Engine Cooling System: Removal & Installation GMC Sierra III

Cooling System (Mechanical) 26 illustrations ~3153 words

Radiator Surge Tank Replacement (LV3)

CalloutComponent Name
Preliminary Procedures Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) . Remove the air cleaner assembly. Refer to Air Cleaner Assembly Replacement . Remove the radiator surge tank inlet hoses from the radiator surge tank. Refer to Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Radiator L83, LV3) , Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet L83) , Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet LV3) .
1Surge Tank Bolt CAUTION: Refer to Fastener Caution . Tighten 10 (89 lb in)
2Surge Tank Nut Tighten 10 (89 lb in)
3Surge Tank Procedures Fill the cooling system to the proper level. Inspect the cooing system for leaks.
CAUTION
Refer to Fastener Caution .

Radiator Surge Tank Replacement (LV3)

Scheme 1

Scheme 1: Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Radiator L83, LV3)
Scheme 1: Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Radiator L83, LV3)
CalloutComponent Name
Preliminary Procedure Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) .
1Radiator Surge Tank Inlet Hose Clamps (Qty: 2) Procedure Using BO-38185 hose clamp pliers, reposition the radiator surge tank inlet hose clamps. Special Tools BO-38185 Hose Clamp Pliers For equivalent regional tools, refer to Special Tools .
2Radiator Surge Tank Inlet Hose Procedures Fill the cooling system to the proper level. Inspect the cooing system for leaks.

Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Radiator L83, LV3)

Scheme 2

Scheme 2: Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet L83)
Scheme 2: Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet L83)
CalloutComponent Name
CAUTION: Use caution when removing the hose from the thermostat housing. The plastic thermostat housing may break if excessive force is used. Preliminary Procedure Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) . Remove the air cleaner outlet duct. Refer to Air Cleaner Outlet Duct Replacement .
1Radiator Surge Tank Inlet Hose Clamps (Qty: 2) Procedure Using BO-38185 hose clamp pliers, reposition the radiator surge tank inlet hose clamps. Special Tools BO-38185 Hose Clamp Pliers For equivalent regional tools, refer to Special Tools .
2Radiator Surge Tank Inlet Hose Retainers (Qty: 2) Procedure Remove radiator surge tank inlet hose from retainers.
3Radiator Surge Tank Inlet Hose Procedures Fill the cooling system to the proper level. Inspect the cooing system for leaks.
CAUTION
Use caution when removing the hose from the thermostat housing. The plastic thermostat housing may break if excessive force is used.

Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet L83)

Scheme 3

Scheme 3: Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet LV3)
Scheme 3: Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet LV3)
CalloutComponent Name
CAUTION: Use caution when removing the hose from the thermostat housing. The plastic thermostat housing may break if excessive force is used. Preliminary Procedure Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) . Remove the air cleaner outlet duct. Refer to Air Cleaner Outlet Duct Replacement .
1Radiator Surge Tank Inlet Hose Clamps (Qty: 2) Procedure Using BO-38185 hose clamp pliers, reposition the radiator surge tank inlet hose clamps. Special Tools BO-38185 Hose Clamp Pliers For equivalent regional tools, refer to Special Tools .
2Radiator Surge Tank Inlet Hose Retainers (Qty: 2) Procedure Remove radiator surge tank inlet hose from retainers.
3Radiator Surge Tank Inlet Hose Procedures Fill the cooling system to the proper level. Inspect the cooing system for leaks.
CAUTION
Use caution when removing the hose from the thermostat housing. The plastic thermostat housing may break if excessive force is used.

Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet LV3)

Scheme 4

Scheme 4: Radiator Inlet Hose Replacement (L83)
Scheme 4: Radiator Inlet Hose Replacement (L83)
CalloutComponent Name
Preliminary Procedure Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) . Remove the air cleaner outlet duct. Refer to Air Cleaner Outlet Duct Replacement .
1Radiator Inlet Hose Clamps (Qty: 2) Procedure Using BO-38185 hose clamp pliers, reposition the radiator inlet hose clamps. Special Tools BO-38185 Hose Clamp Pliers For equivalent regional tools, refer to Special Tools .
2Radiator Inlet Hose Procedures Fill the cooling system to the proper level. Inspect the cooing system for leaks.

Radiator Inlet Hose Replacement (L83)

Radiator Inlet Hose Replacement (LV3)

CalloutComponent Name
Preliminary Procedure Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) . Remove the air cleaner outlet duct. Refer to Air Cleaner Outlet Duct Replacement .
1Radiator Inlet Hose Clamps (Qty: 2) Procedure Using BO-38185 hose clamp pliers, reposition the radiator inlet hose clamps. Special Tools BO-38185 Hose Clamp Pliers For equivalent regional tools, refer to Special Tools .
2Radiator Inlet Hose Procedures Fill the cooling system to the proper level. Inspect the cooing system for leaks.

Radiator Inlet Hose Replacement (LV3)

Scheme 5

Scheme 5: Radiator Outlet Hose Replacement (L83)
Scheme 5: Radiator Outlet Hose Replacement (L83)
CalloutComponent Name
Preliminary Procedures Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) . Remove the air cleaner outlet duct. Refer to Air Cleaner Outlet Duct Replacement .
1Radiator Outlet Hose Clamp (Qty: 3) Procedure Using BO-38185 hose clamp pliers, reposition the radiator outlet hose clamps. Special Tools BO-38185 Hose Clamp Pliers For equivalent regional tools, refer to Special Tools .
2Radiator Outlet Hose Retainer (Qty: 3) Procedure Remove the radiator outlet hose retainers from the engine coolant fan rear shroud.
3Radiator Outlet Hose Procedure Fill the cooling system to the proper level. Inspect the cooing system for leaks.

