Starting System: Specifications GMC Sonoma II

Starter 7 illustrations

TORQUE SPECIFICATIONS

Application	Ft. Lbs. (N.m)
Axle Mounting Bracket Through Bolt Nut ("C" & "K" Series)	67 (91)
Starter Bracket-To-Engine Bolts (2.2L)	33 (45)
Starter Mounting Bolts	30-37 (40-50)
Battery Cable-to-Solenoid Terminal Nut	12-13 (16-18)
INCH Lbs. (N.m)
Solenoid-To-Starter Bolts & Screws (28-MT)	25-40 (2.8-4.5)
Solenoid "S" Terminal Nut	71-89 (8-10)

TORQUE SPECIFICATIONS

Fig. 12: Starting System Wiring Diagram (Astro & Safari)

Scheme 12: Starting System Wiring Diagram (Astro & Safari)

Fig. 13: Starting System Wiring Diagram (Blazer, Bravada, Envoy, Jimmy, Sonoma & S10 Pickup)

Scheme 13: Starting System Wiring Diagram (Blazer, Bravada, Envoy, Jimmy, Sonoma & S10 Pickup)

Fig. 14: Starting System Wiring Diagram (Express & Savana)

Scheme 14: Starting System Wiring Diagram (Express & Savana)

Fig. 15: Starting System Wiring Diagram (Escalade, Pickup, Suburban, Tahoe & Yukon)

Scheme 15: Starting System Wiring Diagram (Escalade, Pickup, Suburban, Tahoe & Yukon)

Fig. 16: Starting System Wiring Diagram (Forward Control - Commercial Chassis)

Scheme 16: Starting System Wiring Diagram (Forward Control - Commercial Chassis)

Fig. 17: Starting System Wiring Diagram (Forward Control - Motorhome Chassis)

Scheme 17: Starting System Wiring Diagram (Forward Control - Motorhome Chassis)

Fig. 18: Starting System Wiring Diagram (Montana, Silhouette & Venture)

Scheme 18: Starting System Wiring Diagram (Montana, Silhouette & Venture)
