Arrows and Symbols
This service manual uses various symbols in order to describe different service operations.
Scheme 2
| Callout | Component Name |
|---|---|
| 1 | Front of Vehicle |
| 2 | View Detail |
| 2 | View Detail |
| 3 | Ambient Air Mixed with Another Gas or Indicate Temperature Change |
| 4 | Motion or Direction |
| 5 | View Angle |
| 6 | Dimension (1:2) |
| 7 | Ambient/Clean Air Flow or Cool Air Flow |
| 8 | Lubrication Point- Oil or Fluid |
| 9 | Task Related |
| 10 | Sectioning (1:3) |
| 11 | Gas Other Than Ambient Air or Hot Air Flow |
| 12 | Lubrication Point- Grease or Jelly |
| 13 | Multidirectional Arrow |
Acronyms and Units
| Acronym | Meaning | Definition |
|---|---|---|
| 2WD | Two-Wheel Drive | Indicates that a vehicle has 2 driven wheels OR that a 4WD vehicle uses only 2 wheels for propulsion. So it can be the description of a vehicle configuration OR the operational mode of the drivetrain. |
| 4WD | Four-Wheel Drive | Four-wheeled vehicle with a drivetrain that allows all four wheels to receive power from the engine simultaneously which provides better control on various surfaces. Can be used to describe the configuration of the vehicle OR as the operational mode of the drivetrain. 4WD vehicles usually can turn 2 wheels off to be in a 2WD mode. See also AWD. |
| A/C | Air Conditioning | The cooling and dehumidification of indoor air for thermal comfort. |
| A/D | Analog to Digital | Used in context of converting electrical analog signals to digital signals. |
| ABS | Antilock Braking System | System on motor vehicles which prevents the wheels from locking while braking which helps the driver maintain control in heavy braking conditions. |
| AC | Alternating Current | An electrical current whose magnitude and direction vary cyclically. |
| AM | Amplitude Modulation | Method of impressing data onto an alternating-current (AC) carrier waveform. |
| APP | Accelerator Pedal Position | A pedal that controls the throttle valve. |
| AWD | All-Wheel Drive | All-wheel-drive systems are designed to function on all types of surfaces, both on- and off-road and most of them cannot be switched off. This can also be called full-time four wheel drive. See also 4WD. |
| AWG | American Wire Gauge | American wire gauge is a standardized wire gauge system used since 1857 predominantly in the United States for the diameters of round, solid, nonferrous, electrically conducting wire. E.g. a wire of AWG10 has a diameter of 2.588mm, AWG20 corresponds to a diameter of 0.812mm. |
| B+ | Battery Positive Voltage | The electrical potential on the positive terminal of the battery. |
| BARO | Barometric Pressure | Atmospheric pressure as measured by a barometer. |
| BCM | Body Control Module | This module supplies vehicle occupants with visual and audible information and controls various vehicle functions |
| BECM | Battery Energy Control Module | Control module used to regulate the battery voltage. |
| BPP | Brake Pedal Position | Position of the foot pedal that moves a piston in the master brake cylinder. |
| CAN | Controller Area Network | Serial data connection between control modules by Bosch |
| CCM | Chassis Control Module | The module that controls various vehicle functions on the Chassis, like Engine/Trans Mount, Active Grille Air Shutter, Load Leveling, etc |
| CD | Compact Disc | A small optical disk on which data such as music, text or graphic images is digitally encoded. |
| CNG | Compressed Natural Gas | This a substitute for gasoline or diesel fuel. It is made by compressing natural gas (which is mainly composed by methane (CH4), in a percentage range of 70% to 98%) |
| CO | Carbon Monoxide | This is a product of the incomplete combustion of carbon-containing compounds, at room temperature this is a gas. It consists of one carbon atom covalently bonded to one oxygen atom. |
| CO2 | Carbon Dioxide | Chemical compound composed of two oxygen atoms covalently bonded to a single carbon atom. |
| CPA | Connector Position Assurance | Part of an electrical connector that prevents the connector from moving out of its socket. Usually needs to be pressed to unlock the connector when disconnecting it. |
| CPP | Clutch Pedal Position | A lever operated with the foot that controls the coupling that connects or disconnects driving and driven parts of a driving mechanism. |
| CV | Constant Velocity | Used in conjunction with CV joints, which connect two shafts at an angle while both shafts always have the same rotational speed without variations. |
| CVT | Continuously Variable Transmission | A transmission in which the ratio of the rotational speeds of two shafts, as the input shaft and output shaft of a vehicle or other machine, can be varied continuously within a given range, providing an infinite number of possible ratios which improves fuel economy. |
| D | Drive | D on the transmission gear selector lever. |
| DAB | Digital Audio Broadcast | Technology for broadcasting of audio using digital radio (carries information via digital signal) transmission. |
| DC | Direct Current | Continuous current, constant flow of electric charge. |
| DLC | Data Link Connector | This is an electronic connector typically located underneath the driver's side dashboard, just above the pedals. The connector has 16 pins. |
| DMM | Digital Multimeter | Electronic measuring instrument that combines several functions in one unit. The most basic instruments include an ammeter, voltmeter and ohmmeter. |
| DOHC | Dual Overhead Camshaft | Dual overhead camshafts (DOHC) are higher performance engines, they produce more power and can run at higher speeds because they allow an engine to have four valves per cylinder. Each camshaft operates two of the valves, one camshaft handles the intake valves and one handles the exhaust valves |
| DPF | Diesel Particulate Filter | Device designed to remove diesel particulate matter or soot from the exhaust gas of a diesel engine. |
| DRL | Daytime Running Lamps | White lights mounted on the front of an automobile that automatically switch on when the key is turned and are intended for daytime use, to increase the visibility of the automobile. |
| DSCC | Distance Sensing Cruise Control | A type of cruise control that automatically maintains the distance between vehicles. |
| DSP | Digital Signal Processor | A specialized microprocessor designed specifically for digital signal processing, generally in real-time computing. |
| DTC | Diagnostic Trouble Code | An electronic signal stored in an automotive computer, indicating the presence of a fault detected by that computer. |
| DVD | DVD | A popular optical disc storage media format the size of a CD. Used mainly for movies but also for data. DVD has no spelled out version (officially it does not mean Digital Video Disc or Digital Versatile Disc, it just means DVD). |
| EBCM | Electronic Brake Control Module | This module contains a microprocessor and software for antilock braking system operation. |
| ECM | Engine Control Module | This electronic module works with a vehicle's sensors and engine control devices to insure that the engine operates at maximum efficiency and performance. It performs three vital functions. Receives electronic signals from engine sensors. Analyzes the data and makes an engine performance decision (based on the pre-set parameters within the unit). Sends an "output command" to an actuator that adjusts engine performance. |
| ECT | Engine Coolant Temperature | A measure of how hot or cold the fluid which flows through the engine in order to prevent its overheating, transferring the heat produced by the device to other devices that utilize or dissipate it. |
| EEPROM | Electrically Erasable Programmable Read-Only Memory | A non-volatile storage chip used in computers and other devices to store small amounts of volatile data, e.g. calibration tables or device configuration. |
| EGR | Exhaust Gas Recirculation | Is an NOx (nitrogen oxide and nitrogen dioxide) reduction technique used in most gasoline and diesel engines. EGR works by recirculating a portion of an engine's exhaust gas back to the engine cylinders. |
| EMI | Electromagnetic Interference | Electromagnetic interference (also called radio frequency interference) is a disturbance that affects an electrical circuit due to either electromagnetic conduction or electromagnetic radiation emitted from an external source. |
| ESD | Electrostatic Discharge | The sudden and momentary electric current that flows between two objects at different electrical potentials. |
| EV | Electric Vehicle | A category of vehicles that only have an electric drive system. |
| EVAP | Evaporative Emission | A system that controls the fuel fumes in the fuel tank. |
| FM | Frequency Modulation | In telecommunication this is a way to convey information over a carrier wave by varying its frequency. |
| FWD | Front-Wheel Drive | A form of engine/transmission layout used in motor vehicles, where the engine drives the front wheels only. |
| GMLAN | General Motors Local Area Network | A local-area network is a computer network covering a small geographic area, like a home or vehicle. This specific type of LAN connects several controllers inside the vehicle and was developed by General Motors. |
| GPS | Global Positioning System | Satellite-based navigation system made up of a network of 24 satellites placed into orbit by the U.S. Department of Defense. |
| GSM | Global System for Mobile Communications | Globally accepted standard for digital cellular communication. |
| GVW | Gross Vehicle Weight | Maximum total weight of a road vehicle or trailer that is loaded, including the weight of the vehicle itself plus fuel, passengers, cargo and trailer tongue weight. |
| HD | Heavy Duty | Robust design to accommodate large work loads. |
| HID | High Intensity Discharge | A type of light that produces a bright light by using gas filled bulbs. (gas is usually mercury, metal halide and high-pressure sodium) Uses very little battery power and is a very "cool" light. |
| HO2S | Heated Oxygen Sensor | Heated oxygen sensors have an internal heater circuit that brings the sensor up to operating temperature more quickly than an unheated sensor. An oxygen sensor must be hot (about 600-650°F) before it will generate a voltage signal. The hot exhaust from the engine will provide enough heat to bring an O2 sensor up to operating temperature. |
| HVAC | Heating Ventilation Air Conditioning | This system is sometimes referred to as climate control. Ventilation air ducts installed throughout a vehicle that supply conditioned air to a room through rectangular or round outlet vents. |
| I 2 C | Inter-Integrated Circuit | Serial data connection between Integrated Circuits (microchips) inside a control module invented by Phillips |
| IAT | Intake Air Temperature | Temperature of the air entering intake air flow system of the engine. |
| ICE | Internal Combustion Engine | An engine in which the combustion of fuel and an oxidizer (typically air) occurs in a confined space called a combustion chamber. |
| ID | Identification | Number or Code that identifies a component or control module. Can be written on the part or be transmitted on a bus or via radio. |
| ISP | Internet Service Provider | A company that furnishes corporations and individual consumers with various services, mainly access to the Internet. |
| ISS | Input Shaft Speed | Rotational speed of the input shaft of a transmission. |
| LAN | Local Area Network | Standard network connection PC's. |
| LCD | Liquid Crystal Display | A thin, flat display device made up of any number of color or monochrome pixels arrayed in front of a light source or reflector. |
| LED | Light Emitting Diode | Small light bulbs that fit easily into an electrical circuit they do not have a filament that will burn out and they do not get especially hot. They are illuminated solely by the movement of electrons in a semiconductor material. |
| LIN | Local Interconnect Network | Computer networking bus system used within automotive network architectures. Similar to CAN, but cheaper and less powerful. |
| LPG | Liquefied Petroleum Gas | A mixture of mainly propane and butane, produced commercially and stored under pressure to keep it in a liquid state. |
| MAF | Mass Air Flow | The amount of air drawn into the engine |
| MAP | Manifold Absolute Pressure | Pressure in the engine intake system after the throttle valve referenced to a perfect vacuum. |
| MDI | Multiple Diagnostics Interface | A device used by GM dealers that enables a PC to communicate with the control modules in a vehicle. |
| MIL | Malfunction Indicator Lamp | An indicator of the internal status of a car engine. |
| MOST | Media Oriented Systems Transport | Serial communication bus to transmit audio and video information. |
| N | Neutral | A state of the transmission in which it is not engaged. |
