Wiring diagram: Computer data lines — Computer data lines circuit GMC Sierra Classic 2500 HD
All systems
- Air conditioning 4
- Anti-lock brakes 4
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan 2
- Cruise control 4.3l vin x
- Cruise control 4.8l vin v
- Cruise control 5.3l vin b
- Cruise control 5.3l vin t
- Cruise control 5.3l vin z
- Cruise control 6.0l vin n
- Cruise control 6.0l vin u
- Cruise control 6.6l vin 2
- Cruise control 6.6l vin d
- Cruise control 8.1l vin g
- Defoggers 2
- Electronic power steering
- Electronic suspension
- Engine performance 4.3l vin x
- Engine performance 4.8l vin v
- Engine performance 5.3l vin b
- Engine performance 5.3l vin t 2
- Engine performance 5.3l vin z
- Engine performance 6.0l vin n
- Engine performance 6.0l vin u
- Engine performance 6.6l vin 2
- Engine performance 6.6l vin d
- Engine performance 8.1l vin g
- Exterior lights 3
- Ground distribution 2
- Headlights
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems 2
- Power distribution 4.3l vin x
- Power distribution 4.8l vin v
- Power distribution 5.3l vin b
- Power distribution 5.3l vin t 2
- Power distribution 5.3l vin z
- Power distribution 6.0l bi-fuel
- Power distribution 6.0l vin n
- Power distribution 6.0l vin u
- Power distribution 6.6l vin 2
- Power distribution 6.6l vin d
- Power distribution 8.1l vin g
- Power door locks 2
- Power mirrors 2
- Power seats 4
- Power top/sunroof
- Power windows
- Radio 6
- Shift interlock
- Starting/charging 5
- Starting/charging 6.0l vin u
- Starting/charging 6.6l vin 2
- Starting/charging 6.6l vin d
- Starting/charging 8.1l vin g
- Supplemental restraints
- Transmission 4.3l vin x 3
- Transmission 4.8l vin v 3
- Transmission 5.3l vin b 3
- Transmission 5.3l vin t 4
- Transmission 5.3l vin z 3
- Transmission 6.0l vin n 4
- Transmission 6.0l vin u 4
- Transmission 6.6l vin 2 3
- Transmission 6.6l vin d 3
- Transmission 8.1l vin g 3
- Warning systems 2
- Wiper/washer
Computer data lines circuit (1 of 2) GMC Sierra Classic 2500 HD
Components on the diagram
Computer data lines circuit (2 of 2) GMC Sierra Classic 2500 HD
Components on the diagram
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