Radiator Outlet Hose Replacement (L83)

Radiator Outlet Hose Replacement (LV3)

CalloutComponent Name
Preliminary Procedure Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) . Remove the air cleaner outlet duct. Refer to Air Cleaner Outlet Duct Replacement .
1Radiator Outlet Hose Clamp (Qty: 3) Procedure Using BO-38185 hose clamp pliers, reposition the radiator outlet hose clamps. Special Tools BO-38185 Hose Clamp Pliers For equivalent regional tools, refer to Special Tools .
2Radiator Outlet Hose Retainer (Qty: 3) Procedure Remove the radiator outlet hose retainers from the engine coolant fan rear shroud.
3Radiator Outlet Hose Procedure Fill the cooling system to the proper level. Inspect the cooing system for leaks.

Radiator Outlet Hose Replacement (LV3)

Scheme 6

Scheme 6: Engine Coolant Fan Replacement (L83, LV3)
Scheme 6: Engine Coolant Fan Replacement (L83, LV3)
CalloutComponent Name
Preliminary Procedure Remove engine coolant fan rear shroud. Refer to Engine Coolant Fan Rear Shroud Replacement (LV3) , Engine Coolant Fan Rear Shroud Replacement (L83) . NOTE: The left and right side engine coolant fans are different. Ensure you install the left or right side engine coolant fans on the proper side.
1Engine Coolant Fan Fastener (Qty: 6) Three Per Motor CAUTION: Refer to Fastener Caution .
2Engine Coolant Fan (Qty: 2)
NOTE
The left and right side engine coolant fans are different. Ensure you install the left or right side engine coolant fans on the proper side.
CAUTION
Refer to Fastener Caution .

Engine Coolant Fan Replacement (L83, LV3)

Removal Procedure

  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(ref-650992-S00449252152014081900000) .
  2. Drain the cooling system. Refer to «Cooling System Draining and Filling (Vac-N-Fill Gasoline)»(ref-651030-S17228941602014081900000) , «Cooling System Draining and Filling (Static Fill)»(ref-651030-S35285794042014081900000) .
  3. Remove the right exhaust manifold outlet pipe. Refer to .
  4. Remove the bolts (1) to the rear EGR bracket (2).
  5. Lower the vehicle.
  6. Remove the generator. Refer to «Generator Replacement (L83, L86, LV1, LV3)»(ref-651026-S27259725632014081900000) .
  7. Remove the intake manifold tube. Refer to .
  8. If equipped with LML, remove the EGR bypass pipe bolts (1) and the rear EGR bypass pipe bolts (3).
  9. If equipped with LML, remove the EGR bypass pipe center mounting bolt (5) and remove the EGR bypass pipe (6).
  10. Remove the rear EGR cooler to front EGR cooler bolts (1).
  11. Remove the turbocharger air inlet adapter. Refer to .
  12. Remove the following hoses: Cooling Feed Hose (1) Cooling Feed Hose (2) Heater Water Bypass Hose (3) Heater Inlet Hose (4)
  13. Remove the rear EGR mounting bolts (1) and let the bracket fall to the floor.
  14. Disconnect the EGR bypass valve electrical connector.
  15. Remove the rear EGR cooler and discard the gasket.
  16. Transfer the EGR bypass valve to the rear EGR cooler.

Installation Procedure

  1. Loosely install the rear EGR mounting bolt (1) to the EGR bracket (2) as shown.
  2. Position the rear EGR cooler (1) and the NEW gasket (2), on top of the engine.
  3. Rotate the EGR bracket into place and loosely tighten the rear EGR mounting bolts (1).
  4. Raise the vehicle.
  5. Install the rear EGR bracket bolts (1) and tighten to 25 (18 lb ft).
  6. Lower the vehicle.
  7. Tighten the rear EGR mounting bolts (1) to 53 (39 lb ft).
  8. Install the turbocharger air inlet adapter to the turbocharger. Refer to .
  9. Install the front EGR cooler bolts to the rear EGR cooler and tighten the bolts (1) to 25 (18 lb ft).
  10. Install the following hoses: EGR Cooling Feed Hose (1) EGR Cooling Feed Hose (2) Heater Water Bypass Hose (3) Heater Inlet Hose (4)
  11. Connect the EGR bypass valve electrical connector.
  12. If equipped with LML, install the EGR bypass pipe center mounting bolt (5) and tighten to 10 (89 lb in).
  13. If equipped with LML, install the EGR bypass pipe bolts (1) and the rear EGR bypass pipe bolts (3). Tighten to 25 (18 lb ft).
  14. Install the intake manifold tube. Refer to .
  15. Install the right exhaust manifold outlet pipe. Refer to .
  16. Fill the cooling system. Refer to «Cooling System Draining and Filling (Vac-N-Fill Gasoline)»(ref-651030-S17228941602014081900000) , «Cooling System Draining and Filling (Static Fill)»(ref-651030-S35285794042014081900000) .
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(ref-650992-S00449252152014081900000) .
  2. Drain the cooling system. Refer to «Cooling System Draining and Filling (Vac-N-Fill Gasoline)»(ref-651030-S17228941602014081900000) , «Cooling System Draining and Filling (Static Fill)»(ref-651030-S35285794042014081900000) .
  3. Remove the generator. Refer to «Generator Replacement (L83, L86, LV1, LV3)»(ref-651026-S27259725632014081900000) .
  4. Reposition the A/C compressor without discharging the refrigerant. Refer to «Air Conditioning Compressor Replacement (LV3)»(ref-651014-S12955681432014081900000) , «Air Conditioning Compressor Replacement (L83)»(ref-651014-S30971541712014081900000) .
  5. Remove the turbocharger coolant feed hose. Refer to .
  6. Remove the intake manifold tube. Refer to .
  7. If equipped with LML, remove the EGR bypass pipe bolts (1) and the rear EGR bypass pipe bolts (3).
  8. If equipped with LML, remove the EGR bypass pipe center mounting bolt (5) and remove the EGR bypass pipe (6).
  9. Remove the EGR valve bolts (1) and disconnect the EGR valve electrical connector.
  10. Remove the EGR manifold cooling return hose (2) and the front EGR cooler mounting bolt (1).
  11. Remove the rear EGR cooler to front EGR cooler bolts (1).
  12. Remove the front EGR cooler mounting bolts (1).
  13. Remove the front EGR cooler (2) and discard the gasket (1).
  1. Position the front EGR cooler (2), with a NEW gasket, to the rear EGR cooler.
  2. Install the front EGR cooler to the rear EGR cooler. Tighten the bolts (1) to 25 N.m (18 lb ft).
  3. Install the front EGR mounting bolts (1) and tighten to 25 N.m (18 lb ft).
  4. Install the EGR manifold cooling return hose (2) and the mounting bolt (1). Tighten to 25 N.m (18 lb ft).
  5. Install NEW gaskets to the EGR valve; intake manifold and the front EGR cooler. Tighten the EGR valve bolts (1) to 25 N.m (18 lb ft).
  6. Connect the EGR valve electrical connector.
  7. If equipped with LML, install the EGR bypass pipe center mounting bolt (5) and tighten to 25 N.m (18 lb ft).
  8. If equipped with LML, install NEW gaskets (2, 4) and tighten the EGR bypass bolts (3) to 25 N.m (18 lb ft).
  9. If equipped with LML, install the EGR bypass valve to the EGR valve bolts (1). Tighten to 25 N.m (18 lb ft).
  10. Install the intake manifold tube. Refer to .
  11. Install the generator. Refer to «Generator Replacement (L83, L86, LV1, LV3)»(ref-651026-S27259725632014081900000) .
  12. Install the A/C compressor. Refer to «Air Conditioning Compressor Replacement (LV3)»(ref-651014-S12955681432014081900000) , «Air Conditioning Compressor Replacement (L83)»(ref-651014-S30971541712014081900000) .
  13. Fill the cooling system. Refer to «Cooling System Draining and Filling (Vac-N-Fill Gasoline)»(ref-651030-S17228941602014081900000) , «Cooling System Draining and Filling (Static Fill)»(ref-651030-S35285794042014081900000) .