| NiMH | Nickel Metal Hydride | A type of rechargeable battery that uses a hydrogen absorbing alloy for the negative electrode. |
| NOx | Nitrogen Oxides | Refers to any of the following oxygen compounds of nitrogen or a mixture of them. Nitric Oxide, Nitrogen dioxide, Nitrous Oxide, Dinitrogen trioxide, Dinitrogen tetroxide, Dinitrogen pentoxide. |
| O2 | Oxygen | A colorless, odorless, tasteless, gaseous chemical element with the chemical symbol O and atomic number 8. |
| O2S | Oxygen Sensor | An electronic device that measures the proportion of oxygen (O2) in the gas or liquid being analyzed. |
| OBD | On-Board Diagnostic | A generic term referring to a vehicle's self-diagnostic and reporting capability. |
| OEM | Original Equipment Manufacturer | A producer that provides a product to its customers, who proceed to modify or bundle it before distributing it to their customers. |
| OSS | Output Shaft Speed | Rotational speed of the output shaft of a transmission. |
| P | Park | A state in which the transmission is set so one can leave the vehicle. |
| PCB | Printed Circuit Board | A thin plate on which chips and other electronic components are placed. |
| PCM | Powertrain Control Module | A control module that features the functions of both, the engine and the transmission control module. |
| PCMCIA | Personal Computer Memory Card Industry Association | An international standards body and trade association with over 100 member companies that was founded in 1989 to establish standards for Integrated Circuit cards and to promote interchangeability among mobile computers where ruggedness, low power and small size were critical. |
| PIN | Personal Identification Number | A secret numeric password shared between a user and a system that can be used to authenticate the user to the system. |
| PPE | Personal Protective Equipment | Protective clothing, helmets, goggles or other garment designed to protect the wearer's body from injury. |
| PRNDL | Park, Reverse, Neutral, Drive, Low | Park, Reverse, Neutral, Drive, Low (automatic transmission positions). |
| PTC | Positive Temperature Coefficient | Refers to materials that experience an increase in electrical resistance when their temperature is raised. |
| PTO | Power Take-Off | A splined driveshaft, usually on a tractor or truck that can be used to provide power to an attachment or separate machine. This mechanism allows implements to draw energy from the tractor's engine. |
| PVC | Polyvinyl Chloride | A thermoplastic copolymer. |
| PWM | Pulse Width Modulation | Square shaped type of signal that carries the information in the ratio between on and off times. |
| R | Reverse | Rearward: directed or moving toward the rear |
| RAM | Random Access Memory | A type of computer data storage. It today takes the form of integrated circuits that allow the stored data to be accessed in any order. |
| RCT | Radiator Coolant Temperature | This is the heat intensity of the radiator coolant measured in degrees. The radiator is a part of the cooling system that removes the engine heat. Coolant is a mixture of water and antifreeze (ethylene glycol) which lowers the freezing point of the water in the coolant system, this fluid also picks up heat from the engine and transfers it to the air. |
| RDS | Radio Data System | A standard from the European Broadcasting Union for sending small amounts of digital information using conventional FM radio broadcasts. |
| RF | Radio Frequency | A frequency or rate of oscillation within the range of about 3 Hz and 300 GHz. This range corresponds to frequency of alternating current electrical signals used to produce and detect radio waves. |
| ROM | Read-Only Memory | A class of storage media used in computers and other electronic devices. Data stored in ROM cannot be modified. |
| RPO | Regular Production Option | A three digit/letter code given to parts, assemblies and systems originally installed on the vehicle. These RPO codes designate options and are assigned by General Motors. |
| RSA | Rear Seat Audio | An auxiliary set of controls that operate the main audio system from the rear seat. Rear passengers can also operate a different media source than the front passengers. |
| RWD | Rear-Wheel Drive | A common engine/transmission layout in which the engine is in the front of the vehicle, but the front mid-engine, rear mid-engine and rear engine layouts are also used. |
| SCV | Speed Controlled Volume | The volume control is set for a desired sound level in the vehicle as the vehicle increases its speed, the sound level is adjusted. |
| SDM | Sensing and Diagnostic Module | The name given to air bag modules used in General Motors vehicles. |
| SIM | Subscriber Identity Module | Part of a removable smart card Integrated Circuit Card. This is used for mobile cellular telephone devices such as mobile computers and mobile phones. SIM cards securely store the service-subscriber key used to identify a subscriber. The SIM card allows users to change phones by simply removing the SIM card from one mobile phone and inserting it into another mobile phone or broadband telephony device. |
| SIR | Supplemental Inflatable Restraint | Technical term for the air bag. Air bag is a stretchable membrane, which inflates during an automobile accident to provide cushioning to the passenger's head and torso to prevent injury to the passengers. |
| SPI | Serial Peripheral Interface | This is an interface that enables the serial (one bit at a time) exchange of data between two devices. An SPI operates in full duplex mode. This means that data can be transferred in both directions at the same time. It is a standard bus technology like CAN or I2C. |
| SPS | Service Programming System | System that enables repair facilities to update the software in control modules. |
| SUV | Sport Utility Vehicle | A passenger vehicle which combines the towing capacity of a pickup truck with the passenger-carrying space of a minivan. |
| SVS | Service Vehicle Soon | Indicator lamp or symbol for a malfunction related to a vehicle component or system. |
| TA | Traffic Announcement | Message spoken on radio regarding the movement of vehicles or pedestrians through an area or along a route. The buttons on radios that enable this announcements are also often labeled TA. |
| TAC | Throttle Actuator Control | A motor which moves the engine throttle plate or valve, controlled by the engine control module. A throttle plate limits the amount of air entering a internal combustion gasoline engine. |
| TAP | Transmission Adaptive Pressure | The transmission control module learns each component's characteristics and adjusts fluid pressure accordingly. |
| TCC | Torque Converter Clutch | Resides in a torque converter to connect an engine to an automatic transmission. The clutch is applied when conditions are correct to achieve a 1:1 ratio of engine crankshaft to transmission input shaft. |
| TCM | Transmission Control Module | A module that controls electronic automatic transmissions. It uses sensors from the vehicle as well as data provided by the Engine Control Module to calculate how and when to change gears in the vehicle for optimum performance, fuel economy and shift quality. |
| TDC | Top Dead Center | The piston is in its highest position relative to the combustion chamber. |
| TIS | Techline Information System | The PC-based global dealership diagnostic software that provides the technician the ability to reference the most recent service information via the service department's computer. |
| TPA | Terminal Position Assurance | An additional locking mechanism inside an electric connector that holds the pins in place. |
| TV | Television | A telecommunication system for broadcasting and receiving moving pictures and sound over a distance. |
| USB | Universal Serial Bus | A type of communication bus connection between a computer and a peripheral device. |
| VCI | Vehicle Communications Interface | A diagnostic tool that communicates to modules of multiple communication protocols in a vehicle by converting vehicle serial data into PC serial data communication. |
| VIN | Vehicle Identification Number | Used by manufacturers to uniquely identify motor vehicles using 17 characters. |
| VSCM | Vehicle Stability Control Module | This module uses information from several sensors to detect a loss of vehicle traction, then works with the antilock brake system to apply individual brakes to help keep the vehicle on its intended path. |
| VSS | Vehicle Speed Sensor | Sends data regarding how fast the car is traveling at the moment of driving. It is designed to be able to record the rate at which the vehicle's crankshaft is spinning. |
| WOT | Wide Open Throttle | When the throttle blade or valve is at its maximum open position, allowing maximum air to enter an internal combustion gasoline engine. |
| WLAN | Wireless Local Area Network | Standard to transmit digital data via radio frequency. |
| XM | XM (Satellite Radio) | XM Satellite Radio Holdings (XM) is one of two satellite radio services in the United States and Canada. XM provides pay-for-service radio, analogous to cable television. Its service includes 73 different music channels, 39 news, sports, talk and entertainment channels, 21 regional traffic and weather channels and 23 play-by-play sports channels (2008). |
| XML | Extensible Markup Language | A markup language that defines a set of rules for encoding documents in a format that is both human-readable and machine-readable. |
Acronyms
| Unit | Meaning | Definition |
|---|---|---|
| M 2 | Square Meter | Area |
| A | Ampere | Electrical |
| Ah | Ampere Hour | Electrical |
| C | Coulomb | Electrical |
| DBm | Decibel Meter | Electrical |
| DBmV | Decibel Millivolt | Electrical |
| MV/DIV | Millivolts per Division | Electrical |
| MV/s | Millivolts per Second | Electrical |
| Ohms | Ohm | Electrical |
| V | Volt | Electrical |
| V/DIV | Volts per Division | Electrical |
| V/ms | Volts per Millisecond | Electrical |
| W | Watt | Electrical |
| Mm 3 /stroke | Cubic Millimeters per Stroke | Flow |
| Gal/h | Gallons per Hour | Flow |
| G/s | Grams per second | Flow |
| G/stroke | Grams per Stroke | Flow |
| Kg/100km | Kilograms per 100 Kilometer | Flow |
| Kg/h | Kilograms per Hour | Flow |
| Km/L | Kilometer/liter | Flow |
| L/100km | Liters per 100 Kilometers | Flow |
| L/h | Liters per Hour | Flow |
| L/min | Liters per Minute | Flow |
| MPG | Miles per Gallon | Flow |
| Mg/s | Milligrams per Second | Flow |
| Mg/stroke | Milligrams per stroke | Flow |
| Ft | Feet | Length |
| In | Inch | Length |
| M | Meter | Length |
| Mi | Mile | Length |
| Bar | Bar | Mechanical |
| Bar/min | Bars per Minute | Mechanical |
| In. H2O | Inches of Water | Mechanical |
| In. H2O/s | Inches of Water per second | Mechanical |
| KPa/s | Kilopascals per Second | Mechanical |
| N | Newton | Mechanical |
| Newton Meter | Mechanical | |
| Pa | Pascal | Mechanical |
| Pa/s | Pascals per Second | Mechanical |
| Lb ft | Pound Foot | Mechanical |
| PSI | Pound-Force per Square Inch | Mechanical |
| Counts | Counts | Misc. |
| Cycles | Cycles | Misc. |
| DB | Decibel | Misc. |
| ° | Degree | Misc. |
| °C | Degree Centigrade | Misc. |
| °CA | Degree Crankshaft Angle | Misc. |
| °F | Degree Fahrenheit | Misc. |
| °/s | Degree per Second | Misc. |
| Hz | Hertz | Misc. |
| Kbit/s | Kilobit per second | Misc. |
| Lx | Lux | Misc. |
| Ppm | Parts per Million | Misc. |
| % | Percent | Misc. |
| %/min | Percents per Minute | Misc. |
| %/sec | Percents per Second | Misc. |
| Pulses | Pulses | Misc. |
| 1 | Ratio | Misc. |
| RPM | Revolutions per Minute | Misc. |
| Steps | Steps | Misc. |
| W/m 2 | Watts per Square Meter | Misc. |
| G | G (Acceleration) | Movement |
| Km/h | Kilometers per Hour | Movement |
| M/s | Meters per Second | Movement |
| M/s 3 | Meters per Second Cubed | Movement |
| M/s 2 | Meters per Second Squared | Movement |
| MPH | Miles per Hour | Movement |
| Mm/s | Millimeters per Second | Movement |
| D | Day | Time |
| H | Hour | Time |
| Hh:mm:ss | Hour:Minute:Second | Time |
| Ms/DIV | Milliseconds per Division | Time |
| Min | Minute | Time |
| S | Second | Time |
| S/DIV | Seconds per Division | Time |
| Yy-mm-dd | Year-Month-Day (2 digits) | Time |
| Yyyy-mm-dd | Year-Month-Day (4 digits, preferred) | Time |
| M 3 | Cubic Meter | Volume |
| Gal | Gallon | Volume |
| L | Liter | Volume |
| ML | Milliliters | Volume |
| US gal | US Gallon | Volume |
| US pt | US Pint | Volume |
| US qt | US Quart | Volume |
| Kg | Kilogram | Weight |
Units
Customer Concern Verification Sheets
The GM Customer Concern Verification Sheets have been designed to improve communications between the service customer and the technician. The more clearly the technician understands the concern and its symptoms, the more likely the concern will be fixed right the first time.
