Inches | 3 1/2 |
| Caster in Degrees (Fraction) | 3 13/32 |
| Caster in Degrees (Decimal) | 3.4 |
| Ride Height in Inches | 3 3/4 |
| Caster in Degrees (Fraction) | 3 13/32 |
| Caster in Degrees (Decimal) | 3.4 |
| Ride Height in Inches | 4 |
| Caster in Degrees (Fraction) | 3 13/32 |
| Caster in Degrees (Decimal) | 3.4 |
| Ride Height in Inches | 4 1/4 |
| Caster in Degrees (Fraction) | 3 13/32 |
| Caster in Degrees (Decimal) | 3.4 |
| Ride Height in Inches | 4 1/2 |
| Caster in Degrees (Fraction) | 3 13/32 |
| Caster in Degrees (Decimal) | 3.4 |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (G100 & G200)
| Application | Specification |
|---|
| Adjustment Procedures | (Scheme 12) |
| Camber in Degrees (Fraction) | 1/4 |
| Camber in Degrees (Decimal) | 0.25 |
| Toe-In in Inches (Fraction) | 1/64 |
| Toe-In in Inches (Decimal) | 0.018 |
| Toe-In in Degrees (Fraction) | 1/32 |
| Toe-In in Degrees (Decimal) | 0.036 |
| Toe-Out on Turns | (1) |
| Steering Axis Inclination (SAI) | (1) |
| Ride Height in Inches | 1 1/2 |
| Caster in Degrees (Fraction) | 3 3/32 |
| Caster in Degrees (Decimal) | 3.1 |
| Ride Height in Inches | 1 3/4 |
| Caster in Degrees (Fraction) | 3 |
| Caster in Degrees (Decimal) | 3.0 |
| Ride Height in Inches | 2 |
| Caster in Degrees (Fraction) | 2 45/64 |
| Caster in Degrees (Decimal) | 2.7 |
| Ride Height in Inches | 2 1/4 |
| Caster in Degrees (Fraction) | 2 13/32 |
| Caster in Degrees (Decimal) | 2.4 |
| Ride Height in Inches | 2 1/2 |
| Caster in Degrees (Fraction) | 2 3/32 |
| Caster in Degrees (Decimal) | 2.1 |
| Ride Height in Inches | 2 3/4 |
| Caster in Degrees (Fraction) | 1 51/64 |
| Caster in Degrees (Decimal) | 1.8 |
| Ride Height in Inches | 3 |
| Caster in Degrees (Fraction) | 1 1/2 |
| Caster in Degrees (Decimal) | 1.5 |
| Ride Height in Inches | 3 1/4 |
| Caster in Degrees (Fraction) | 1 13/64 |
| Caster in Degrees (Decimal) | 1.2 |
| Ride Height in Inches | 3 1/2 |
| Caster in Degrees (Fraction) | 1 |
| Caster in Degrees (Decimal) | 1.0 |
| Ride Height in Inches | 3 3/4 |
| Caster in Degrees (Fraction) | 45/64 |
| Caster in Degrees (Decimal) | 0.7 |
| Ride Height in Inches | 4 |
| Caster in Degrees (Fraction) | 1/2 |
| Caster in Degrees (Decimal) | 0.5 |
| Ride Height in Inches | 4 1/4 |
| Caster in Degrees (Fraction) | 13/64 |
| Caster in Degrees (Decimal) | 0.2 |
| Ride Height in Inches | 4 1/2 |
| Caster in Degrees (Fraction) | 1/32 |
| Caster in Degrees (Decimal) | 0.03 |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (G300)
| Application | Specification |
|---|
| Adjustment Procedures | (Scheme 12) |
| Camber in Degrees (Fraction) | 1/4 |
| Camber in Degrees (Decimal) | 0.25 |
| Toe-In in Inches (Fraction) | 1/64 |
| Toe-In in Inches (Decimal) | 0.018 |
| Toe-In in Degrees (Fraction) | 1/32 |
| Toe-In in Degrees (Decimal) | 0.036 |
| Toe-Out on Turns | (1) |