Scheme 7

Scheme 7: Engine Coolant Thermostat Housing Replacement (L83 With Thermostat)
Scheme 7: Engine Coolant Thermostat Housing Replacement (L83 With Thermostat)
CalloutComponent Name
CAUTION: Use caution when removing the hose from the thermostat housing. The plastic thermostat housing may break if excessive force is used. Preliminary Procedures Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) . Remove the air cleaner outlet duct. Refer to Air Cleaner Outlet Duct Replacement . Disconnect the radiator inlet hose from the thermostat housing. Refer to Radiator Inlet Hose Replacement (L83) , Radiator Inlet Hose Replacement (LV3) . Disconnect the radiator surge tank inlet hose from the thermostat housing. Refer to Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Radiator L83, LV3) , Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet L83) , Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet LV3) .
1Thermostat Housing Bolt (Qty: 3) CAUTION: Refer to Fastener Caution . Procedure Remove the thermostat housing bolts. Tighten 10 (89 lb in)
2Thermostat Housing
3Thermostat Housing Gasket Procedure Install a new thermostat gasket.
CAUTION
Use caution when removing the hose from the thermostat housing. The plastic thermostat housing may break if excessive force is used.
CAUTION
Refer to Fastener Caution .

Engine Coolant Thermostat Housing Replacement (L83 With Thermostat)

Scheme 8

Scheme 8: Engine Coolant Thermostat Housing Replacement (LV3 With Thermostat)
Scheme 8: Engine Coolant Thermostat Housing Replacement (LV3 With Thermostat)
CalloutComponent Name
CAUTION: Use caution when removing the hose from the thermostat housing. The plastic thermostat housing may break if excessive force is used. Preliminary Procedures Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) . Remove the air cleaner outlet duct. Refer to Air Cleaner Outlet Duct Replacement . Disconnect the radiator inlet hose from the thermostat housing. Refer to Radiator Inlet Hose Replacement (L83) , Radiator Inlet Hose Replacement (LV3) . Disconnect the radiator surge tank inlet hose from the thermostat housing. Refer to Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Radiator L83, LV3) , Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet L83) , Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet LV3) .
1Thermostat Housing Bolt (Qty: 3) CAUTION: Refer to Fastener Caution . Procedure Remove the thermostat housing bolts. Tighten 10 N.m (89 lb in)
2Thermostat Housing
3Thermostat housing gasket Procedure Install a NEW thermostat gasket.
CAUTION
Use caution when removing the hose from the thermostat housing. The plastic thermostat housing may break if excessive force is used.
CAUTION
Refer to Fastener Caution .

Engine Coolant Thermostat Housing Replacement (LV3 With Thermostat)

Scheme 9

Scheme 9: Engine Coolant Manifold Replacement (L83)
Scheme 9: Engine Coolant Manifold Replacement (L83)
CalloutComponent Name
Preliminary Procedures Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) . Disconnect the engine coolant temperature sensor. Refer to Engine Coolant Temperature Sensor Replacement . Remove the generator and drive belt tensioner bracket. Refer to Generator Bracket Replacement (L83, L86) , Generator Bracket Replacement (LV1, LV3) , Generator Bracket Replacement (LML) . Remove the drive belt tensioner. Refer to Drive Belt Tensioner Replacement - Accessory (L83) . Disconnect the radiator surge tank inlet hose from the engine coolant manifold. Refer to Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Radiator L83, LV3) , Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet L83) , Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet LV3) . Disconnect the radiator inlet and outlet hoses from the engine coolant manifold. Refer to Radiator Inlet Hose Replacement (L83) , Radiator Inlet Hose Replacement (LV3) and Radiator Outlet Hose Replacement (L83) , Radiator Outlet Hose Replacement (LV3) . Disconnect the heater inlet and outlet hoses from the engine coolant manifold. Refer to Heater Inlet Hose Replacement (L83) , Heater Inlet Hose Replacement (LV3) and Heater Outlet Hose Replacement (L83) , Heater Outlet Hose Replacement (LV3) . NOTE: Tighten the water pump bolts in the sequence shown.
1Engine Coolant Manifold Fastener (Qty: 1) CAUTION: Refer to Fastener Caution . Procedure Clean the fastener threads and apply thread locker. Refer to Adhesives, Fluids, Lubricants and Sealers . Tighten 25 (18 lb ft)
2Engine Coolant Manifold Fastener (Qty: 6) CAUTION: Refer to Fastener Caution . Procedure Clean the fastener threads and apply thread locker. Refer to Adhesives, Fluids, Lubricants and Sealers . Tighten 30 (22 lb ft)
3Engine Coolant Manifold
4Engine Coolant Manifold Gaskets Procedure Install a new engine coolant manifold gaskets.
NOTE
Tighten the water pump bolts in the sequence shown.
CAUTION
Refer to Fastener Caution .
CAUTION
Refer to Fastener Caution .