The GM-wide Customer Concern Verification Sheets are available in GM GlobalConnect. The Customer Concern Verification Sheets may be printed and reproduced locally.
Dealers
All U.S. GM Dealers participating in the Center of Learning / GM Service Technical College (STC) Programs can enroll through the Center of Learning website at https://www.centerlearning.com. Within the website, there are individual training paths that are designed to assist in planning the training needs for each individual and their job role. Dealers who have questions about Center of Learning Training should contact the Center of Learning help desk at 1-888-748-2687. The help desk is available Monday through Friday, 8:00 am - 9:00 pm Eastern Standard Time, excluding holidays. For GM Access support, contact the GM Access Help Desk at 1-888-337-1010.
Fleets
GM Fleet customers with GM Warranty In-Shop agreements are able to participate in service technical training through the Center of Learning/GM Service Technical College (STC).
Assistance for GM fleet registered customers using GM STC training is provided by the Center of Learning help desk at 1-888-748-2687. The help desk is available Monday through Friday, 8:00 am-9:00 pm Eastern Standard Time, excluding holidays. For GM Access support, contact the GM Access Help Desk at 1-888-337-1010.
Most GM STC course materials have associated charges.
To purchase authentic GM STC Training Materials, contact the GM Training Materials Headquarters at 1-800-393-4831.
Non-GM Dealer Technicians
Technician training for non-GM dealers is available through ACDelco. This training is for ACDelco PSC and Fleet program members employed in the automotive or truck service industry.
ACDelco courses are available at approved GM STC Training Centers. Availability and schedules can be obtained by calling 1-800-825-5886 (prompt 1) or contact us via the web at www.acdelcotechconnect.com and select the Training tab. Seminars are also offered through the ACDelco Warehouse Distribution channel. Contact your Local ACDelco representative or distributor directly for more information.
Scheme 3
The vehicle identification number (VIN) plate is the legal identifier of the vehicle. The VIN plate is located on the upper left corner of the instrument panel. The VIN number can be seen through the windshield from the outside of the vehicle
| Position | Definition | Character | Description |
|---|---|---|---|
| 1 | Country of Origin | 1 | United States |
| 3 | Mexico | ||
| 2 | Manufacturer | G | General Motors |
| 3 | Make | C | Chevrolet Truck |
| T | GMC Truck | ||
| 4 | GVWR/Brake System/Body Style | N | 6, 001-7, 000 lbs/Hydraulic/Standard Cab |
| P | 6, 001-7, 000 lbs/Hydraulic/Crew Cab | ||
| R | 6, 001-7, 000 lbs/Hydraulic/Extended Cab | ||
| U | 7, 001-8, 000 lbs/Hydraulic/Crew Cab | ||
| V | 7, 001-8, 000 lbs/Hydraulic/Extended Cab | ||
| 0 | 9, 001-10, 000 lbs/Hydraulic/Standard Cab | ||
| 1 | 9, 001-10, 000 lbs/Hydraulic/Crew Cab | ||
| 2 | 9, 001-10, 000 lbs/Hydraulic/Extended Cab | ||
| 3 | 10, 001-14, 000 lbs/Hydraulic/Standard Cab | ||
| 4 | 10, 001-14, 000 lbs/Hydraulic/Crew Cab | ||
| 5 | 10, 001-14, 000 lbs/Hydraulic/Extended Cab | ||
| 5 | Line Chassis | C | 4x2 |
| 1 | |||
| K | 4x4 | ||
| 2 | |||
| 6 | Series | P | 1/2 ton Silverado Work Truck/Fleet/Base |
| R | 1/2 ton Silverado LT | ||
| S | 1/2 ton Silverado LTZ | ||
| T | 1/2 ton Silverado High Country 1/2 ton Sierra Work Truck/Fleet/Base | ||
| U | 3/4 ton Silverado Work Truck/Fleet/Base 1/2 ton Sierra SLE | ||
| V | 3/4 ton Silverado LT 1/2 ton Sierra SLT | ||
| W | 1/2 ton Sierra Denali | ||
| X | 3/4 ton Silverado LTZ 3/4 ton Sierra Work Truck/Fleet/Base | ||
| Y | 1 ton Silverado Work Truck/Fleet/Base 3/4 ton Sierra SLE | ||
| Z | 1 ton Silverado LT 3/4 ton Sierra SLT | ||
| 0 | 1 ton Silverado LTZ 3/4 ton Sierra Denali | ||
| 1 | 1 ton Sierra Work Truck/Fleet/Base | ||
| 2 | 1 ton Sierra SLE | ||
| 3 | 1 ton Sierra SLT | ||
| 4 | 1 ton Sierra Denali | ||
| 9 | Export Only | ||
| 7 | Restraint System | C | Active Manual Belts, Airbag - Driver & Passenger - Front (1st row) |
| E | Active Manual Belts, Airbag - Driver & Passenger - Front (1st row), Front Seat Side (1st row) and Roof Side (all seating rows) | ||
| 8 | Engine Type | B | RPO LC8, Engine Flexible Fuel, (CNG/LGP), 8 Cyl, V8, 6.0L, SFI |
| C | RPO L83, Engine Gas, 8 Cylinder, 5.3L, SIDI VVT, AFM, E85 MAX, Aluminum | ||
| G | RPO L96, (Gas/Ethanol), 8 Cylinder, 6.0L, SFI, Iron | ||
| H | RPO LV3. Engine Gas, 6 Cylinder, 4.3L, SIDI, V6, VVT, OHV, E85 MAX, Aluminum | ||
| J | RPO L86, Engine Gas, 8 Cylinder, 6.2L, SIDI VVT, AFT, E85 MAX, Aluminum | ||
| P | RPO LV1, Engine Gas, 6 Cylinder, 4.3L, SIDI, V6, VVT, E85 MAX | ||
| 8 | RPO LML, Engine - Diesel, 8 Cylinder, 6.6L, PTI, V8, Turbo, Duramax | ||
| 9 | Check Digit | Check Digit | |
| 10 | Model Year | E | 2014 |
| 11 | Plant Location | F | Flint, Michigan, USA |
| Z | Fort Wayne, Indiana, USA | ||
| G | Silao, Mexico | ||
| 12-17 | Plant Sequence Number | Plant Sequence Number |
Vehicle Identification Number (VIN) System
4.3L (LV3) Engine ID and VIN Derivative Location
Refer to Engine Identification .
5.3L (L83), 6.0L (L96), 6.2L (L86) Engine ID and VIN Derivative Location
Refer to .
6.0L (LC8) Engine ID and VIN Derivative Location
Refer to .
6.6L (LML, LV1) Engine ID and VIN Derivative Location
Refer to .
6L50/6L80/6L90 Transmission ID and VIN Derivative Location
Refer to Transmission Identification Information .
Allison Transmission ID and VIN Derivative Location
Refer to .
Scheme 4
| Callouts | Description |
|---|---|
| Vehicle Certification Label The vehicle certification label is located on the driver door and displays the following assessments: Gross Vehicle Weight Rating (GVWR) Gross Axle Weight Rating (GAWR), front and rear The gross vehicle weight (GVW) is the weight of the vehicle and everything it carries. The gross vehicle weight must not exceed the GVWR. Include the following items when figuring the GVW: The base vehicle weight (factory weight) The weight of all vehicle accessories The weight of the driver and the passengers The weight of the cargo | |
| 1 | Name of Manufacturer |
| 2 | Gross Vehicle Weight Rating |
| 3 | Gross Axle Weight Rating (Front, Rear) |
| 4 | Canadian Safety Mark (w/RPO Z49) |
| 5 | Certification Statement |
| 6 | Vehicle Class Type (Pass Car, etc.) |
| 7 | Vehicle Identification Number |
| 8 | Date of Manufacture (Mo/Yr) |
| Tire Placard The tire placard label is located on the driver side B pillar and displays the following assessments | |
| 9 | Specified Occupant Seating Positions |
| 10 | Maximum Vehicle Capacity Weight |
| 11 | Tire Pressure, Front, Rear and Spare (Cold) |
| 12 | Original Equipment Tire Size |
| Service Parts ID Label The vehicle service parts identification label is located in the instrument panel (I/P) compartment. The label is use to help identify the vehicle original parts and options. | |
| 13 | Vehicle Identification Number |
| 14 | Engineering Model Number (Vehicle Division, Line and Body Style) |
| 15 | Interior Trim Level and Decor |
| 16 | Exterior (Paint Color) WA Number |
| 17 | Paint Technology |
| 18 | Special Order Paint Colors and Numbers |
| 19 | Vehicle Option Content |
| Anti-Theft Label | |
| 20 | The Federal law requires that General Motors label certain body parts on this vehicle with the VIN. The purpose of the law is to reduce the number of motor vehicle thefts by helping in the tracing and recovery of parts from stolen vehicles. Labels are permanently affixed to an interior surface of the part. The label on the replacement part contains the letter R, the manufacturer's logo and the DOT symbol. The anti-theft label must be covered before any painting and rustproofing procedures and uncovered after the procedures. Failure to follow the precautionary steps may result in liability for violation of the Federal Vehicle Theft Prevention Standard and possible suspicion to the owner that the part was stolen. |
Vehicle Certification, Tire Placard, Anti-Theft and Service Parts ID Label
RPO Code List (Light Duty)
| RPO | Description |
|---|---|
| The production/process codes provide the description of the Regular Production Options (RPOs). The RPO list is printed on the Service Parts Identification Label. | |
| 4AA | Interior Trim - Jet Black |
| 4D7 | Interior Trim - Jet Black, Dark Ash |
| 4DP | Interior Trim - Cocoa/Dune |
| 4EX | Interior Trim - Mink |
| 4GB | Interior Trim - Jet Black/Cobalt Red |
| 5AZ | Accessory - Safety Kit - Universal |
| 5JY | Accessory - Tonneau - Rear Compartment - Soft Folding |
| 5VI | Accessory - Tie Down Rings - Cargo Area |
| 5Y3 | Accessory - Tow Ball - Trailer Hitch |
| 9L7 | Equipment - Accessory Wiring Junction Block |
| A31 | Window - Power Operated, All Doors |
| A45 | Memory - Seat Adjuster, Mirror, Power, Driver, Personalization |
| A48 | Window Rear - Full Width, Sliding, Power |
| A52 | Seat - Front Bench |
| A60 | Lock Control Rear Compartment - Lid, Tailgate, Key Activated |
| A68 | Seat Rear - Split, Folding |
| A95 | Seat - Front Bucket, High Back, Driver and Passenger Recliner |