| Steering Axis Inclination (SAI) | (1) |
| Ride Height in Inches | 2 |
| Caster in Degrees (Fraction) | 3 |
| Caster in Degrees (Decimal) | 3.0 |
| Ride Height in Inches | 2 1/4 |
| Caster in Degrees (Fraction) | 2 19/32 |
| Caster in Degrees (Decimal) | 2.6 |
| Ride Height in Inches | 2 1/2 |
| Caster in Degrees (Fraction) | 2 19/64 |
| Caster in Degrees (Decimal) | 2.3 |
| Ride Height in Inches | 2 3/4 |
| Caster in Degrees (Fraction) | 2 |
| Caster in Degrees (Decimal) | 2.0 |
| Ride Height in Inches | 3 |
| Caster in Degrees (Fraction) | 1 45/64 |
| Caster in Degrees (Decimal) | 1.7 |
| Ride Height in Inches | 3 1/4 |
| Caster in Degrees (Fraction) | 1 13/32 |
| Caster in Degrees (Decimal) | 1.4 |
| Ride Height in Inches | 3 1/2 |
| Caster in Degrees (Fraction) | 1 13/64 |
| Caster in Degrees (Decimal) | 1.2 |
| Ride Height in Inches | 3 3/4 |
| Caster in Degrees (Fraction) | 29/32 |
| Caster in Degrees (Decimal) | 0.9 |
| Ride Height in Inches | 4 |
| Caster in Degrees (Fraction) | 19/32 |
| Caster in Degrees (Decimal) | 0.6 |
| Ride Height in Inches | 4 1/4 |
| Caster in Degrees (Fraction) | 13/32 |
| Caster in Degrees (Decimal) | 0.4 |
| Ride Height in Inches | 4 1/2 |
| Caster in Degrees (Fraction) | 13/64 |
| Caster in Degrees (Decimal) | 0.2 |
| Ride Height in Inches | 4 3/4 |
| Caster in Degrees (Fraction) | 3/32 |
| Caster in Degrees (Decimal) | 0.1 |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS (P200 & P300 W/O 5000-lb. I-BEAM AXLE, DUAL REAR WHEELS & HYDROBOOST)
| Application | Specification |
|---|
| Adjustment Procedure | (Scheme 12) |
| Camber in Degrees (Fraction) | 1/4 |
| Camber in Degrees (Decimal) | 0.25 |
| Toe-In in Inches (Fraction) | 1/64 |
| Toe-In in Inches (Decimal) | 0.018 |
| Toe-In in Degrees (Fraction) | 1/32 |
| Toe-In in Degrees (Decimal) | 0.036 |
| Toe-Out on Turns | (1) |
| Steering Axis Inclination (SAI) | (1) |
| Ride Height in Inches | 2 |
| Caster in Degrees (Fraction) | 2 1/2 |
| Caster in Degrees (Decimal) | 2.5 |
| Ride Height in Inches | 2 1/4 |
| Caster in Degrees (Fraction) | 2 13/64 |
| Caster in Degrees (Decimal) | 2.2 |
| Ride Height in Inches | 2 1/2 |
| Caster in Degrees (Fraction) | 1 29/32 |
| Caster in Degrees (Decimal) | 1.9 |
| Ride Height in Inches | 2 3/4 |
| Caster in Degrees (Fraction) | 1 19/32 |
| Caster in Degrees (Decimal) | 1.6 |
| Ride Height in Inches | 3 |
| Caster in Degrees (Fraction) | 1 19/64 |
| Caster in Degrees (Decimal) | 1.3 |
| Ride Height in Inches | 3 1/4 |
| Caster in Degrees (Fraction) | 1 3/32 |
| Caster in Degrees (Decimal) | 1.1 |
| Ride Height in Inches | 3 1/2 |
| Caster in Degrees (Fraction) | 51/64 |
| Caster in Degrees (Decimal) | 0.8 |
| Ride Height in Inches | 3 3/4 |
| Caster in Degrees (Fraction) | 1/2 |
| Caster in Degrees (Decimal) | 0.5 |
| Ride Height in Inches | 4 |