Engine Coolant Manifold Replacement (L83)

Scheme 10

Scheme 10: Engine Coolant Manifold Replacement (LV3)
Scheme 10: Engine Coolant Manifold Replacement (LV3)
CalloutComponent Name
Preliminary Procedures Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) . Disconnect the engine coolant temperature sensor. Refer to Engine Coolant Temperature Sensor Replacement . Remove the generator and drive belt tensioner bracket. Refer to Generator Bracket Replacement (L83, L86) , Generator Bracket Replacement (LV1, LV3) , Generator Bracket Replacement (LML) . Disconnect the radiator surge tank inlet hose from the engine coolant manifold. Refer to Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Radiator L83, LV3) , Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet L83) , Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet LV3) . Disconnect the radiator inlet and outlet hoses from the engine coolant manifold. Refer to Radiator Inlet Hose Replacement (L83) , Radiator Inlet Hose Replacement (LV3) and Radiator Outlet Hose Replacement (L83) , Radiator Outlet Hose Replacement (LV3) . Disconnect the heater inlet and outlet hoses from the engine coolant manifold. Refer to Heater Inlet Hose Replacement (L83) , Heater Inlet Hose Replacement (LV3) and Heater Outlet Hose Replacement (L83) , Heater Outlet Hose Replacement (LV3) . NOTE: Tighten the water pump bolts in the sequence shown.
1Engine Coolant Manifold Fastener (Qty: 1) CAUTION: Refer to Fastener Caution . Procedure Clean the fastener threads and apply thread locker. Refer to Adhesives, Fluids, Lubricants and Sealers . Tighten 25 (18 lb ft)
2Engine Coolant Manifold Fastener (Qty: 6) CAUTION: Refer to Fastener Caution . Procedure Clean the fastener threads and apply thread locker. Refer to Adhesives, Fluids, Lubricants and Sealers . Tighten 30 (22 lb ft)
3Engine Coolant Manifold
4Engine Coolant Manifold Gaskets Procedure Install NEW engine coolant manifold gaskets.
NOTE
Tighten the water pump bolts in the sequence shown.
CAUTION
Refer to Fastener Caution .
CAUTION
Refer to Fastener Caution .

Engine Coolant Manifold Replacement (LV3)

Scheme 11

Scheme 11: Water Pump Replacement (L83)
Scheme 11: Water Pump Replacement (L83)
CalloutComponent Name
Preliminary Procedures Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) . Remove the drive belt. Refer to Drive Belt Replacement - Accessory (L83) .
1Water Pump Bolt (Qty: 6) CAUTION: Refer to Fastener Caution . Procedure Remove the water pump bolts. Tighten 10 (89 lb in)
2Water Pump
3Water Pump Gasket Procedure Install a new water pump gasket.
CAUTION
Refer to Fastener Caution .

Water Pump Replacement (L83)

Scheme 12

Scheme 12: Water Pump Replacement (LV3)
Scheme 12: Water Pump Replacement (LV3)
CalloutComponent Name
Preliminary Procedures Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) . Remove the drive belt. Refer to Drive Belt Replacement - Accessory .
1Water Pump Bolt (Qty: 6) CAUTION: Refer to Fastener Caution . Procedure Remove the water pump bolts. Tighten 10 (89 lb in)
2Water Pump
3Water Pump Gasket Procedure Install a NEW water pump gasket.
CAUTION
Refer to Fastener Caution .

Water Pump Replacement (LV3)

Scheme 13

Scheme 13: Radiator Drain Cock Replacement (LV3 L83)
Scheme 13: Radiator Drain Cock Replacement (LV3 L83)
CalloutComponent Name
Preliminary Procedures Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Place a drain pan under the radiator drain cock. Attach a rubber hose to the radiator drain port to guide the coolant into the drain pan Drain the engine coolant. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) .
1Radiator Drain Cock CAUTION: Refer to Fastener Caution . Procedures Fill the cooling system to the proper level. Inspect the cooing system for leaks.
CAUTION
Refer to Fastener Caution .

Radiator Drain Cock Replacement (LV3 L83)