| AE7 | Seat - Front Split, Driver, Passenger |
| AG1 | Adjuster Front Seat - Power, Multi-Directional, Driver |
| AKO | Window Type - Privacy |
| AKP | Window Type - Solar Absorbing |
| AL0 | Sensor Indicator - Inflatable Restraint, Front Passenger/Child Presence Detector |
| AM7 | Seat Rear - Folding |
| AN3 | Seat - Front, Individual, Non-Bucket |
| AQQ | Lock Control, Entry - Remote Entry, Extended Range (Model Year 09 and Future) |
| AU3 | Lock Control - Side Door, Electronic |
| AXK | Vehicle Type Truck |
| AY0 | Restraint System - Seat, Inflatable, Driver and Passenger Front, Seat Side, Roof Side |
| AZ3 | Seat - Front Split, Driver, Passenger, Full Feature Center |
| B1J | Liner - Rear Wheelhouse |
| B30 | Floor Covering - Carpet |
| B32 | Covering Front - Floor Mats, Auxiliary |
| B33 | Covering Rear - Floor Mats, Auxiliary |
| B3F | Seat - Front Split, Deluxe, Driver, Passenger, Full Feature Center |
| B58 | Covering - Floor Mat, Front and Rear, Carpeted Insert |
| B85 | Molding Bodyside - Exterior, Bright |
| B86 | Molding Bodyside - Body Color |
| BAG | Parts Package - Export |
| BG9 | Covering - Floor, Rubber |
| BTV | Remote Start - Engine |
| BVQ | Steps, Runningboard - Side, Tubular, Chrome |
| BWN | Steps - Corner Assist, Bumper |
| C42 | HVAC System - Heater, Outside Air, Deluxe |
| C49 | Defogger - Rear Window, Electric |
| C67 | HVAC System - Air Conditioner Front, Electronic Controls |
| C9I | Switch - Roll Over Sensing |
| CF5 | Roof - Sun, Glass, Sliding, Electric |
| CJ2 | HVAC System - Air Conditioner Front, Automatic Temperature Control, Auxiliary Temperature Control |
| CL5 | Country - Peru |
| CL6 | Country - Bolivia |
| CMD | Plant Code - Flint, MI, USA (TRK) |
| CTD | Equipment - Cargo Tie Down (Movable) |
| CU7 | Country - Kuwait |
| CU8 | Country - Saudi Arabia |
| CV3 | Country - Mexico |
| CV6 | Country - Chile |
| CW2 | Country - Gulf Areas (Bahrain, Kuwait, Oman, Qatar, Saudi Arabia, UAE) |
| CW9 | Country - Miscellaneous |
| CX3 | Country - Ecuador |
| CX9 | Country - Lebanon |
| CY2 | Country - Jordan |
| D07 | Console - Front Compartment, Floor, Custom |
| D2D | County - Philippines |
| D75 | Handle Outside Door - Body Color |
| DD8 | Mirror Inside Rearview - Light Sensitive |
| DE2 | Mirror Outside - Left and Right, Manual Control, Folding, Color |
| DF2 | Mirror Outside - Left and Right, Wide Load, Folding, Stainless Steel |
| DH6 | Mirror Inside Front Vanity - Left and Right, Sunshade, Illuminated |
| DL3 | Mirror Outside - Left and Right, Remote Control, Electric, Heated, Power Folding, Turn Signal Indicator, Light Sensitive, Color |
| DL8 | Mirror Outside - Left and Right, Remote Control, Electric, Heated |
| DP6 | Mirror Provisions - Housing, Painted |
| DP9 | Mirror Provisions - Housing, Chrome |
| DPN | Mirror Outside - Left and Right, Wide Load, Vertical Glass, Manual Extending, Manual Folding, Heated, Turn Signal Indicator, Remote Control |
| DT4 | Ashtray - Cigarette Lighter |
| E20 | Handle Outside Door - Chrome |
| E29 | Equipment - Modification Base Equipment |
| E5D | Accessory - Assist Handles - Interior |
| E63 | Body Equipment - Fleetside, Pick-up Box |
| EF7 | Country United States of America (USA) |
| EXP | Export |
| F60 | Spring Front - Heavy Duty |
| FE9 | Certification - Emission, Federal |
| FHO | Vehicle Fuel - Gasoline E10 |
| FHS | Vehicle Fuel - Gasoline E85 |
| FWI | Plant Code - Fort Wayne, IN, USA |
| G56 | Primary Color - Exterior, Stealth Gray Metallic 928L |
| G80 | Axle Positraction - Limited Slip |
| GAJ | Appearance Package - Chevrolet Premium Package |
| GAN | Primary Color - Exterior, Switchblade Silver Metallic (G) 636R |
| GAT | Appearance Package - GMC All Terrain |
| GAZ | Primary Color - Exterior, Summit White (G) 8624 |
| GBA | Primary Color - Exterior, Black (G) 8555 |
| GBN | Primary Color - Exterior, White Diamond Tricoat (G) 800J |
| GCE | Primary Color - Exterior, Sonoma Jewel Metallic (412P) |
| GCN | Primary Color - Exterior, Victory Red 9260 |
| GT4 | Axle Rear - 3.73 Ratio |
| GT5 | Axle Rear - 4.10 Ratio |
| GTS | Primary Color - Exterior, Luxo Blue Metallic (933L) (44U) |
| GU4 | Axle Rear - 3.08 Ratio |
| GU5 | Axle Rear - 3.23 Ratio |
| GU6 | Axle Rear - 3.42 Ratio |
| GWX | Primary Color - Exterior, Subterranean Metallic (105V) |
| GXG | Primary Color - Exterior, Iridium Metallic (121V) |
| H0K | Interior Trim Configuration - Leather, Level 3, Cocoa/Dune |
| H0U | Interior Trim Configuration - Cloth, Level 2, Jet Black |
| H1Y | Interior Trim Configuration - Leather, Level 2, Jet Black |
| H2Q | Interior Trim Configuration - Vinyl, Level 1, Jet Black/Dark Ash |
| H2R | Interior Trim Configuration - Cloth, Level 1, Jet Black/Dark Ash |
| H2S | Interior Trim Configuration - Cloth, Level 2, Jet Black/Dark Ash |
| H2T | Interior Trim Configuration - Cloth, Level 2, Cocoa/Dune |
| H2U | Interior Trim Configuration - Leather, Level 3, Jet Black |
| H2V | Interior Trim Configuration - Leather, Level 3, Jet Black/Dark Ash |
| H2W | Interior Trim Configuration - Leather, Level 3, Jet Black/Cobalt |
| H2X | Interior Trim Configuration - Leather, Level 4, Jet Black |
| H2Y | Interior Trim Configuration - Leather, Level 4, Cocoa/Dune |
| H2Z | Interior Trim Configuration - Cloth, Level 2, VAR 1, Jet Black |
| H3A | Interior Trim Configuration - Leather VAR 1, Level 3, Coco /Dune |
| H3B | Interior Trim Configuration - Leather VAR 1, Level 3, Jet Black |
| H3C | Interior Trim Configuration - Leather VAR 1, Level 3, Jet Black/Dark Ash |
| H4S | Interior Trim Configuration - Leather, Level 3, Mink |
| I14 | Engineering Year - 2014 |
| IO3 | Radio - Infotainment System - Base |
| IO4 | Radio - Infotainment System - Base With Connectivity |
| IO5 | Radio - Infotainment System - Uplevel With Connectivity |
| IO6 | Radio - Infotainment System - Uplevel With Connectivity And Embedded Navigation |
| JD9 | Brake - VAC Power, 17 inch Disc/Disc, With VSES, 7, 700 lbs |
| JF4 | Pedals - Adjustable, Power |
| JHD | Control - Hill Descent, Gear Hold |
| JK1 | Tire press Indicator - Low Tire Pressure - None |
| JL1 | Control - Integrated Trailer Brake |
| K05 | Heater Engine - Block |
| K47 | Air Cleaner - High Capacity |
| KA1 | Heater Seat Front - Driver and Passenger |
| KB6 | Heater - Seat, Cooling, Front |
| KC4 | Cooling System - Engine Oil |
| KG4 | Generator - 150 Amp |
| KI4 | Receptacle - Electrical, Accessory 110 Volt |
| KI5 | Receptacle - Electrical, Accessory 230 Volt |
| KNP | Cooling System - Transmission, HD |
| KW7 | Generator - 170 Amp |
| L83 | Engine - Gas, 8 Cylinder, 6.2L, SIDI VVT, AFM, E85 MAX, Aluminum, GM |
| L86 | Engine - Gas, 8 Cylinder, 6.2L, SIDI VVT, AFM, E85 MAX, Aluminum, GM |
| LV1 | Engine - Gas, 6 Cylinder, 4.3L, SIDI, V6, VVT, E85 MAX, Iron |
| LV3 | Engine - Gas, 6 Cylinder, 4.3L, GEN 5, SIDI, V6, VVT, OHV, E85 MAX, Aluminum |
| MAA | Marketing Area - Africa |
| MAF | Marketing Area - Southeast Asia |
| MAH | Marketing Area - US, Puerto Rico/USVI |
| MAM | Marketing Area - Middle East |
| MAY | Marketing Area - Andean (South America 2) |
| MBC | Marketing Area - Canada |
| MCX | Marketing Area - Mexico |
| MSL | Plant Code - Silao, Mexico |
| MXW | Transmission - Manual 5 Speed, 4.227 1st, 2.375 2nd, 1.470 3rd, 1.000 4th, 0.808th Tremec, GEN 1 |
| MYC | Transmission - Automatic 6 Speed, HMD, 6L80 |
| N05 | Lock Control - Fuel Filler Cap |
| N30 | Steering Wheel - Deluxe |
| N33 | Steering Column - Tilt Type |
| N37 | Steering Column - Tilt, Telescoping |
| NE1 | Certification - Emission, Geographically Restricted Registration For Vehicles Up To 14, 000 lbs GVW |
| NHT | Performance Package - Enhanced Towing |
| NK5 | Steering Wheel - Standard |
| NKC | Noise Control - System, Active Noise Cancellation |
| NP5 | Steering Wheel - Leather Wrapped |
| NQG | Transfer Case - Manual Shift Cont, Two Speed, Aluminum |
| NQH | Transfer Case - Active, Two Speed, Push Button Control, Aluminum |
| NT7 | Emission System - Federal, Tier 2 |
| NU5 | Emission System - California, Bin 4 |
| NZH | Wheel - 20 X 9.0, J, Aluminum, Design 8 |
| NZJ | Wheel - 20 X 9.0, J, Aluminum, Design 9 |
| NZM | Wheel - 20 X 9.0, J, Aluminum, Design 10 |
| NZZ | Sales Package - Skid Plate Off-Road Sport |
| PPA | Equipment - Assist, Open and Close, Tailgate |
| PZX | Wheel - 18 x 8.5, J, Aluminum, Design 2 |
| Q5U | Wheel - 17 x 8.0, J, Aluminum, Design 2 |
| Q5W | Wheel - 17 x 8.0, J, Aluminum, Design 1 |
| QBL | Tire All P265/70R17- SL 113H BW OOR |
| QHX | Tire All P285/50R20-111H BW AL3 |
| QNM | Tire All - P245/70R17-108H BW TL ST ALS |
| QSS | Tire All - P275/55R20-111S BW TL ST AL2 |
| RBR | Wheel - 22 X 9.0, J, Steel, Design 1 |
| RBW | Tire All - P265/65R18 SL 112T WOL AT |
| RBX | Tire All - P265/65R18 SL 112T BW AT |
| RBZ | Tire All - P255/70R17 SL 110S BW ALS |
| RC3 | Tire All - P265/70R17 SL 113S BW AT |
| RC4 | Tire Spare - P265/70R17 SL 113S BW |
| RC5 | Tire All - LT265/70R17 C 112Q BW AT |
| RC7 | Tire All - P275/55R20 SL 111S BW AT |
| RCW | Wheel - 18 X 8.5, J, Aluminum, Design 5 |
| RD1 | Wheel - 18 X 8.5, J, Aluminum, Design 6 |