| Caster in Degrees (Fraction) | 19/64 |
| Caster in Degrees (Decimal) | 0.3 |
| Ride Height in Inches | 4 1/4 |
| Caster in Degrees (Fraction) | 0 |
| Caster in Degrees (Decimal) | 0 |
| Ride Height in Inches | 4 1/2 |
| Caster in Degrees (Fraction) | 13/64 |
| Caster in Degrees (Decimal) | 0.2 |
| Ride Height in Inches | 4 3/4 |
| Caster in Degrees (Fraction) | 13/32 |
| Caster in Degrees (Decimal) | 0.4 |
| (1) Information not available |
| (1) | Information not available |
P200 & P300 W/ DUAL REAR WHEELS & w/o HYDROBOOST
| Application | Specifications |
|---|
| Adjustment Procedures | (Scheme 12) |
| Camber in Degrees (Fraction) | 1/4 |
| Camber in Degrees (Decimal) | 0.25 |
| Toe-In in Inches (Fraction) | 1/4 |
| Toe-In in Inches (Decimal) | 0.25 |
| Toe-In in Degrees (Fraction) | 1/2 |
| Toe-In in Degrees (Decimal) | 0.5 |
| Toe-Out on Turns | (1) |
| Steering Axis Inclination (SAI) | (1) |
| Ride Height in Inches | 2 1/2 |
| Caster in Degrees (Fraction) | 5 1/2 |
| Caster in Degrees (Decimal) | 5.5 |
| Ride Height in Inches | 2 3/4 |
| Caster in Degrees (Fraction) | 5 19/64 |
| Caster in Degrees (Decimal) | 5.3 |
| Ride Height in Inches | 3 |
| Caster in Degrees (Fraction) | 5 |
| Caster in Degrees (Decimal) | 5.0 |
| Ride Height in Inches | 3 1/4 |
| Caster in Degrees (Fraction) | 4 45/64 |
| Caster in Degrees (Decimal) | 4.7 |
| Ride Height in Inches | 3 1/2 |
| Caster in Degrees (Fraction) | 4 13/32 |
| Caster in Degrees (Decimal) | 4.4 |
| Ride Height in Inches | 3 3/4 |
| Caster in Degrees (Fraction) | 4 3/32 |
| Caster in Degrees (Decimal) | 4.1 |
| Ride Height in Inches | 4 |
| Caster in Degrees (Fraction) | 3 51/64 |
| Caster in Degrees (Decimal) | 3.8 |
| Ride Height in Inches | 4 1/4 |
| Caster in Degrees (Fraction) | 3 19/32 |
| Caster in Degrees (Decimal) | 3.6 |
| Ride Height in Inches | 4 1/2 |
| Caster in Degrees (Fraction) | 3 19/64 |
| Caster in Degrees (Decimal) | 3.3 |
| Ride Height in Inches | 4 3/4 |
| Caster in Degrees (Fraction) | 3 3/32 |
| Caster in Degrees (Decimal) | 3.1 |
| Ride Height in Inches | 5 |
| Caster in Degrees (Fraction) | 2 29/32 |
| Caster in Degrees (Decimal) | 2.9 |
| Ride Height in Inches | 5 1/4 |
| Caster in Degrees (Fraction) | 2 19/32 |
| Caster in Degrees (Decimal) | 2.6 |
| Ride Height in Inches | 5 1/2 |
| Caster in Degrees (Fraction) | 2 13/32 |
| Caster in Degrees (Decimal) | 2.4 |
| Ride Height in Inches | 5 3/4 |
| Caster in Degrees (Fraction) | 2 13/64 |
| Caster in Degrees (Decimal) | 2.2 |
| Ride Height in Inches | 6 |
| Caster in Degrees (Fraction) | 2 |
| Caster in Degrees (Decimal) | 2.0 |
| (1) Information not available. |
| (1) | Information not available. |
P300 (32) w/HYDROBOOST, w/o 5000-lb. Ft. AXLE
| Application | Specification |
|---|
| Adjustment Procedures | (Scheme 12) |
| Camber in Degrees (Fraction) | 1/4 |
| Camber in Degrees (Decimal) | 0.25 |
