Fuses & Circuit Breakers - "s" Series GMC Sonoma Syclone

FUSE PANEL LOCATIONS

The fuse block is located under the instrument panel to the left of the steering column.

Scheme 1

Fuse & Circuit Breaker Identification

1. 1 - Inst-Lps 5 Amp Instrument Panel Lights, Headlight Warning Buzzer, Rear Defogger Switch Light, Ashtray Light, 4WD Indicator Light, Rear Wiper Switch Light, Foglight Switch Light
2. 2 - Pwr-Accy 30 Amp (Circuit Breaker) Power Door Locks & Rear Defogger, Console Accy. Receptacles Bravada & Typhoon), CD Player (If Equipped), Power Seat (If Equipped), Elec. Shift Transfer Case (If Equipped)
3. 3 - Horn-Dim 20 Amp Horn, Clock & Lighter, Dome & Glove Box Lights, Courtesy & Vanity Mirror Lights, Compass (Bravada), Liftgate Release Solenoid (If Equipped), Fog Lights (1991), Outside Rearview Mirror
4. 4 - Ign-Gau 20 Amp Ignition (1985-87), Indicator Lights & Gauges, Rear Defogger Relay & Timer, A/T Converter Clutch & Cruise Control, RWAL Brake Signal (If Equipped), Seat Belt Timer (If Equipped), A/C Compressor Timer (If Equipped), 4WD Indicator Light (If Equipped)
5. 5 - Choke 20 Amp (1985-87) Choke, Brake 15 Amp (1988-94), Rear/Four Wheel Anti-Lock Brake Module, Digital Radio Adapter Module, Speedometer, Auto. Trans. Converter Clutch
6. 6 - Stop-Haz 15 Amp Stoplights & Hazard Warning Lights, Chime Module (1991-94)
7. 7 - T/L-Ctsy 20 Amp Light Switch, Taillights & Parking Lights, Courtesy Lights, Electronic Cluster (If Equipped)
8. 8 - Turn-B/U 15 Amp Turn Signal & Back-Up Lights
9. 9 - Htr-A/C 25 Amp Heating & A/C
10. 10 - Radio 15 Amp Radio, Tachometer, Rearview Mirror Map Lights, Rear Wiper & Washer, Compass (1993)
11. 11 - ECM B 10 Amp (Exc. 1993-94); 15 Amp (1993-94) Electronic Control Module, Fuel Pump
12. 12 - ECM I 10 Amp Electronic Control Module
13. 13 - Pwr Wdo 30 Amp (Circuit Breaker) Power Windows
14. 14 - Wiper 25 Amp Windshield Wipers & Washers
15. 15 - Crank 3 Amp Electronic Control Module
16. 16 - TCCM 5 Amp (1993-94) Elec. Shift Transfer Case Module
17. 17 - DRL 10 Amp (1993-94) Daytime Running Lights (Canada)

Scheme 2

Fuse & Circuit Breaker Identification

1. A - Pwr-Accy 20 Amp (Circuit Breaker) Power Door Locks
2. B - Pwr-Wdo 30 Amp (Circuit Breaker) Power Windows
3. 1 - Stop-Haz 20 Amp Stoplights & Hazard Warning Lights, Chime Module
4. 2 - Horn-Dim 20 Amp Dome & Glove Box Lights, Lighted Visor Mirror, Horn, I/P Courtesy Light, Power Mirror
5. 3 - T/L-Ctsy 20 Amp Electric Shift Transfer Case Module, Parking Lights, License Plate Light
6. 4 - Gauges 20 Amp Auto Trans., Alternator Field, Variable Throttle Control, A/C Compressor, Cluster, Chime Module, 4WD Indicator Light, Heated O2 Sensor, Daytime Running Lights Module
7. 5 - Not Used
8. 6 - Htr-A/C 25 Amp Blower Motor, Temp. Door Motor
9. 7 - Pwr Aux 25 Amp Power Auxiliary Outlets
10. 8 - Not Used
11. 9 - ECM Batt 15 Amp Engine Computer (Battery), ABS Battery, Fuel Pump
12. 10 - ECM Ign 10 Amp Engine Computer (Ignition), Injectors, Engine Sensors
13. 11 - Radio 20 Amp Radio, Inside Rearview Mirror Map Lights
14. 12 - Not Used
15. 13 - Rdo/Batt 15 Amp Clock, Radio Battery, CD Player
16. 14 - Illum 5 Amp Cluster Illumination, Ash Tray Lamp, Radio Illumination, Heater Lamp, 4WD Illumination, Chime Module, Fog Lamp Sw. Illumination, Daytime Running Lights
17. 15 - DRL 10 Amp Daytime Running Lights (Canada)
18. 16 - Turn-B/U 15 Amp Turn Signal & Back-Up Lights
19. 17 - Wiper 25 Amp Windshield Washers, Windshield Wiper Motor
20. 18 - Brake 15 Amp Speedometer, ABS System, Cruise Control
21. 19 - 4WD 20 Amp Four-Wheel Drive
22. 20 - Not Used
23. 21 - Fog 20 Amp Fog Lamps
24. 22 - Not Used
25. 23 - Not Used
26. 24 - Not Used