| RD2 | Wheel - 20 X 9.0, J, Aluminum, Design 2 |
| RD3 | Wheel - 20 X 9.0, J, Aluminum, Design 3 |
| RD4 | Wheel - 20 X 9.0, J, Aluminum, Design 4 |
| RD6 | Wheel - 17 X 8.0, J, Steel, Design 2 |
| RD7 | Wheel - 17 X 8.0, J, Steel, Design 3 |
| RHH | Tire All - P285/45R22 SL 110H BW AT |
| RHM | RHM |
| RKX | Tire All - P265/65R18 SL 112T BW ALS |
| RT5 | Wheel - 18 X 8.5, J, Aluminum, Design 1 |
| RTL | Wheel - 20 X 9.0, J, Aluminum, Design 1 |
| RUF | Wheel Spare - 17 X 7.5, J, Steel, Design 1 |
| RVG | Accessory - Adapter - Trailer Harness |
| RVO | Accessory - Assist Steps - Tubular - Oval - Black |
| RVS | Accessory - Assist Steps - Tubular - Round - Black |
| RVX | Accessory - Ball Mount - Trailer Hitch |
| RW6 | Accessory - Bed Storage Box - Fixed Full Width - Metal |
| RWI | Accessory - Body Side Moldings - Chrome |
| RWS | Accessory - Floor Mats - Carpet |
| RX1 | Accessory - Wheel, With Inserts - Design 1 |
| RXH | Accessory - Center Cap - Wheel - Design 1 |
| RXN | Accessory - Wheel, With Inserts - Design 2 |
| RXQ | Accessory - Convenience Net - Bed Mounted |
| RZ9 | Accessory - Grilles/Grille Insert - Alternate Design 1 |
| RZB | Accessory - Grilles/Grille Insert - Alternate Design 2 |
| S0P | Accessory - Insert - Floor Console |
| S0Y | Accessory - Lamps - Cargo Area |
| S2B | Wheel Spare - 17 X 7.0, J, Aluminum, Design 1 |
| S41 | Accessory - Liner - Wheel House |
| S42 | Accessory - Load Stops - Utility Rack |
| S44 | Accessory - Locking Pin - Trailer Hitch |
| S6P | Accessory - Remote Start Kit |
| S6V | Accessory - Assist Steps - Retractable |
| SAF | Lock - Spare Tire, Hoist Shaft |
| SAO | Accessory - Smokers Package |
| SB1 | Accessory - Splash Guards - Flat |
| SB7 | Accessory - Decal Package - Design 1 |
| SB9 | Accessory - Decal Package - Design 2 |
| SCZ | Accessory - Tailgate Handle - Alternate Finish - Chrome |
| SDA | Accessory - Tow Hooks |
| SDE | Accessory - Trailer Hitch - Removable |
| SES | Accessory - Wheel - 22 X 9.0 - J - Aluminum - Design 1 |
| SEU | Accessory - Wheel - 22 X 9.0 - J - Aluminum - Design 2 |
| SEV | Accessory - Wheel - 22 X 9.0 - J - Aluminum - Design 3 |
| SEW | Accessory - Wheel - 22 X 9.0 - J - Aluminum - Design 4 |
| SEY | Accessory - Wheel - 22 X 9.0 - J - Aluminum - Design 5 |
| SEZ | Accessory - Wheel - 22 X 9.0 - J - Aluminum - Design 6 |
| SFO | Accessory - Wheel - 22 X 9.0 - J - Aluminum - Design 7 |
| SF1 | Accessory - Wheel - 22 X 9.0 - J - Aluminum - Design 8 |
| SF6 | Accessory - Wheel Flares - Alternate Design - Painted |
| SF8 | Accessory - Decal Package - Design 3 |
| SFE | Accessory - Wheel Locks |
| SFJ | Accessory - Window Shades - Reflective |
| SFV | Accessory - Wireless Network Interface Module |
| SJ9 | Accessory - Grille/Grille Inserts - Alternate Finish 1 |
| SLT | Equipment - LT Sales Package |
| SYT | Accessory - Sill Plates - Alternate Finish |
| T2H | Ornamentation - Exterior, Export Unique Requirements |
| T3U | Lamp Front Fog - Front Fog |
| T62 | Lamp System - Daytime Running - Delete |
| T98 | Stamping - Vehicle Identification Number |
| TG5 | Player - Compact Disc and MP3 |
| TL1 | Grille - Special |
| TRW | Provisions - Lamp, Roof Mounted |
| TUF | Ornamentation Emblem, "Texas Edition" |
| U19 | Speedometer - Instrument, Kilometers and Miles, Kilometer Odometer |
| U2J | Digital Audio System - S-Band, Not Installed |
| U2M | Digital Audio System - S-Band and HD |
| U42 | Entertainment Package - Rear Seat, Single Display, Remote Control, Auxiliary Jack, 2 - Wireless Dual Channel Headphones |
| U73 | Antenna - Fixed, Radio |
| UB7 | Performance Package - Higher Payload |
| UD5 | Park Assist - Front And Rear |
| UD7 | Sensor Indicator - Rear Parking Assist |
| UDC | Display Instrument - Driver Information Enhanced (One Color Graphic) |
| UDD | Display Instrument - Driver Information Enhanced (Multi Color Standard Graphic) |
| UE0 | Communication System - Vehicle, G.P.S. - Not Installed |
| UE1 | Communication System - Vehicle, G.P.S. 1 |
| UEU | Sensor Indicator - Forward Collision Alert |
| UF2 | Lamp - Cargo |
| UFL | Lane Active Safety - Departure Warning |
| UG1 | Opener - Garage Door, Universal |
| UHN | Wheel - 18 X 8.5, J, Aluminum, Design 3 |
| UHS | Display Instrument - Driver Information Enhanced (Multi Color Enhanced Graphic) |
| UJM | Tire Press Indicator - Manual Learn |
| UK3 | Accessory - Steering Wheel Control |
| UL2 | Frequencies - European |
| UL4 | Frequencies - South American |
| UL8 | Frequencies - Saudi Arabian |
| UMN | Speedometer - Instrument, Miles and Kilometers, Miles Odometer |
| UPF | Wireless Interface - Short Range, Voice REC |
| UQ3 | Speaker System - Performance Enhanced Audio |
| UQ5 | Speaker System - 4, Dual Front Door Mounted, Dual Extended Range Quarter Mounted |
| UQA | Speaker System - Premium Performance Enhanced Audio |
| UQG | Speaker System - Enhanced Audio with Amplifier |
| UTJ | Theft Deterrent - Electrical, Unauthorized Entry |
| UVC | Vision - Rear View, Mono |
| UVD | Heater - Steering Wheel |
| V22 | Grille - Radiator, Chrome |
| V46 | Bumper Front - Chrome |
| V76 | Hook - Tow |
| VAV | Accessory - Floor Mats - All Weather |
| VB5 | Bumper Front - Color |
| VBJ | Accessory - Underseat Storage |
| VBN | Accessory - PUBX Carpet |
| VBR | Accessory - PUBX Rubber Mat |
| VBX | Language Label - Arabic |
| VC5 | Label - Shipping, Except US, US Possessions or Japan |
| VFF | Video Format - Region 1, NTSC |
| VFJ | Video Format - Region 2, PAL |
| VFK | Video Format - Region 3, NTSC |
| VFM | Video Format - Region 4, NTSC |
| VGC | Protector - Film, Paint Etch Preventive |
| VH6 | Bumper Front - Black |
| VH9 | Envelope - Owner Information Manual |
| VJG | Bumper Rear - Black |
| VJH | Bumper Rear - Chrome |
| VK3 | License Plate Front - Front Mounting Package |
| VKU | Accessory - Mirror Caps - Chrome |
| VKW | Accessory - Organizer - Front Console |
| VKY | Accessory - Door Handles - Alternate Finish - Chrome |
| VPB | Accessory - Tonneau - Rear Compartment - Vinyl with Integral Crossbow Supports |
| VPH | Vehicle Preparation - Overseas Delivery |
| VQK | Accessory - Splash Guards - Custom Molded |
| VQL | Accessory - Fuel Door - Design 1 |
| VQT | Accessory - Tonneau - Rear Compartment -- Hard Folding |
| VQZ | Accessory-Exhaust Tip - Design 1 |
| VR6 | Hook - Tie-Down Shipping |
| VRV | Accessory - Splash Guards - Custom Molded - Painted |
| VT5 | Bumper Rear - Color Keyed |
| VT7 | Owners Manual - English Language |
| VUK | Accessory - Tailgate Liner - PUBX |
| VXH | Accessory - Assist Steps - Tubular - Chrome - Oval |
| VXJ | Accessory - Assist Steps - Tubular - Chrome - Round |
| VYU | Provisions - Snow Plow Preparation |
| VZ3 | Label - Mercury Disposal Notification |
| VZE | VIN Model Year - 2014 |
| VZX | Accessory - PUBX Bedliner |
| W88 | Accessory - PUBX Bedliner |
| WEA | Appearance Package Z71 Plus |
| X88 | Market Brand - Chevrolet |
| XFE | Fuel Economy - Extended Fuel Economy |
| XL7 | Frequencies Rating - 315 MHZ, Long Distance |
| XL8 | Frequencies Rating - 433 MHZ |
| Y65 | Sales Package - ESS 1 |
| Y91 | Merchandised Package - Luxury Edition |
| YE9 | Convenience Package - Comfort and Decor Level #3 |
| YF5 | Certification - Emission, California |
| Z49 | Export Canadian MODIF Mandatory Base EQUIP |
| Z5X | Mirror Provisions - Arabic Language |
| Z60 | Chassis Package - High Performance |
| Z71 | Chassis Package - Off Road |
| Z82 | Trailer Provisions - Special Equipment, H. D. |
| Z85 | Chassis Package - Increased Capacity |
| Z88 | Market Brand - GMC |
| ZBL | Tire Spare - P265/70R17 SL 113 H BW OOR |
| ZBZ | Tire Spare - P255/70R17 SL 110H BW ALS |
| ZNM | Tire Spare - P245/70R17-108H BW TL ST ALS |
| ZY1 | Color Combination - Solid |
RPO Table
RPO Code List (Heavy Duty)
| RPO | Description |
|---|---|
| The production/process codes provide the description of the Regular Production Options (RPOs). The RPO list is printed on the Service Parts Identification Label. | |
| 4AA | Interior Trim - Jet Black |
| 4D7 | Interior Trim - Jet Black, Dark Ash |
| 4DP | Interior Trim - Cocoa/Dune |
| 5A7 | Wheel Spare - None |
| 5AZ | Accessory - Safety Kit - Universal |
| 5JY | Accessory - Tonneau - Rear Compartment - Soft Folding |
| 5VI | Accessory - Tie Down Rings - Cargo Area |
| 5Y3 | Accessory - Tow Ball - Trailer Hitch |
| 9J4 | Bumper Rear - None |
| 9L3 | Tire Spare - None |
| 9L7 | Equipment - Accessory Wiring Junction Block |
| A31 | Window - Power Operated, All Doors |
| A45 | Memory - Seat Adjuster, Mirror, Power, Driver, Personalization |
| A48 | Window Rear - Full Width, Sliding, Power |
| A52 | Seat - Front Bench |
| A60 | Lock Control Rear Compartment - Lid, Tailgate, Key Activated |
| A68 | Seat Rear - Split, Folding |
| A95 | Seat - Front Bucket, High Back, Driver and Passenger Recliner |
| AE7 | Seat - Front Split, Driver, Passenger |
| AG1 | Adjuster Front Seat - Power, Multi-Directional, Driver |
| AK5 | Restraint System - Seat, Inflatable, Driver and Passenger Front |
| AKO | Window Type - Privacy |
| AKP | Window Type - Solar Absorbing |
| AM7 | Seat Rear - Folding |