  1. Remove the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(ref-651029-S17583717992014081900000) .
  2. Remove the front compartment side sight shield. Refer to «Front Compartment Front Sight Shield Replacement»(ref-651006-S09190975902014081900000) .
  3. Unclip the radiator surge tank inlet hose (3) from the engine coolant fan rear shroud and reposition out of the way. Refer to «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Radiator L83, LV3)»(ref-651030-S13833522632014081900000) , «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet L83)»(ref-651030-S37127330382014081900000) , «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet LV3)»(ref-651030-S12867252132014081900000) .
  4. Disconnect the electrical connectors from the engine coolant fans and reposition out of the way.
  5. Unclip the electrical harness from the engine coolant fan rear shroud.
  6. Unclip the radiator outlet hose retainers (2) from the engine coolant fan rear shroud. Refer to «Radiator Outlet Hose Replacement (L83)»(ref-651030-S26105066592014081900000) , «Radiator Outlet Hose Replacement (LV3)»(ref-651030-S17689244922014081900000) .
  7. Remove the transmission fluid cooler inlet and outlet pipe from the radiator. Refer to «Transmission Fluid Cooler Inlet and Outlet Pipe Replacement (LV3)»(ref-651119-S27636677462014081900000) , «Transmission Fluid Cooler Inlet and Outlet Pipe Replacement (L83)»(ref-651119-S26006950032014081900000) .
  8. Unclip the transmission fluid cooler inlet and outlet pipe from the engine coolant fan rear shroud.
  9. Remove the engine oil cooler hose from the radiator. Refer to «Engine Oil Cooler Hose Replacement»(ref-651099-S29242148532014081900000) .
  10. Unclip the engine oil cooler hose from the engine coolant fan rear shroud.
  11. Remove the engine coolant fan rear shroud bolts (1).
  12. Remove the engine coolant fan rear shroud (1) from the vehicle.
  1. Install the engine coolant fan rear shroud (1) to the vehicle.
  2. Install the engine coolant fan rear fan shroud bolts (1) and tighten to 7 (62 lb in).
  3. Install the engine oil cooler hose to the radiator. Refer to «Engine Oil Cooler Hose Replacement»(ref-651099-S29242148532014081900000) .
  4. Install the engine oil cooler hose to the engine coolant fan rear shroud.
  5. Install the transmission fluid cooler inlet and outlet pipe to the radiator. Refer to «Transmission Fluid Cooler Inlet and Outlet Pipe Replacement (LV3)»(ref-651119-S27636677462014081900000) , «Transmission Fluid Cooler Inlet and Outlet Pipe Replacement (L83)»(ref-651119-S26006950032014081900000) .
  6. Install the transmission fluid cooler inlet and outlet pipe to the engine coolant fan rear shroud.
  7. Install the radiator outlet hose retainers (2) to the engine coolant fan rear shroud. Refer to «Radiator Outlet Hose Replacement (L83)»(ref-651030-S26105066592014081900000) , «Radiator Outlet Hose Replacement (LV3)»(ref-651030-S17689244922014081900000) .
  8. Install the electrical harness to the engine coolant fan rear shroud.
  9. Connect the electrical connectors to the engine coolant fans.
  10. Install the radiator surge tank inlet hose (3) to the engine coolant fan rear shroud. Refer to «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Radiator L83, LV3)»(ref-651030-S13833522632014081900000) , «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet L83)»(ref-651030-S37127330382014081900000) , «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet LV3)»(ref-651030-S12867252132014081900000) .
  11. Install the front compartment side sight shield. Refer to «Front Compartment Front Sight Shield Replacement»(ref-651006-S09190975902014081900000) .
  12. Install the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(ref-651029-S17583717992014081900000) .
  1. Remove the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(ref-651035-S07307479992014081900000) .
  2. Remove the front compartment side sight shield. Refer to «Front Compartment Front Sight Shield Replacement»(ref-651006-S09190975902014081900000) .
  3. Unclip the radiator surge tank inlet hose (3) from the engine coolant fan rear shroud and reposition out of the way. Refer to «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Radiator L83, LV3)»(ref-651030-S13833522632014081900000) , «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet L83)»(ref-651030-S37127330382014081900000) , «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet LV3)»(ref-651030-S12867252132014081900000) .
  4. Disconnect the electrical connectors from the engine coolant fans and reposition out of the way.
  5. Unclip the electrical harness from the engine coolant fan rear shroud.
  6. Unclip the radiator outlet hose retainers (2) from the engine coolant fan rear shroud. Refer to «Radiator Outlet Hose Replacement (L83)»(ref-651030-S26105066592014081900000) , «Radiator Outlet Hose Replacement (LV3)»(ref-651030-S17689244922014081900000) .
  7. Remove the transmission fluid cooler inlet and outlet pipe from the radiator. Refer to «Transmission Fluid Cooler Inlet and Outlet Pipe Replacement (LV3)»(ref-651119-S27636677462014081900000) , «Transmission Fluid Cooler Inlet and Outlet Pipe Replacement (L83)»(ref-651119-S26006950032014081900000) .
  8. Unclip the transmission fluid cooler inlet and outlet pipe from the engine coolant fan rear shroud.
  9. Remove the engine oil cooler hose from the radiator. Refer to «Engine Oil Cooler Hose Replacement (L83)»(ref-651100-S13255344152014081900000) .
  10. Unclip the engine oil cooler hose from the engine coolant fan rear shroud.
  11. Remove the engine coolant fan rear shroud bolts (1).
  12. Remove the engine coolant fan rear shroud (1) from the vehicle.
  1. Install the engine coolant fan rear shroud (1) to the radiator.
  2. Install the engine coolant fan rear fan shroud bolts (1) and tighten to 7 (62 lb in).
  3. Install the engine oil cooler hose to the radiator. Refer to «Engine Oil Cooler Hose Replacement (L83)»(ref-651100-S13255344152014081900000) .
  4. Install the engine oil cooler hose to the engine coolant fan rear shroud.
  5. Install the transmission fluid cooler inlet and outlet pipe to the radiator. Refer to «Transmission Fluid Cooler Inlet and Outlet Pipe Replacement (LV3)»(ref-651119-S27636677462014081900000) , «Transmission Fluid Cooler Inlet and Outlet Pipe Replacement (L83)»(ref-651119-S26006950032014081900000) .
  6. Install the transmission fluid cooler inlet and outlet pipe to the engine coolant fan rear shroud.
  7. Install the radiator outlet hose retainers (2) to the engine coolant fan rear shroud. Refer to «Radiator Outlet Hose Replacement (L83)»(ref-651030-S26105066592014081900000) , «Radiator Outlet Hose Replacement (LV3)»(ref-651030-S17689244922014081900000) .
  8. Connect the electrical connectors to the engine coolant fans.
  9. Install the electrical harness to the engine coolant fan rear shroud.
  10. Install the radiator surge tank inlet hose (3) to the engine coolant fan rear shroud. Refer to «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Radiator L83, LV3)»(ref-651030-S13833522632014081900000) , «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet L83)»(ref-651030-S37127330382014081900000) , «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet LV3)»(ref-651030-S12867252132014081900000) .
  11. Install the front compartment side sight shield. Refer to «Front Compartment Front Sight Shield Replacement»(ref-651006-S09190975902014081900000) .
  12. Install the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(ref-651035-S07307479992014081900000) .
  1. Drain the cooling system. Refer to «Cooling System Draining and Filling (Vac-N-Fill Gasoline)»(ref-651030-S17228941602014081900000) , «Cooling System Draining and Filling (Static Fill)»(ref-651030-S35285794042014081900000) .
  2. Remove the engine coolant fan rear shroud. Refer to «Engine Coolant Fan Rear Shroud Replacement (LV3)»(ref-651030-S38023999942014081900000) , «Engine Coolant Fan Rear Shroud Replacement (L83)»(ref-651030-S08362403652014081900000) .
  3. Remove the radiator surge tank inlet hose (2) from the radiator. Refer to «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Radiator L83, LV3)»(ref-651030-S13833522632014081900000) , «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet L83)»(ref-651030-S37127330382014081900000) , «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet LV3)»(ref-651030-S12867252132014081900000) .