FUSE PANEL ID (1995 S-SERIES PICKUP)

Fuse & Circuit Breaker Identification

1. A - Pwr-Accy 20 Amp (Circuit Breaker) Power Door Locks
2. B - Pwr-Wdo 30 Amp (Circuit Breaker) Power Windows
3. 1 - Stop-Haz 20 Amp Stoplights & Hazard Warning Lights, Chime Module
4. 2 - Horn-Dim 20 Amp Dome & Glove Box Lights, Lighted Visor Mirror, Horn, I/P Courtesy Light, Power Mirror
5. 3 - T/L-Ctsy 20 Amp Electric Shift Transfer Case Module, Parking Lights, License Plate Light
6. 4 - Gauges 20 Amp Auto Trans., Alternator Field, Variable Throttle Control, A/C Compressor, Cluster, Chime Module, 4WD Indicator Light, Heated O2 Sensor, Daytime Running Lights Module
7. 5 - ENG1 20 Amp Linear EGR Valve, Evaporative Emissions Canister Purge Solenoid, Heated O2 Sensor #1, Heated O2 Sensor #2, Camshaft Position Sensor, Vehicle Control Module, Powertrain Control Module
8. 6 - Htr-A/C 25 Amp HVAC Select Switch, Air Valve Actuator Motor
9. 7 - Pwr Aux 25 Amp Power Auxiliary Outlets, Data Link Connector
10. 8 - Not Used
11. 9 - ECM Batt 15 Amp Engine Computer (Battery), ABS Battery, Fuel Pump
12. 10 - ECM Ign 10 Amp Engine Computer (Ignition), Injectors, Engine Sensors
13. 11 - Radio 20 Amp Radio, Inside Rearview Mirror Map Lights
14. 12 - Not Used
15. 13 - Rdo/Batt 15 Amp Clock, Radio Battery, CD Player
16. 14 - Illum 5 Amp Cluster Illumination, Ash Tray Lamp, Radio Illumination, Heater Lamp, 4WD Illumination, Chime Module, Fog Lamp Sw. Illumination, Daytime Running Lights
17. 15 - DRL 10 Amp Daytime Running Lights (Canada)
18. 16 - Turn-B/U 15 Amp Turn Signal & Back-Up Lights
19. 17 - Wiper 25 Amp Windshield Washers, Windshield Wiper Motor
20. 18 - Brake 15 Amp Speedometer, ABS System, Cruise Control
21. 19 - 4WD 20 Amp Transfer Case Control Module (Four-Wheel Drive)
22. 20 - CRANK 10 Amp Diagnostic Energy Reserve Module (DERM)
23. 21 - Fog 20 Amp Fog Lamps Relay
24. 22 - Air Bag 10 Amp Air Bag Diagnostic Energy Reserve Module (DERM), Arming Sensor
25. 23 - TRANS 10 Amp Automatic Transmission
26. 24 - PRNDL 10 Amp Instrument Cluster