| AN3 | Seat - Front, Individual, Non-Bucket |
| AQQ | Lock Control, Entry - Remote Entry, Extended Range (Model Year 09 and Future) |
| AU3 | Lock Control - Side Door, Electronic |
| AXK | Vehicle Type Truck |
| AY0 | Restraint System - Seat, Inflatable, Driver and Passenger Front, Seat Side, Roof Side |
| AZ3 | Seat - Front Split, Driver, Passenger, Full Feature Center |
| B1J | Liner - Rear Wheelhouse |
| B30 | Floor Covering - Carpet |
| B32 | Covering Front - Floor Mats, Auxiliary |
| B33 | Covering Rear - Floor Mats, Auxiliary |
| B3F | Seat - Front Split, Deluxe, Driver, Passenger, Full Feature Center |
| B58 | Covering - Floor Mat, Front and Rear, Carpeted Insert |
| B85 | Molding Bodyside - Exterior, Bright |
| B86 | Molding Bodyside - Body Color |
| BAG | Parts Package - Export |
| BG9 | Covering - Floor, Rubber |
| BJA | Parts Package - Truck Application VAR.1 |
| BTV | Remote Start - Engine |
| BWN | Steps - Corner Assist, Bumper |
| C42 | HVAC System - Heater, Outside Air, Deluxe |
| C49 | Defogger - Rear Window, Electric |
| C67 | HVAC System - Air Conditioner Front, Electronic Controls |
| C99 | Switch - Inflatable Restraint Instrument Panel Middle Man Suppression |
| CF5 | Roof - Sun, Glass, Sliding, Electric |
| CGN | Liner - PUBX, Spray On |
| CJ2 | HVAC System - Air Conditioner Front, Automatic Temperature Control, Auxiliary Temperature Control |
| CMD | Plant Code - Flint, MI, USA (TRK) |
| CTD | Equipment - Cargo Tie Down (Movable) |
| CU7 | Country - Kuwait |
| CU8 | Country - Saudi Arabia |
| CV3 | Country - Mexico |
| CV4 | Country - Israel |
| CW2 | Country - Gulf Areas (Bahrain, Kuwait, Oman, Qatar, Saudi Arabia, UAE) |
| CW5 | Country - Venezuela |
| CW9 | Country - Miscellaneous |
| CX3 | Country - Ecuador |
| CX9 | Country - Lebanon |
| CY2 | Country - Jordan |
| D07 | Console - Front Compartment, Floor, Custom |
| D75 | Handle Outside Door - Body Color |
| DD8 | Mirror Inside Rearview - Light Sensitive |
| DE2 | Mirror Outside - Left and Right, Manual Control, Folding, Color |
| DF2 | Mirror Outside - Left and Right, Wide Load, Folding, Stainless Steel |
| DH6 | Mirror Inside Front Vanity - Left and Right, Sunshade, Illuminated |
| DL3 | Mirror Outside - Left and Right, Remote Control, Electric, Heated, Power Folding, Turn Signal Indicator, Light Sensitive, Color |
| DL8 | Mirror Outside - Left and Right, Remote Control, Electric, Heated |
| DNS | Equipment - Supplier Installed |
| DP6 | Mirror Provisions - Housing, Painted |
| DP9 | Mirror Provisions - Housing, Chrome |
| DPN | Mirror Outside - Left and Right, Wide Load, Vertical Glass, Manual Extending, Manual Folding, Heated, Turn Signal Indicator, Remote Control |
| DT4 | Ashtray - Cigarette Lighter |
| E20 | Handle Outside Door - Chrome |
| E29 | Equipment - Modification Base Equipment |
| E63 | Body Equipment - Fleetside, Pick-up Box |
| EF7 | Country United States of America (USA) |
| EXP | Export |
| FE9 | Certification - Emission, Federal |
| FHO | Vehicle Fuel - Gasoline E10 |
| FHS | Vehicle Fuel - Gasoline E85 |
| FHV | Vehicle Fuel - Bifuel and Monovalent Plus CNG |
| FHX | Vehicle Fuel - Diesel B20 |
| FWI | Plant Code - Fort Wayne, IN, USA |
| G56 | Primary Color - Exterior, Stealth Gray Metallic 928L |
| G80 | Axle Positraction - Limited Slip |
| GAN | Primary Color - Exterior, Switchblade Silver Metallic (G) 636R |
| GAR | Primary Color - Exterior, Carbon Flash Metallic (G) 501Q |
| GAZ | Primary Color - Exterior, Summit White (G) 8624 |
| GBA | Primary Color - Exterior, Black (G) 8555 |
| GCE | Primary Color - Exterior, Sonoma Jewel Metallic (412P) |
| GCN | Primary Color - Exterior, Victory Red 9260 |
| GCS | Primary Color - Exterior, Velvet Red Metallic (681R) |
| GOZ | Primary Color - Exterior, Daydream Beige Metallic (892T) |
| GT4 | Axle Rear - 3.73 Ratio |
| GT5 | Axle Rear - 4.10 Ratio |
| GTS | Primary Color - Exterior, Luxo Blue Metallic (933L) (44U) |
| GTY | Axle - Wide Track |
| GWX | Primary Color - Exterior, Subterranean Metallic (105V) |
| GXG | Primary Color - Exterior, Iridium Metallic (121V) |
| GYK | Primary Color - Exterior, Iridium Metallic (121V) |
| GYM | Primary Color - Exterior, Satin Steel Grey Metallic (205V) |
| H0K | Interior Trim Configuration - Leather, Level 3, Cocoa/Dune |
| H0U | Interior Trim Configuration - Cloth, Level 2, Jet Black |
| H1Y | Interior Trim Configuration - Leather, Level 2, Jet Black |
| H2Q | Interior Trim Configuration - Vinyl, Level 1, Jet Black/Dark Ash |
| H2R | Interior Trim Configuration - Cloth, Level 1, Jet Black/Dark Ash |
| H2S | Interior Trim Configuration - Cloth, Level 2, Jet Black/Dark Ash |
| H2T | Interior Trim Configuration - Cloth, Level 2, Cocoa/Dune |
| H2U | Interior Trim Configuration - Leather, Level 3, Jet Black |
| H2V | Interior Trim Configuration - Leather, Level 3, Jet Black/Dark Ash |
| H2X | Interior Trim Configuration - Leather, Level 4, Jet Black |
| H2Y | Interior Trim Configuration - Leather, Level 4, Cocoa/Dune |
| H3A | Interior Trim Configuration - Leather VAR 1, Level 3, Coco /Dune |
| H3B | Interior Trim Configuration - Leather VAR 1, Level 3, Jet Black |
| H3C | Interior Trim Configuration - Leather VAR 1, Level 3, Jet Black/Dark Ash |
| I14 | Engineering Year - 2014 |
| IO3 | Radio - Infotainment System - Base |
| IO4 | Radio - Infotainment System - Base With Connectivity |
| IO5 | Radio - Infotainment System - Uplevel With Connectivity |
| IO6 | Radio - Infotainment System - Uplevel With Connectivity And Embedded Navigation |
| J95 | Brake - Hydraulic Power, Single Rear Wheel, 4 Wheel Disc |
| J96 | Brake - Hydraulic Power, Dual Rear Wheel, 4 Wheel Disc |
| JF4 | Pedals - Adjustable, Power |
| JHD | Control - Hill Descent, Gear Hold |
| JK1 | Tire press Indicator - Low Tire Pressure - None |
| JL1 | Control - Integrated Trailer Brake |
| K05 | Heater Engine - Block |
| K34 | Cruise Control - Automatic, Electronic |
| K40 | Engine Brake Exhaust |
| K47 | Air Cleaner - High Capacity |
| K4B | Battery - LN3, FLA, 12V, 70AH, 730 SAE CCA, AUX |
| KA1 | Heater Seat Front - Driver and Passenger |
| KB6 | Heater - Seat, Cooling, Front |
| KC4 | Cooling System - Engine Oil |
| KG4 | Generator - 150 Amp |
| KH5 | Generator - 150 Amp, Dual |
| KI4 | Receptacle - Electrical, Accessory 110 Volt |
| KI5 | Receptacle - Electrical, Accessory 230 Volt |
| KNP | Cooling System - Transmission, HD |
| KW5 | Generator - 220 Amp |
| L96 | Engine - Gas, 8 Cylinder, 6.0l, SFI, E85 MAX, Iron, GM |
| LC8 | Engine - LPG/CNG, 8 Cylinder, V8, 6.0L, SFI, GEN 1, GMNA |
| LML | Engine - Diesel, 8 Cylinder, 6.6L, PTI, V8, Turbo, Duramax |
| M1F | Power Take Off - Rear PTO |
| MAA | Marketing Area - Africa |
| MAH | Marketing Area - US, Puerto Rico/USVI |
| MAM | Marketing Area - Middle East |
| MAY | Marketing Area - Andean (South America 2) |
| MBC | Marketing Area - Canada |
| MBI | Marketing Area - Israel |
| MCX | Marketing Area - Mexico |
| MQ7 | Transmission - Manual 5 Speed, Tremec, 109MM, 6.16 1ST, 3.11 2ND, 1.71 3RD, 1.00 4TH, 0.76 5TH (TR4050) |
| MSL | Plant Code - Silao, Mexico |
| MW7 | Transmission - Automatic 6 Speed, Allison, LCT 1000, 3.10 1ST.71 5TH.62 6TH, O/D, CONV Clutch |
| MYD | Transmission - Automatic 6 Speed, HMD, 6L90 |
| N05 | Lock Control - Fuel Filler Cap |
| N2L | Fuel Tank - Rear Tank 40 GAL (151L) |
| N2M | Fuel Tank - Front Tank 23.5 GAL (89L) |
| N2N | Fuel Tank - Dual Tank, Front Tank 23.5 GAL (89L) Rear Tank 40 GAL (151L) |
| N30 | Steering Wheel - Deluxe |
| N33 | Steering Column - Tilt Type |
| N37 | Steering Column - Tilt, Telescoping |
| N79 | Wheel Spare - Full Size, Steel |
| NC8 | Emission System - California, ULEV |
| NE1 | Certification - Emission, Geographically Restricted Registration For Vehicles Up To 14, 000 lbs GVW |
| NK5 | Steering Wheel - Standard |
| NP5 | Steering Wheel - Leather Wrapped |
| NPL | Plate - Name - None |
| NQF | Transfer Case - Electric Shift CONT, Two Speed, Aluminum |
| NQG | Transfer Case - Manual Shift CONT, Two Speed, Aluminum |
| NT7 | Emission System - Federal, Tier 2 |
| NU2 | Emission System - California, ULEV2 |
| NU4 | Emission System - California LEV2 Plus |
| NZ4 | Wheel Spare - Full Size, 17" Steel |
| NZZ | Sales Package - Skid Plate Off-Road Sport |
| P03 | Cover, Wheel - VAR 3 |
| P06 | Trim Discs - Wheel |
| PPA | Equipment - Assist, Open and Close, Tailgate |
| PTO | Engine Control - Power Take Off (PTO) Controls |
| PYN | Wheel - 17 x 7.5, Steel, HD 8 Lug |
| PYP | Wheel - 17 x 7.5, Chrome Appearance, HD 8 Lug |
| PYQ | Wheel - 17 x 7.5, Aluminum, Premium, HD 8 Lug |
| PYR | Wheel - 18 x 8.0, Forged Aluminum, Premium |
| PYS | Wheel - 20 x 8.5, Forged Aluminum, Polished |
| PYT | Wheel - 18 x 8, Steel, HD 8 Lug |
| PYV | Wheel - 18 x 8, Forged Aluminum, Polished |
| PYW | Wheel - 17 x 6.5, Steel, HD 8 Lug |
| QFC | Tire All - LT265/60R20/E 121S AT |
| QGM | Tire All - LT265/70R18/E 124R BW TL AT |
| QHQ | Tire All - LT245/75R17 E 121/118 R BW ALS |
| QQO | Tire All - LT235/80R17/E (120/117R) BW TL HWY |
| QWF | Tire All - LT265/70R18/E 124S BW TL ALS |
| QXT | Tire All - LT265/70R17/E BW TL AT |