| Toe-In in Inches (Fraction) | 1/4 |
| Toe-In in Inches (Decimal) | 0.25 |
| Toe-In In Degrees (Fraction) | 1/2 |
| Toe-In in Degrees (Decimal) | 0.5 |
| Toe-Out on Turns | (1) |
| Steering Axis Inclination (SAI) | (1) |
| Ride Height in Inches | 2 |
| Caster in Degrees (Fraction) | 3 13/64 |
| Caster in Degrees (Decimal) | 3.2 |
| Ride Height in Inches | 2 1/4 |
| Caster in Degrees (Fraction) | 2 29/32 |
| Caster in Degrees (Decimal) | 2.9 |
| Ride Height in Inches | 2 1/2 |
| Caster in Degrees (Fraction) | 2 19/32 |
| Caster in Degrees (Decimal) | 2.6 |
| Ride Height in Inches | 2 3/4 |
| Caster in Degrees (Fraction) | 2 13/32 |
| Caster in Degrees (Decimal) | 2.4 |
| Ride Height in Inches | 3 |
| Caster in Degrees (Fraction) | 2 3/32 |
| Caster in Degrees (Decimal) | 2.1 |
| Ride Height in Inches | 3 1/4 |
| Caster in Degrees (Fraction) | 1 51/64 |
| Caster in Degrees (Decimal) | 1.8 |
| Ride Height in Inches | 3 1/2 |
| Caster in Degrees (Fraction) | 1 1/2 |
| Caster in Degrees (Decimal) | 1.5 |
| Ride Height in Inches | 3 3/4 |
| Caster in Degrees (Fraction) | 1 13/64 |
| Caster in Degrees (Decimal) | 1.2 |
| Ride Height in Inches | 4 |
| Caster in Degrees (Fraction) | 1 |
| Caster in Degrees (Decimal) | 1.0 |
| Ride Height in Inches | 4 1/4 |
| Caster in Degrees (Fraction) | 45/64 |
| Caster in Degrees (Decimal) | 0.7 |
| Ride Height in Inches | 4 1/2 |
| Caster in Degrees (Fraction) | 1/2 |
| Caster in Degrees (Decimal) | 0.5 |
| Ride Height in Inches | 4 3/4 |
| Caster in Degrees (Fraction) | 13/64 |
| Caster in Degrees (Decimal) | 0.2 |
| Ride Height in Inches | 5 |
| Caster in Degrees (Fraction) | 3/32 |
| Caster in Degrees (Decimal) | 0.1 |
| Ride Height in Inches | 5 1/4 |
| Caster in Degrees (Fraction) | 19/64 |
| Caster in Degrees (Decimal) | 0.3 |
| Ride Height in Inches | 5 1/2 |
| Caster in Degrees (Fraction) | 1/2 |
| Caster in Degrees (Decimal) | 0.5 |
| Ride Height in Inches | 5 3/4 |
| Caster in Degrees (Fraction) | 45/64 |
| Caster in Degrees (Decimal) | 0.7 |
| (1) Information not available |
| (1) | Information not available |
P300 (42) w/HYDROBOOST, w/o 5000-lb. Ft. AXLE
| Application | Specification |
|---|
| Adjustment Procedures | (Scheme 13) |
| Camber in Degrees (Fraction) | 13/16 +/- 1/2 |
| Camber in Degrees (Decimal) | 0.81 +/- 0.5 |
| Caster in Degrees (Fraction) | 2 +/- 1/2 |
| Caster in Degrees (Decimal) | 2.0 +/- 0.5 |
| Toe-In in Inches (Fraction) | 3/64 +/- 3/32 |
| Toe-In in Inches (Decimal) | 0.047 +/- 0.10 |
| Toe-In in Degrees (Fraction) | 3/32 +/- 13/64 |
| Toe-In in Degrees (Decimal) | 0.094 +/- 0.203 |
| Toe-Out on Turns | (1) |
| Steering Axis Inclination (SAI) | (1) |
| (1) Information not available. |
| (1) | Information not available. |
WHEEL ALIGNMENT SPECS (S10/15, T10/15, S/T JIMMY, & S/T BLAZER)
Scheme 11
Scheme 12
Scheme 13