  4. Remove the radiator inlet hose (2) from the radiator. Refer to «Radiator Inlet Hose Replacement (L83)»(ref-651030-S22518516992014081900000) , «Radiator Inlet Hose Replacement (LV3)»(ref-651030-S28769280132014081900000) .
  5. Remove the radiator outlet hose (3) from the radiator. Refer to «Radiator Outlet Hose Replacement (L83)»(ref-651030-S26105066592014081900000) , «Radiator Outlet Hose Replacement (LV3)»(ref-651030-S17689244922014081900000) .
  6. Remove the radiator air upper baffle and deflector (1). Refer to «Radiator Air Upper Baffle and Deflector Replacement (LV3 L83)»(ref-651030-S02292542272014081900000) .
  7. Remove the air conditioning condenser bracket (2) from the radiator. Refer to «Air Conditioning Condenser Bracket Replacement (L83, LV3)»(ref-651014-S34403851512014081900000) .
  8. Without disconnecting the air conditioning compressor and condenser hoses, carefully lift the air conditioning condenser assembly off the radiator and position out of the way.
  9. Tilt the radiator rearward and release the radiator air lower baffle retaining tabs from the radiator. Refer to «Radiator Air Lower Baffle Replacement (L83, LV3)»(ref-651030-S11223842052014081900000) .
  10. Remove the radiator (1) from the vehicle.
  11. If replacing the radiator transfer the components as necessary.
  1. Install the radiator (1) to the vehicle.
  2. Ensure the radiator air lower baffle retaining tabs are engaged to the radiator. Refer to «Radiator Air Lower Baffle Replacement (L83, LV3)»(ref-651030-S11223842052014081900000) .
  3. Carefully install the air conditioning condenser assembly to the radiator.
  4. Install the air conditioning condenser bracket (2) to the radiator. Refer to «Air Conditioning Condenser Bracket Replacement (L83, LV3)»(ref-651014-S34403851512014081900000) .
  5. Install the radiator air upper baffle and deflector (1). Refer to «Radiator Air Upper Baffle and Deflector Replacement (LV3 L83)»(ref-651030-S02292542272014081900000) .
  6. Install the radiator outlet hose (3) to the radiator. Refer to «Radiator Outlet Hose Replacement (L83)»(ref-651030-S26105066592014081900000) , «Radiator Outlet Hose Replacement (LV3)»(ref-651030-S17689244922014081900000) .
  7. Install the radiator inlet hose (2) to the radiator. Refer to «Radiator Inlet Hose Replacement (L83)»(ref-651030-S22518516992014081900000) , «Radiator Inlet Hose Replacement (LV3)»(ref-651030-S28769280132014081900000) .
  8. Install the radiator surge tank inlet hose (2) to the radiator. Refer to «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Radiator L83, LV3)»(ref-651030-S13833522632014081900000) , «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet L83)»(ref-651030-S37127330382014081900000) , «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet LV3)»(ref-651030-S12867252132014081900000) .
  9. Install the engine coolant fan rear shroud. Refer to «Engine Coolant Fan Rear Shroud Replacement (LV3)»(ref-651030-S38023999942014081900000) , «Engine Coolant Fan Rear Shroud Replacement (L83)»(ref-651030-S08362403652014081900000) .
  10. Fill the cooling system to the proper level. Refer to «Cooling System Draining and Filling (Vac-N-Fill Gasoline)»(ref-651030-S17228941602014081900000) , «Cooling System Draining and Filling (Static Fill)»(ref-651030-S35285794042014081900000) .
  11. Inspect the cooling system for leaks. Refer to «Cooling System Leak Testing»(ref-651030-S02693327442014081900000) .
  1. Drain the cooling system. Refer to «Cooling System Draining and Filling (Vac-N-Fill Gasoline)»(ref-651030-S17228941602014081900000) , «Cooling System Draining and Filling (Static Fill)»(ref-651030-S35285794042014081900000) .
  2. Remove the engine coolant fan rear shroud. Refer to «Engine Coolant Fan Rear Shroud Replacement (LV3)»(ref-651030-S38023999942014081900000) , «Engine Coolant Fan Rear Shroud Replacement (L83)»(ref-651030-S08362403652014081900000) .
  3. Remove the radiator air upper baffle and deflector (1). Refer to «Radiator Air Upper Baffle and Deflector Replacement (LV3 L83)»(ref-651030-S02292542272014081900000) .
  4. Remove the radiator surge tank inlet hose (2) from the radiator. Refer to «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Radiator L83, LV3)»(ref-651030-S13833522632014081900000) , «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet L83)»(ref-651030-S37127330382014081900000) , «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet LV3)»(ref-651030-S12867252132014081900000) .
  5. Remove the radiator inlet hose (2) from the radiator. Refer to «Radiator Inlet Hose Replacement (L83)»(ref-651030-S22518516992014081900000) , «Radiator Inlet Hose Replacement (LV3)»(ref-651030-S28769280132014081900000) .
  6. Remove the radiator outlet hose (3) from the radiator. Refer to «Radiator Outlet Hose Replacement (L83)»(ref-651030-S26105066592014081900000) , «Radiator Outlet Hose Replacement (LV3)»(ref-651030-S17689244922014081900000) .
  7. Remove the transmission fluid auxiliary cooler inlet pipe. Refer to «Transmission Fluid Auxiliary Cooler Inlet Pipe Replacement (L83)»(ref-651119-S00950157142014081900000) .
  8. Remove the transmission fluid auxiliary cooler outlet pipe. Refer to «Transmission Fluid Auxiliary Cooler Outlet Pipe Replacement (L83)»(ref-651119-S39973431362014081900000) .
  9. Remove the air conditioning condenser bracket (2) from the radiator. Refer to «Air Conditioning Condenser Bracket Replacement (L83, LV3)»(ref-651014-S34403851512014081900000) .
  10. Without disconnecting the air conditioning compressor and condenser hoses, carefully lift the air conditioning condenser assembly off the radiator and position out of the way.
  11. Tilt the radiator rearward and release the radiator air lower baffle retaining tabs from the radiator. Refer to «Radiator Air Lower Baffle Replacement (L83, LV3)»(ref-651030-S11223842052014081900000) .
  12. Remove the radiator (1) from the vehicle.
  13. If replacing the radiator transfer the components as necessary.
  1. Install the radiator (1) to the vehicle.
  2. Ensure the radiator air lower baffle retaining tabs are engaged to the radiator. Refer to «Radiator Air Lower Baffle Replacement (L83, LV3)»(ref-651030-S11223842052014081900000) .
  3. Carefully install the air conditioning condenser assembly to the radiator.
  4. Install the air conditioning condenser bracket (2) to the radiator. Refer to «Air Conditioning Condenser Bracket Replacement (L83, LV3)»(ref-651014-S34403851512014081900000) .
  5. Install the transmission fluid auxiliary cooler outlet pipe. Refer to «Transmission Fluid Auxiliary Cooler Outlet Pipe Replacement (L83)»(ref-651119-S39973431362014081900000) .
  6. Install the transmission fluid auxiliary cooler inlet pipe. Refer to «Transmission Fluid Auxiliary Cooler Inlet Pipe Replacement (L83)»(ref-651119-S00950157142014081900000) .
  7. Install the radiator outlet hose (3) to the radiator. Refer to «Radiator Outlet Hose Replacement (L83)»(ref-651030-S26105066592014081900000) , «Radiator Outlet Hose Replacement (LV3)»(ref-651030-S17689244922014081900000) .
  8. Install the radiator inlet hose (2) to the radiator. Refer to «Radiator Inlet Hose Replacement (L83)»(ref-651030-S22518516992014081900000) , «Radiator Inlet Hose Replacement (LV3)»(ref-651030-S28769280132014081900000) .
  9. Install the radiator surge tank inlet hose (2) to the radiator. Refer to «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Radiator L83, LV3)»(ref-651030-S13833522632014081900000) , «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet L83)»(ref-651030-S37127330382014081900000) , «Radiator Surge Tank Inlet Hose Replacement (Surge Tank To Water Outlet LV3)»(ref-651030-S12867252132014081900000) .
  10. Install the radiator air upper baffle and deflector (1). Refer to «Radiator Air Upper Baffle and Deflector Replacement (LV3 L83)»(ref-651030-S02292542272014081900000) .
  11. Install the engine coolant fan rear shroud. Refer to «Engine Coolant Fan Rear Shroud Replacement (LV3)»(ref-651030-S38023999942014081900000) , «Engine Coolant Fan Rear Shroud Replacement (L83)»(ref-651030-S08362403652014081900000) .
  12. Fill the cooling system to the proper level. Refer to «Cooling System Draining and Filling (Vac-N-Fill Gasoline)»(ref-651030-S17228941602014081900000) , «Cooling System Draining and Filling (Static Fill)»(ref-651030-S35285794042014081900000) .
  13. Inspect the cooling system for leaks. Refer to «Cooling System Leak Testing»(ref-651030-S02693327442014081900000) .