| QXU | Tire All - LT265/70R17/E BW TL AT Export |
| QZT | Tire All - LT235/80R17/E (120/117R) BW TL AT |
| R6J | Control - Sales Item No. 10 |
| R6K | Control - Sales Item No. 11 |
| R6V | Control - Sales Item No. 21 |
| RS7 | Wheel - 17 X 6.5, J, Aluminum, Design 1 |
| RVG | Accessory - Adapter - Trailer Harness |
| RVQ | Accessory - Assist Steps - Tubular - Oval - Black |
| RVS | Accessory - Assist Steps - Tubular - Round - Black |
| RVX | Accessory - Ball Mount - Trailer Hitch |
| RW6 | Accessory - Bed Storage Box - Fixed Full Width - Metal |
| RWI | Accessory - Body Side Moldings - Chrome |
| RWS | Accessory - Floor Mats - Carpet |
| RXQ | Accessory - Convenience Net - Bed Mounted |
| RZB | Accessory - Grilles/Grille Insert - Alternate Design 2 |
| S0P | Accessory - Insert - Floor Console |
| S0Y | Accessory - Lamps - Cargo Area |
| S41 | Accessory - Liner - Wheel House |
| S44 | Accessory - Locking Pin - Trailer Hitch |
| S6P | Accessory - Remote Start Kit |
| S6V | Accessory - Assist Steps - Retractable |
| SAF | Lock - Spare Tire, Hoist Shaft |
| SAO | Accessory - Smokers Package |
| SB1 | Accessory - Splash Guards - Flat |
| SB7 | Accessory - Decal Package - Design 1 |
| SB9 | Accessory - Decal Package - Design 2 |
| SCZ | Accessory - Tailgate Handle - Alternate Finish - Chrome |
| SDA | Accessory - Tow Hooks |
| SDE | Accessory - Trailer Hitch - Removable |
| SEM | Accessory - Wheel - 20" - Aluminum - Design 5 |
| SEO | Accessory - Wheel - 20" - Aluminum - Design 6 |
| SF6 | Accessory - Wheel Flares - Alternate Design - Painted |
| SF8 | Accessory - Decal Package - Design 3 |
| SFE | Accessory - Wheel Locks |
| SFJ | Accessory - Window Shades - Reflective |
| SFV | Accessory - Wireless Network Interface Module |
| SJ9 | Accessory - Grille/Grille Inserts - Alternate Finish 1 |
| SKP | Wheel Spare - 17 X 6.5, J, Steel, Design 1 |
| SLT | Equipment - LT Sales Package |
| SRW | Chassis - Single Rear Wheel, Ride and Handling |
| SYT | Accessory - Sill Plates - Alternate Finish |
| T2H | Ornamentation - Exterior, Export Unique Requirements |
| T3U | Lamp Front Fog - Front Fog |
| T62 | Lamp System - Daytime Running - Delete |
| T98 | Stamping - Vehicle Identification Number |
| TCB | Plant Code - Valencia, Venezuela |
| TG5 | Player - Compact Disc and MP3 |
| TL1 | Grille - Special |
| TRW | Provisions - Lamp, Roof Mounted |
| TUF | Ornamentation - Emblem, "Texas Edition" |
| U01 | Lamp - Five, Roof Marker, Truck |
| U19 | Speedometer - Instrument, Kilometers and Miles, Kilometer Odometer |
| U2J | Digital Audio System - S-Band, Not Installed |
| U2M | Digital Audio System - S-Band and HD |
| U42 | Entertainment Package - Rear Seat, Single Display, Remote Control, Auxiliary Jack, 2 - Wireless Dual Channel Headphones |
| U73 | Antenna - Fixed, Radio |
| UB7 | Performance Package - Higher Payload |
| UD5 | Park Assist - Front And Rear |
| UD7 | Sensor Indicator - Rear Parking Assist |
| UDC | Display Instrument - Driver Information Enhanced (One Color Graphic) |
| UDD | Display Instrument - Driver Information Enhanced (Multi Color Standard Graphic) |
| UE0 | Communication System - Vehicle, G.P.S. - Not Installed |
| UE1 | Communication System - Vehicle, G.P.S. 1 |
| UEU | Sensor Indicator - Forward Collision Alert |
| UF2 | Lamp - Cargo |
| UF3 | Switch - High Idle |
| UFL | Lane Active Safety - Departure Warning |
| UG1 | Opener - Garage Door, Universal |
| UHS | Display Instrument - Driver Information Enhanced (Multi Color Enhanced Graphic) |
| UJM | Tire Press Indicator - Manual Learn |
| UK3 | Accessory - Steering Wheel Control |
| UL2 | Frequencies - European |
| UL4 | Frequencies - South American |
| UL8 | Frequencies - Saudi Arabian |
| UMN | Speedometer - Instrument, Miles and Kilometers, Miles Odometer |
| UPF | Wireless Interface - Short Range, Voice REC |
| UQ3 | Speaker System - Performance Enhanced Audio |
| UQ5 | Speaker System - 4, Dual Front Door Mounted, Dual Extended Range Quarter Mounted |
| UQA | Speaker System - Premium Performance Enhanced Audio |
| UTJ | Theft Deterrent - Electrical, Unauthorized Entry |
| UTM | Theft Deterrent System - Unauthorized Entry, without Remote Keyless Entry |
| UVC | Vision - Rear View, Mono |
| UVD | Heater - Steering Wheel |
| UY2 | Wiring Provisions - Camper and 5th Wheel Trailer |
| V10 | Provision Options - Cold Weather |
| V22 | Grille - Radiator, Chrome |
| V3Q | Bar - Rollover |
| V46 | Bumper Front - Chrome |
| V76 | Hook - Tow |
| V8I | Vehicle Statement - Israel |
| VAV | Accessory - Floor Mats - All Weather |
| VB5 | Bumper Front - Color |
| VBJ | Accessory - Underseat Storage |
| VBN | Accessory - PUBX Carpet |
| VBR | Accessory - PUBX Rubber Mat |
| VBX | Language Label - Arabic |
| VC5 | Label - Shipping, Except US, US Possessions or Japan |
| VFF | Video Format - Region 1, NTSC |
| VFJ | Video Format - Region 2, PAL |
| VGC | Protector - Film, Paint Etch Preventive |
| VH9 | Envelope - Owner Information Manual |
| VJH | Bumper Rear - Chrome |
| VK3 | License Plate Front - Front Mounting Package |
| VKU | Accessory - Mirror Caps - Chrome |
| VKW | Accessory - Organizer - Front Console |
| VKY | Accessory - Door Handles - Alternate Finish - Chrome |
| VPB | Accessory - Tonneau - Rear Compartment - Vinyl with Integral Crossbow Supports |
| VPH | Vehicle Preparation - Overseas Delivery |
| VQK | Accessory - Splash Guards - Custom Molded |
| VQL | Accessory - Fuel Door - Design 1 |
| VQT | Accessory - Tonneau - Rear Compartment -- Hard Folding |
| VQZ | Accessory-Exhaust Tip - Design 1 |
| VR6 | Hook - Tie-Down Shipping |
| VRV | Accessory - Splash Guards - Custom Molded - Painted |
| VT5 | Bumper Rear - Color Keyed |
| VT7 | Owners Manual - English Language |
| VUK | Accessory - Tailgate Liner - PUBX |
| VXH | Accessory - Assist Steps - Tubular - Chrome - Oval |
| VXJ | Accessory - Assist Steps - Tubular - Chrome - Round |
| VXT | Vehicle Type - Incomplete |
| VYU | Provisions - Snow Plow Preparation |
| VZ3 | Label - Mercury Disposal Notification |
| VZE | VIN Model Year - 2014 |
| VZX | Accessory - PUBX Bedliner |
| W88 | Accessory - PUBX Bedliner |
| WEA | Appearance Package Z71 Plus |
| X88 | Market Brand - Chevrolet |
| XL7 | Frequencies Rating - 315 MHZ, Long Distance |
| XL8 | Frequencies Rating - 433 MHZ |
| Y65 | Sales Package - ESS 1 |
| Y91 | Merchandised Package - Luxury Edition |
| YE9 | Convenience Package - Comfort and Decor Level #3 |
| YF5 | Certification - Emission, California |
| Z49 | Export Canadian MODIF Mandatory Base EQUIP |
| Z5X | Mirror Provisions - Arabic Language |
| Z71 | Chassis Package - Off Road |
| Z82 | Trailer Provisions - Special Equipment, H. D. |
| Z85 | Chassis Package - Increased Capacity |
| Z88 | Market Brand - GMC |
| ZHQ | Tire Spare - LT245/75R17 E 121/118 R BW ALS |
| ZQO | Tire Spare - LT235/80R17/E (120/117R) BW TL HWY |
| ZW9 | Body Equipment Base Body or Chassis |
| ZWF | Tire Spare - LT265/70R18 E 124/121 S BW ALS |
| ZXT | Tire Spare - LT265/70R17/E BW TL |
| ZXU | Tire Spare - LT265/70R17/E BW TL AT Export |
| ZY1 | Color Combination - Solid |
| ZZT | Tire Spare - LT235/80R17 E 120/117 Q BW AT |
RPO Table
Metric Fasteners
This vehicle provides fastener dimensions using the metric system. Most metric fasteners are approximate in diameter to equivalent English fasteners. Make replacements using fasteners of the same nominal diameter, thread pitch and strength.
A number marking identifies the OE metric fasteners except cross-recess head screws. The number also indicates the strength of the fastener material. A Posidrive® or Type 1A cross-recess identifies a metric cross-recess screw. For best results, use a Type 1A cross-recess screwdriver or equivalent, in Posidrive® recess head screws.
GM Engineering Standards and North American Industries have adopted a portion of the ISO-defined standard metric fastener sizes. The purpose was to reduce the number of fastener sizes used while retaining the best thread qualities in each thread size. For example, the metric M6.0 X 1 screw, with nearly the same diameter and 25.4 threads per inch replaced the English 1/4-20 and 1/4-28 screws. The thread pitch is midway between the English coarse and fine thread pitches.
Scheme 5
| Callout | Component Name |
|---|---|
| 1 | English Bolt, Grade 2 (Strength Class) |
| 2 | English Bolt, Grade 5 (Strength Class) |
| 3 | English Bolt, Grade 7 (Strength Class) |
| 4 | English Bolt, Grade 8 (Strength Class) |
| 5 | Metric Nut, Strength Class 9 |
| 6 | Metric Bolts, Strength Class Increases as Numbers Increase |
The most commonly used metric fastener strength property classes are 9.8 and 10.9. The class identification is embossed on the head of each bolt. The English, inch strength classes range from grade 2 to grade 8. Radial lines are embossed on the head of each bolt in order to identify the strength class. The number of lines on the head of the bolt is 2 lines less than the actual grade. For example, a grade 8 bolt will have 6 radial lines on the bolt head. Some metric nuts are marked with a single digit strength identification number on the nut face.
