Wiring diagram: Computer data lines — Computer data lines circuit GMC Sierra 3500 HD
All systems
- Air conditioning 3
- Anti-lock brakes 9
- Anti-theft
- Body control modules
- Computer data lines
- Cooling fan
- Cooling fan 6.0l vin g
- Cooling fan 6.6l vin 8
- Cooling fan 6.6l vin l
- Cruise control 6.0l vin g
- Cruise control 6.0l vin k
- Cruise control 6.6l vin 6
- Cruise control 6.6l vin 8
- Cruise control 6.6l vin l
- Defoggers 8
- Engine performance 6.0l vin g
- Engine performance 6.0l vin k
- Engine performance 6.6l vin 6
- Engine performance 6.6l vin 8
- Engine performance 6.6l vin l
- Exterior lights 4
- Ground distribution
- Headlights
- Horn
- Instrument cluster
- Interior lights 6
- Memory systems 3
- Navigation 15
- Power distribution 6.0l vin g
- Power distribution 6.0l vin k
- Power distribution 6.6l vin 6
- Power distribution 6.6l vin 8
- Power distribution 6.6l vin k
- Power distribution 6.6l vin l
- Power door locks 6
- Power mirrors 7
- Power seats 10
- Power top/sunroof
- Power windows 7
- Radio 13
- Shift interlock
- Starting/charging 3
- Starting/charging 6.0l vin g 2
- Starting/charging 6.0l vin k 2
- Starting/charging 6.6l vin 6 2
- Starting/charging 6.6l vin 8 2
- Starting/charging 6.6l vin l 2
- Supplemental restraints
- Transmission 2
- Transmission 6.0l vin g 3
- Transmission 6.0l vin k 4
- Transmission 6.6l vin 6 5
- Transmission 6.6l vin 8 4
- Transmission 6.6l vin l 4
- Warning systems 7
- Wiper/washer 3
Computer data lines circuit (1 of 2) GMC Sierra 3500 HD
Components on the diagram
Computer data lines circuit (1 of 3) GMC Sierra 3500 HD
Components on the diagram
Computer data lines circuit (2 of 2) GMC Sierra 3500 HD
Components on the diagram
Computer data lines circuit (2 of 3) GMC Sierra 3500 HD
Components on the diagram
Computer data lines circuit (3 of 3) GMC Sierra 3500 HD
Components on the diagram
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