Scheme 14

Scheme 14: Radiator Inner Grille Replacement (LV3)
Scheme 14: Radiator Inner Grille Replacement (LV3)
CalloutComponent Name
Preliminary Procedure Remove the front grille from the vehicle. Refer to Front Grille Replacement (Chevrolet) , Front Grille Replacement (GMC) .
1Radiator Inner Grille Screw (Qty: 14) CAUTION: Refer to Fastener Caution .
2Radiator Inner Grille
CAUTION
Refer to Fastener Caution .

Radiator Inner Grille Replacement (LV3)

Scheme 15

Scheme 15: Radiator Inner Grille Replacement (L83)
Scheme 15: Radiator Inner Grille Replacement (L83)
CalloutComponent Name
Preliminary Procedure Remove the front grille from the vehicle. Refer to Front Grille Replacement (Chevrolet) , Front Grille Replacement (GMC) .
1Radiator Inner Grille Screw (Qty: 11) CAUTION: Refer to Fastener Caution .
2Radiator Inner Grille
CAUTION
Refer to Fastener Caution .

Radiator Inner Grille Replacement (L83)

Scheme 16

Scheme 16: Radiator Support Baffle Replacement (LV3)
Scheme 16: Radiator Support Baffle Replacement (LV3)
CalloutComponent Name
Preliminary Procedures Remove the air cleaner assembly. Refer to Air Cleaner Assembly Replacement . Remove the electrical harness from the radiator support baffle and reposition out of the way.
1Radiator Support Baffle Retainer (Qty: 4)
2Radiator Support Baffle

Radiator Support Baffle Replacement (LV3)

Radiator Support Baffle Replacement (L83)

CalloutComponent Name
Preliminary Procedures Remove the air cleaner assembly. Refer to Air Cleaner Assembly Replacement . Remove the electrical harness from the radiator support baffle and reposition out of the way.
1Radiator Support Baffle Retainer (Qty: 4)
2Radiator Support Baffle

Radiator Support Baffle Replacement (L83)

Scheme 17

Scheme 17: Radiator Air Baffle Replacement - Left (LV3)
Scheme 17: Radiator Air Baffle Replacement - Left (LV3)
CalloutComponent Name
Preliminary Procedure Remove the air conditioning condenser from the vehicle. Refer to Air Conditioning Condenser Replacement (LV3) , Air Conditioning Condenser Replacement (L83) .
1Radiator Air Baffle Left Procedure Remove the radiator air baffle left from the radiator air lower baffle and remove from the condenser.