The correct fasteners are available through GM SPO. Many metric fasteners available in the aftermarket parts channels are designed to metric standards of countries other than the United States and may exhibit the following
- Lower strength
- No numbered head marking system
- Wrong thread pitch
The metric fasteners on GM products are designed to new, international standards. The following are the common sizes and pitches, except for special applications
- M6.0 X 1
- M8 X 1.25
- M10 X 1.5
- M12 X 1.75
- M14 X 2.00
- M16 X 2.00
Thread Inserts
General Purpose Thread Repair Kits.
These kits are available commercially.
Repair Procedure
- Determine the size, the pitch and the depth of the damaged thread. If necessary, adjust the stop collars on the cutting tool and tap to the required depth.
- Drill out the damaged threads. Clean out any chips.
- Lubricate the tap with light engine oil. Tap the hole. Clean the threads.
- Thread the thread insert onto the mandrel of the installer. Engage the tang of the insert onto the end of the mandrel.
- Lubricate the insert with light engine oil, except when installing in aluminum and install the insert.
- If the tang of the insert does not break off when backing out the installer, break the tang off with a drift.
Registered and Non-Registered Trademarks
Listed below are Registered Trademarks (®) or Non-Registered Trademarks (™) which may appear in this service manual.
| A |
|---|
| AC® |
| ACCUTURN® |
| ACDelco® |
| Active Fuel Management™ |
| Acuzinc® |
| Airbank® |
| Allison® |
| AMMCO® |
| AUTOFUSE® |
| AUTOTRAC® |
| B |
| Bendix® |
| Bluetooth® |
| BON-AMI® |
| Bosch® |
| Bose® |
| C |
| Caterpillar® |
| CAT® |
| C-Quam® |
| D |
| Delco® |
| Delco Bose® |
| Delco Electronics® |
| Delco Freedom® |
| Delco LOC II® |
| Delco Moraine® |
| Delco Remy® |
| Delco Sound® |
| Delco Supreme® |
| Delco Tech® |
| DELCORE® |
| Delphi® |
| DEX-COOL® |
| DEXOIL® |
| DEXRON® |
| DEXSTEER™ |
| DNR® |
| Dolby® |
| DR® |
| Duracell® |
| Duraguard® |
| Durastop® |
| Duramax™ |
| E |
| Eaton Corporation® |
| EMD® |
| ETR® |
| F |
| FLO-LITE® |
| G |
| General Motors® |
| GM® |
| GM Goodwrench Service® |
| GM Optikleen® |
| GM Parts™ |
| GM Pass® |
| GM Ultralite® |
| GMAC® |
| Goodwrench® |
| GTP® |
| H |
| Homelink™ |
| HYDRA-MATIC® |
| I |
| Illumination® |
| INSTA-TRAC® |
| Intune® |
| L |
| LOCTITE™ |
| Lord Fusor™ |
| M |
| MAGNASTEER® |
| Maxifuse® |
| Metripack® |
| Micropack® |
| Minifuse® |
| Mr Goodwrench® |
| N |
| Northstar® |
| O |
| OnStar® |
| Optikleen® |
| P |
| PASS-KEY® |
| PASS-KEYII® |
| PASSLOCK™ |
| PK3® |
| Posidrive® |
| Pro® |
| Q |
| Quad 4® |
| R |
| RAINSENSE™ |
| Rapid Fire® |
| S |
| ScotchBrite™ |
| Scotchguard™ |
| Signals® |
| Sikkens™ |
| Soft-Ray® |
| Solar-Ray® |
| Stabilitrak® |
| Sunrayce® |
| Superlube® |
| Syclone® |
| T |
| Tech 2® |
| Techline® |
| Teflon® |
| Tefzel® |
| Theft-I® |
| Theftlock® |
| Tiltmaster® |
| TORX® |
| Transjel® |
| Transguide® |
| Twilight Sentinel® |
| U |
| Ultralite® |
| V |
| Velcro® |
| W |
| Weatherpack™ |
Registered and Non-Registered Trademarks
Scheme 6
The internal lock cylinder only uses 4 of the ten cut positions, 7 through 10. The tumbler positions are on one side and self-retaining.
- Rotate the cylinder (1) so the side with tumbler spring wells faces up.
- Insert the tumbler springs (2) into the 4 spring wells.
- Install the first tumbler (3) for key cut position 7 in the slot nearest to the front of the lock cylinder. Install the remaining tumblers following the key code.
- Press the tumblers in place until they are secure.
- Check for correct loading of the tumblers by inserting the key into the cylinder. All tumblers should be flush with the lock cylinder body.
Scheme 7
The door lock cylinder only uses 7 of the 10 cut positions, 3 through 9. The tumbler positions are staggered from side to side, 4 on one side and 3 on the other side, are self-retaining. The left and right door lock cylinders are identical. The lever assembly determines which side of the vehicle the lock cylinder is for. After removing the current lock, record which lever is used and the orientation of rod clip.
- Rotate the cylinder (1) so the side with the 4 tumbler spring wells faces up.
- Insert the tumbler springs (2) into the 4 spring wells.
- Install the tumbler (3) for key cut position 3 in the slot closest to the cylinder. Install the remaining tumblers, key cut positions 5, 7 and 9, following the key code and same process. Press the tumblers in place until they are secure.
- Check the correct loading of the tumblers by inserting the key into the cylinder. All tumblers should be flush with the lock cylinder body.
- Turn the cylinder so the side with the 3 tumbler spring wells faces up.
- Insert the tumbler springs into the 3 spring wells.
- The first tumbler closest to the front of the lock cylinder to be loaded will be the fourth key cut position. Install the remaining tumblers for key cut positions 6 and 8. Press the tumblers in place until they are secure.
- Check the correct loading of the tumblers by inserting the key into the cylinder. All of the tumblers should be flush with the lock cylinder body.
- Apply lubricant to the cylinder body and tumbler surfaces along with a small amount in the head of the cylinder using the supplied grease.
- Install 2 springs (4) into the spring wells in the head of the lock cylinder.
- Snap the shutter assembly (5) into the cylinder.
- Assemble the cylinder into the case (6).
- Align dimples of the cylinder cap (7) with the 4 recesses in the cap. Secure by pressing the cap into place with light hand pressure.
- If required, assemble the rod clip (9) to the lever (8) using the recorded lever information.
- Assemble the lever to the lock. Use E-clip (10) to retain the lever assembly.
- If supplied, assemble the gasket to the lock.
- Insert the key into the lock and function the lock to check for proper assembly and smooth operation.
Scheme 8
The ignition lock cylinder uses only 7 of the 10 cut positions, 3 through 9. The ignition cylinder tumblers are all located on alternate sides of the cylinder (1). They are snap-in and self-retaining. It follows the key code with the first tumbler being the first depth of the key code, closest to the head of the key.
- Hold the ignition cylinder assembly (1) so the side with the 4 tumblers spring pocket of the cylinder is facing up.
- Insert the tumbler springs (2) into each of the spring pockets of the cylinder assembly.
- The first tumbler (3) to be loaded will be the third key cut position, the third number in the key code. Install the first tumbler in the slot nearest the head of the lock cylinder. Install the remaining tumblers for cuts 5, 7 and 9 following the key code and same process. Press the tumblers in place until they are secure.
- Rotate cylinder assembly so the 3 tumblers springs pocket of the cylinder is facing up. Insert tumbler springs (2) into each of the spring pockets of the cylinder assembly.
- The first tumbler (3) to be loaded will be the fourth key cut position, the fourth number in the key code. Install the first tumbler in the slot nearest the head of the lock cylinder. Install the remaining tumblers for cuts 6 and 8 following the key code and same process. Press the tumblers in place until they are secure.
- Inspect for correct loading of the tumblers by inserting the key into cylinder. The side bar should drop flush with the lock cylinder body diameter.
- Lightly lubricate the outside surfaces in the tumbler area of the lock body and down the key slot using the provided grease. Insert and extract the key 5 times to lubricate the keyway.
- Line-up the lock to the run position. Insert lock in steering column. Rotate lock to key out position and remove key. Insert key and rotate lock 3 times to distribute the grease from the lock to column housing inside diameter.
Lifting and Jacking the Vehicle
| WARNING | To avoid any vehicle damage, serious personal injury or death, always use the jackstands to support the vehicle when lifting the vehicle with a jack. |
| WARNING | To avoid any vehicle damage, serious personal injury or death when major components are removed from the vehicle and the vehicle is supported by a hoist, support the vehicle with jack stands at the opposite end from which the components are being removed and strap the vehicle to the hoist. |
| CAUTION | Perform the following steps before beginning any vehicle lifting or jacking procedure: Remove or secure all of the vehicle contents in order to avoid any shifting or any movement that may occur during the vehicle lifting or jacking procedure. The lifting equipment or the jacking equipment weight rating must meet or exceed the weight of the vehicle and any vehicle contents. The lifting equipment or the jacking equipment must meet the operational standards of the lifting equipment or jacking equipment manufacturer. Perform the vehicle lifting or jacking procedure on a clean, hard, dry, level surface. Perform the vehicle lifting or jacking procedure only at the identified lift points. DO NOT allow the lifting equipment or jacking equipment to contact any other vehicle components. Failure to perform the previous steps could result in damage to the lifting equipment or the jacking equipment, the vehicle, and/or the vehicle contents. |
For lifting the vehicle, various lift points are recommended. Before you begin any lifting procedure, place the vehicle on a clean, hard, level surface. Verify that all the lifting equipment meets weight standards and is in good working order. Verify that all of the vehicle loads are equally distributed and secure. If you are only supporting the vehicle at the frame side rails, verify that the lifting equipment does not put too much stress on or weaken, the frame side rails.
During hoisting, do NOT damage the fuel tanks, the exhaust system or the underbody.
Scheme 9
| Callout | Component Name |
|---|---|
| 1 | Lower Control Arm Contact Points |
| 2 | Front Frame Contact Points |
| 3 | Rear Frame Contact Points |
| 4 | Rear Axle Contact Points |
| 5 | Differential Contact Points |
Frame Contact Hoist
Front Hoist Pads
Scheme 10
Note. The front hoist pads must not contact the rocker panels, the front fenders or the floor pan.
Position the front hoist pads under the front frame for 1500 pickup and all utilities just after the rear edge of the number 1 body mount bracket.
Rear Hoist Pads
Scheme 11
Note. The rear hoist pads must not contact the body rocker panels or the floor pan.
Position the rear hoist pads under the rear spring, just behind the hanger.
Suspension Contact Hoist
Front Lift
Scheme 12
Position the front lift under the outer edge of the front suspension lower control arms.
Rear Lift
Scheme 13
Position the rear lift under the axle housing tubes on each side of the differential.
Do not damage the stabilizer bar.
Jacking
When you are lifting a vehicle with a vehicle jack or a floor jack, block the wheels at the opposite end from which you are lifting. Use jack stands to provide additional support.
Under the Frame Rails
Scheme 14
Note. The floor jack pad must not contact rocker panel or the floor pan.
Position the floor jack pad under the frame rail pad.
Under the Rear Differential
Scheme 15
Position the floor jack pad under the center of the rear axle differential.
Do not damage the establisher bar.
Under the Rear Spring Hanger
Scheme 16
Position the jack under the rear spring hanger.
Jack Stands
When you support the vehicle with jack stands, place the jack stands under the frame, the front suspension crossmember or the rear axle.
