Aiming Procedure

Park the vehicle on a level surface 7.6 m (25 ft) (3) away from a wall or other flat surface.
Measure the distance from the floor to the center of the fog lamp (5).
Using this measurement, mark the horizontal centerline of the fog lamp (1) on the flat surface directly in front of the vehicle.
Remove the front portion of the front wheel liner in order to access the adjusting screw.
Turn ON the fog lamps.
Reach inside of the front portion of the fender liner in order to access the fog lamp vertical adjustment screw on the bottom of the fog lamp.
Adjust the fog lamp so that the top edge of the fog lamp beam pattern is 100 mm (4 in) below the horizontal centerline (2).
Turn OFF the fog lamps.
Secure the forward edge of the front fender liner.

Scheme 36

Scheme 36: Front Side Marker Lamp Bulb Replacement (GMC)

Callout	Component Name
Preliminary Procedure: Remove either the LF or RF headlamp assembly. Refer to Headlamp Replacement (Chevrolet) or Headlamp Replacement (GMC ) or Headlamp Replacement (HD Diesel) .
1	Lamp Harness Socket Tip: Rotate the marker lamp socket a quarter turn counterclockwise and remove the lamp socket from the headlamp assembly.
2	Front Side Marker Lamp Bulb Tip: Pull the front side marker lamp bulb straight from the lamp socket.

Scheme 37

Scheme 37: Roof Clearance Center Lamp Replacement (U01)

Callout	Component Name
1	Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2	Roof Clearance Center Lamp Tip: Lift the lamp cover lens and replace the bulb as needed.

CAUTION
Refer to Fastener Caution .

Scheme 38

Scheme 38: Roof Clearance Outer Lamp Replacement (U01)

Callout	Component Name
1	Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2	Roof Clearance Outer Lamp Tip: Lift the lamp cover lens and replace the bulb as needed.

CAUTION
Refer to Fastener Caution .

Scheme 39

Scheme 39: Parking and Turn Signal Lamp Bulb Replacement (Chevrolet)

Callout	Component Name
Preliminary Procedure: Remove either the LF or RF headlamp assembly in order to access the headlamp bulbs. Refer to Headlamp Replacement (Chevrolet) or Headlamp Replacement (GMC ) or Headlamp Replacement (HD Diesel) .
1	Directional Bulb Sockets (Qty: 2) WARNING: Refer to Halogen Bulb Warning . Tip: Rotate the bulb sockets a quarter turn counter-clockwise to access the bulbs.
2	Directional Bulbs (Qty: 2) Tip: Pull the bulbs straight from the lamp sockets.

WARNING
Refer to Halogen Bulb Warning .

Scheme 40

Scheme 40: Parking and Turn Signal Lamp Bulb Replacement (GMC)

Callout	Component Name
Preliminary Procedure: Remove either the LF or RF headlamp assembly. Refer to Headlamp Replacement (Chevrolet) or Headlamp Replacement (GMC ) or Headlamp Replacement (HD Diesel) .
1	Directional Lamp Bulb Socket Tip: Rotate the marker lamp socket a quarter turn counterclockwise and remove the lamp socket from the headlamp assembly.
2	Directional / DRL Bulb Tip: Pull the marker lamp bulbs straight from the lamp bulb socket.

Scheme 41

Scheme 41: Pickup Box Identification Lamp Replacement (Chevrolet HD)

Callout	Component Name
1	Pick Up Box Identification Lamp Assembly Tip: Release the 3 integral clips securing the lamp assembly to the pick up box end panel.
2	Pick Up Box Identification Lamp Electrical Connector

Scheme 42

Scheme 42: Pickup Box Identification Lamp Replacement (GMC HD)

Callout	Component Name
1	Pick Up Box Identification Lamp Assembly Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2	Pick Up Box Identification Lamp Assembly
3	Pick Up Box Identification Lamp Electrical Connector
4	Rear Cross Sill Nut (Qty: 2)

CAUTION
Refer to Fastener Caution .

Scheme 43

Scheme 43: Rear Fender Clearance Lamp Replacement

Callout	Component Name
Preliminary Procedure Reach inside the rear fender and wheelhouse in order to disconnect the electrical connector for the rear fender lamp from the main chassis harness. Disengage the retainer securing the connector to the pick up box panel brace. From inside the wheelhouse push inward on the locking tab for the lamp assembly and push the lamp outward from the fender. Remove the lamp and electrical harness.
1	Rear Fender Clearance Lamps Tip: The amber lens is installed to the front of the rear fender and the red lens is installed at the rear of the rear fender.

Callout

Component Name

Preliminary Procedure Reach inside the rear fender and wheelhouse in order to disconnect the electrical connector for the rear fender lamp from the main chassis harness. Disengage the retainer securing the connector to the pick up box panel brace. From inside the wheelhouse push inward on the locking tab for the lamp assembly and push the lamp outward from the fender. Remove the lamp and electrical harness.

Rear Fender Clearance Lamps Tip: The amber lens is installed to the front of the rear fender and the red lens is installed at the rear of the rear fender.

Scheme 44

Scheme 44: High Mount Stop Lamp Replacement (Extended and Crew Cab)

Callout	Component Name
1	High Mounted Stop and Cargo Lamp Opening Cover Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2	High Mounted Stop and Cargo Lamp Opening Cover Tip: Pull the lamp rearward in order to access the electrical connector.
3	Electrical Connector
4	High Mounted Stop and Cargo Lamp Opening Cover Retainer Clip (Qty: 2)

CAUTION
Refer to Fastener Caution .

