Power Outlets: Removal & Installation GMC Sierra 3500

Body Electrical 1 illustration ~441 words

120 Volt Receptacle Replacement

CAUTIONTo reduce the risk of severe shock and burns, disable the 42 volt (42V) system anytime you perform service work on or around the energy storage box (ESB). The 42V system will still be active after you have disabled the ESB.
CAUTIONTo reduce the risk of severe shock and burns, always disconnect the 42 volt (42V) energy storage box (ESB) before doing any work to the ESB system. To disconnect the ESB, turn the engine off and turn OFF the service disconnect switch, which is located on the passenger side of the ESB.

Removal Procedure

  1. Disconnect the energy storage box (ESB). Refer to «Energy Storage Box (ESB) Service Disconnect/Connect (5.3L Engine w/RPO HP2)»(ref-184144-S17357825682005082200000) in Engine Electrical.
  2. Remove the receptacle outlet screws (2).
  3. Remove the receptacle outlet (3) from the receptacle box (1).
  4. Disconnect the receptacle electrical connections.

Installation Procedure

  1. Connect the receptacle electrical connections.
  2. Install the receptacle outlet (3) to the receptacle box (1).
  3. Install the receptacle outlet screws (2). Tighten: Tighten the screws to 2 N.m (18 lb in).
  4. Connect the ESB. Refer to «Energy Storage Box (ESB) Service Disconnect/Connect (5.3L Engine w/RPO HP2)»(ref-184144-S17357825682005082200000) in Engine Electrical.

Accessory Power Receptacle Replacement - 12 Volt

Tools Required

J 42059 Cigar Lighter Socket Remover. See Special Tools .

Scheme 128

Scheme 128: Removal Procedure
  1. Remove the power supply fuse.
  2. Lift up the front cover of the receptacle.
  3. Insert the J 42059 into the receptacle sleeve. See «Special Tools»(ref-184151-S02020278552005082200000) . Tilt the tool so that the tool fits into the slots on the sides of the receptacle sleeve.
  4. Hold the plastic ring in place. Pull the receptacle out of the assembly in order to remove the outlet.
  5. If J 42059 tool fails to release the power port/lighter socket from the retainer, perform the following alternate method: Insert a small grinding tool with a cutoff wheel into the socket. Remove the plastic latches in the 3 mm (0.11 in) square windows. Use the J 42059 as directed above to remove the socket.
  6. Remove the electrical connector from the socket.
  1. Insert the plastic ring into the opening and snap the plastic ring into place.
  2. Connect the electrical connector to the receptacle.
  3. Insert the receptacle through the plastic ring gently by hand until the receptacle ring is sealed.
  4. Install the power supply fuse.

The Auxiliary Power Outlet (APO) system provides up to 2,400 watts of 120-volt AC power. With these power outlets, you can plug in most auxiliary electrical equipment and devices with a maximum limit of 2,400 watts. If you try to use equipment that requires more than the limit, a 20-amp protection circuit will cut the power supply and a light in the APO switch will flash along with a Driver Information Center (DIC) message that will flash 120V OVERLOAD.

When running APO, do not have the front of the vehicle obstructed. Leave at least five feet (1.5 m) of space between the front of the vehicle and any other object. This will allow airflow through the radiator and help to keep the SGCM cooler.

The power outlets are not designed for equipment with high initial peak starting power of greater than 2,400 watts, such as some air compressors, table saws, etc.