Radiator Air Baffle Replacement - Left (LV3)

Scheme 18

Scheme 18: Radiator Air Baffle Replacement - Left (L83)
Scheme 18: Radiator Air Baffle Replacement - Left (L83)
CalloutComponent Name
Preliminary Procedure Remove the air conditioning condenser from the vehicle. Refer to Air Conditioning Condenser Replacement (LV3) , Air Conditioning Condenser Replacement (L83) .
1Radiator Air Baffle Left Procedure Remove the radiator air baffle left from the radiator air lower baffle and remove from the condenser.

Radiator Air Baffle Replacement - Left (L83)

Scheme 19

Scheme 19: Radiator Air Baffle Replacement - Right (LV3)
Scheme 19: Radiator Air Baffle Replacement - Right (LV3)
CalloutComponent Name
Preliminary Procedure Remove the air conditioning condenser from the vehicle. Refer to Air Conditioning Condenser Replacement (LV3) , Air Conditioning Condenser Replacement (L83) .
1Radiator Air Baffle Right Procedure Remove the radiator air baffle right from the radiator air lower baffle and remove from the condenser.

Radiator Air Baffle Replacement - Right (LV3)

Scheme 20

Scheme 20: Radiator Air Baffle Replacement - Right (L83)
Scheme 20: Radiator Air Baffle Replacement - Right (L83)
CalloutComponent Name
Preliminary Procedure Remove the air conditioning condenser from the vehicle. Refer to Air Conditioning Condenser Replacement (LV3) , Air Conditioning Condenser Replacement (L83) .
1Radiator Air Baffle Right Procedure Remove the radiator air baffle right from the radiator air lower baffle and remove from the condenser.

Radiator Air Baffle Replacement - Right (L83)

Scheme 21

Scheme 21: Radiator Air Lower Baffle Replacement (L83, LV3)
Scheme 21: Radiator Air Lower Baffle Replacement (L83, LV3)
CalloutComponent Name
Preliminary Procedures Remove the engine coolant fan rear shroud from the vehicle. Refer to Engine Coolant Fan Rear Shroud Replacement (LV3) , Engine Coolant Fan Rear Shroud Replacement (L83) . Remove the front end upper tie bar support. Refer to Front End Upper Tie Bar Support Replacement . Raise the condenser and radiator as and assembly (CRA) upward and support CRA above lower tie-bar. Push downward on radiator air lower baffle to remove the left and right radiator air baffle retaining tabs from the radiator air lower baffle. Refer to Radiator Air Baffle Replacement - Left (LV3) , Radiator Air Baffle Replacement - Left (L83) and Radiator Air Baffle Replacement - Right (LV3) , Radiator Air Baffle Replacement - Right (L83) . NOTE: Some early builds have 1 or 2 tie straps holding the baffle to the radiator at the inner tabs. Cut tie strap before removing baffle.
1Radiator Air Lower Baffle Procedure Push each of the four radiator air lower baffle retaining tabs inward to disengage the radiator air lower baffle from the radiator.
NOTE
Some early builds have 1 or 2 tie straps holding the baffle to the radiator at the inner tabs. Cut tie strap before removing baffle.

Radiator Air Lower Baffle Replacement (L83, LV3)

Scheme 22

Scheme 22: Radiator Air Upper Baffle and Deflector Replacement (LV3 L83)
Scheme 22: Radiator Air Upper Baffle and Deflector Replacement (LV3 L83)
CalloutComponent Name
Preliminary Procedures Remove the front compartment front side sight shield. Refer to Front Compartment Front Sight Shield Replacement . Remove the front end upper tie bar support. Refer to Front End Upper Tie Bar Support Replacement .
1Radiator Air Upper Baffle and Deflector Procedure Unclip the radiator air upper baffle and deflector from the radiator and lift up to remove.

Radiator Air Upper Baffle and Deflector Replacement (LV3 L83)

Scheme 23

Scheme 23: Radiator Air Seal Replacement (LV3 L83)
Scheme 23: Radiator Air Seal Replacement (LV3 L83)
CalloutComponent Name
Preliminary Procedure Remove the headlamp radiator grille mount panel from the vehicle. Refer to Headlamp and Radiator Grille Mount Panel Replacement .
1Radiator Air Seal Retainer (Qty: 10)
2Radiator Air Seal

Radiator Air Seal Replacement (LV3 L83)

Scheme 24

Scheme 24: Coolant Heater Replacement (L83)
Scheme 24: Coolant Heater Replacement (L83)
CalloutComponent Name
Preliminary Procedure Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) .
1Coolant Heater Connector
2Coolant Heater CAUTION: Refer to Fastener Caution . Procedure Remove the engine coolant heater. Tighten 50 (37 lb ft)
CAUTION
Refer to Fastener Caution .

Coolant Heater Replacement (L83)

Scheme 25

Scheme 25: Coolant Heater Replacement (LV3)
Scheme 25: Coolant Heater Replacement (LV3)
CalloutComponent Name
Preliminary Procedure Drain the cooling system. Refer to Cooling System Draining and Filling (Vac-N-Fill Gasoline) , Cooling System Draining and Filling (Static Fill) . Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle .
1Coolant Heater Connector
2Coolant Heater CAUTION: Refer to Fastener Caution . Procedure Remove the engine coolant heater. Tighten 50 (37 lb ft)
CAUTION
Refer to Fastener Caution .

Coolant Heater Replacement (LV3)

Scheme 26

Scheme 26: Coolant Heater Cord Replacement
Scheme 26: Coolant Heater Cord Replacement
CalloutComponent Name
Preliminary Procedure Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle .
1Coolant Heater Cord Connector
2Coolant Heater Cord Retainers
3Coolant Heater Cord Procedure Note the location and routing of the coolant heater cord prior to removal in order to ensure proper installation.

Coolant Heater Cord Replacement

More articles — Engine Cooling System