Scheme 45

Scheme 45: High Mount Stop Lamp Replacement (Regular Cab)

Callout	Component Name
1	High Mounted Stop and Cargo Lamp Opening Cover Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2	High Mounted Stop and Cargo Lamp Opening Cover Tip: Pull the lamp rearward in order to access the electrical connector.

CAUTION
Refer to Fastener Caution .

Scheme 46

Scheme 46: High Mount Stop Lamp Bulb Replacement (GMC Denali)

Callout	Component Name
Preliminary Procedure: Remove the high mounted stop lamp cover assembly. Refer to High Mount Stop Lamp Replacement (Extended and Crew Cab) or High Mount Stop Lamp Replacement (Regular Cab) .
1	High Mounted Stop and Cargo Lamp Opening Cover Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2	High Mounted Stop and Cargo Lamp Opening Cover
3	Cargo Lamp Bulb (Qty: 2) Tip: Rotate the bulb sockets a quarter turn counter-clockwise to unlock in order to remove the bulbs from the bulb sockets.
4	Brake Lamp Bulb (Qty: 2) Tip: Rotate the bulb sockets a quarter turn counter-clockwise to unlock in order to remove the bulbs from the bulb sockets.

CAUTION
Refer to Fastener Caution .

Scheme 47

Scheme 47: Backup Lamp Bulb Replacement (Chevrolet)

Callout	Component Name
Preliminary Procedure: Remove either the LR or RR tail lamp assembly. Refer to Tail Lamp Replacement (Chevrolet) or Tail Lamp Replacement (GMC) or Tail Lamp Replacement (HD) .
1	Back Up Lamp Bulb

Scheme 48

Scheme 48: Backup Lamp Bulb Replacement (GMC)

Callout	Component Name
Preliminary Procedure: Remove either the LR or RR tail lamp assembly. Refer to Tail Lamp Replacement (Chevrolet) or Tail Lamp Replacement (GMC) or Tail Lamp Replacement (HD) .
1	Back Up Lamp Bulb

Scheme 49

Scheme 49: Rear License Plate Lamp Replacement (VF7)

Callout	Component Name
1	License Plate Lamp Electrical Connector Tip: Disconnect the electrical connector from the rear junction block.
2	Rear License Plate Lamp Assembly

Scheme 50

Scheme 50: Rear License Plate Lamp Replacement (Chevrolet GMC)

Callout	Component Name
Preliminary Procedures Ensure the headlamp switch is in the OFF position. Reach under the bumper and press on the lens end of the cover in order to release the locking tab. Push outward to disengage the lens housing from the rear bumper. Remove the lens housing from the bumper assembly. Remove and replace the bulb as needed.
1	Rear License Plate Lamp Tip: Inspect the operation of the lamp prior to the re-installation of the lens cover assembly.

Scheme 51

Scheme 51: Rear License Plate Lamp Bulb Replacement

Callout	Component Name
Procedure Reach under the rear bumper for the bulb socket. Turn the bulb socket counter-clockwise and pull the bulb socket out of the connector. Pull the old bulb from the socket, keeping the bulb straight as you pull it out. Install the new bulb.
1	Bulb Socket
2	Rear License Plate Lamp Bulb

Scheme 52

Scheme 52: Tail Lamp Replacement (Chevrolet)

Callout	Component Name
Preliminary Procedure: Open the endgate in order to access the tail lamp assembly screws.
1	Tail Lamp Assembly Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2	Tail Lamp Wiring Harness Assembly Connector
3	Tail Lamp Assembly Tip: Upon installation, push inward on the tail lamp in order to seat the 2 locating pins in the body panel.

CAUTION
Refer to Fastener Caution .

Scheme 53

Scheme 53: Tail Lamp Replacement (GMC)

Callout	Component Name
Preliminary Procedures Open the endgate in order to access the tail lamp assembly screws. Disconnect the electrical harness to the tail lamp.
1	Tail Lamp Assembly Screws (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2	Tail Lamp Assembly Tip: Upon installation, push inward on the outer edge of the tail lamp in order to seat the 2 locating pins in the body panel.

CAUTION
Refer to Fastener Caution .

Scheme 54

Scheme 54: Tail Lamp Replacement (HD)

Callout	Component Name
Preliminary Procedures Open the endgate in order to access the tail lamp assembly screws. Disconnect the electrical harness to the tail lamp.
1	Tail Lamp Assembly Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2	Tail Lamp Assembly Tip: Upon installation, push inward on the outer edge of the tail lamp in order to seat the 2 locating pins in the body panel. prior to installing the screws.

CAUTION
Refer to Fastener Caution .

Scheme 55

Scheme 55: Tail Lamp Bulb Replacement (Chevrolet)

Callout	Component Name
Preliminary Procedure: Remove the rear tail lamp. Refer to Tail Lamp Replacement (Chevrolet) or Tail Lamp Replacement (GMC) or Tail Lamp Replacement (HD) .
1	Park and Turn Signal Lamp Bulb (Qty: 2)

Scheme 56

Scheme 56: Tail Lamp Bulb Replacement (GMC)

Callout	Component Name
Preliminary Procedure: Remove the rear tail lamp. Refer to Tail Lamp Replacement (Chevrolet) or Tail Lamp Replacement (GMC) or Tail Lamp Replacement (HD) .
1	Park and Turn Signal Lamp Bulbs (Qty: 2)
